Ubiquiti Wave-Pico Wave Pico

https://arcip.com.au/web/image/product.template/7888/image_1920?unique=1a15e79
Wave Pico. Max. link range:— Wave AP: 1.3 km— Wave AP Micro: 0.9 km. Max. total throughput: 2 Gbps. 5 GHz weatherproof backup radio (Max. throughput: 800 Mbps). Australian stock from ARC IP Networks.

344.85 344.85 AUD 344.85 incl. GST

Not Available For Sale


  • Max Throughput
  • Coverage Area
  • Brand

This combination does not exist.

UISP Ubiquiti
  • Stock

    Authorised Australian Reseller | Australian Stock | Genuine Local Warranty

  • Instalment
    Buy Now, Pay Later
  • [Warranty Information] Warranty
    Manufacturer Warranty
Estimate delivery
Shipping calculated at checkout
Estimate delivery times: 3-7 business days
Guaranteed Safe Checkout
Guaranteed Safe Checkout
SKU
Wave-Pico
Tags
Wave-Pico
Wave Pico

Features

  • Max. link range:— Wave AP: 1.3 km— Wave AP Micro: 0.9 km
  • Max. total throughput: 2 Gbps
  • 5 GHz weatherproof backup radio (Max. throughput: 800 Mbps)
  • (1) GbE RJ45 port
  • Integrated Bluetooth

Specifications

Mechanical
Dimensions⌀152.1 x 55.8 mm / (⌀6 x 2.2")
WeightWithout mount: 347 g (12.2 oz) / With mount: 409 g (14.4 oz)
Enclosure MaterialUV stabilized polycarbonate
Mount MaterialUV stabilized polycarbonate
MountingPole Mount
Pole Mount Diameter20 to 53.1 mm (0.8 to 2.1")
Wind Loading31.3 N at 200 km/h (7 lbf at 125 mph)
WeatherproofingIPX6
Hardware
ProcessorDual-core ARM® Cortex®-A53 at 1 GHz
Memory512 MB
Networking Interface(1) GbE RJ45 port
Max. Power Consumption10W
Power MethodPassive PoE 4-pairs (1, 2+; 3, 6-) (4, 5+; 7, 8 -) / Passive PoE 2-pairs (4, 5+; 7, 8 -), for 44–54V DC only
Supported Voltage Range44–54V DC / 22–27V DC
Power Supply48V DC, 0.5A gigabit PoE adapter (Included)
Buttons(1) Factory reset
PowerFlashing white: bootup in progress / White: not connected to UISP application / Blue: connected to UISP application / Flashing blue: locate in progress / Blue/white: firmware upgrade in progress
EthernetFlashing blue: Ethernet traffic detected
LinkWhite: 5 GHz link / Blue: 60 GHz link
Ambient Operating Temperature-40 to 60° C (-40 to 140° F)
Ambient Operating Humidity5 to 95% noncondensing
CertificationsFCC, IC, CE
Software
Operating ModesPtP / PtMP Station
NetworkBridge/Router mode
UISP webVersion 2.4.61 and later
UISP mobile iOS™Version 2.32.0 and later
System
Total Throughput2 Gbps
Max. RangePtP: up to 1.5 km (1 mile) / PtMP: up to 1.3 km (0.8 mile) (Wave AP), up to 0.9 km (0.55 mile) (Wave AP Micro, Wave AP Gen2)
EncryptionWPA2-PSK (AES)
Radio Frequency
Worldwide57–71 GHz
Channel Bandwidth2160, 1080, 540 MHz
Operating Channels58320, 59400, 60480, 61560, 62640, 63720, 64800, 65880, 66960, 68040, 69120, 70200, 70560 MHz
Modulation16QAM, QPSK
Antenna Gain27.7 dBi
PolarizationVertically-Linear
BeamwidthAzimuth: 3 dB 6° / Elevation: 3 dB 6°
Radio Frequency (Back-Up)
WiFi Standard802.11ax (WiFi 6)
US/CAU-NII-1 5150 - 5250 MHz / U-NII-2A 5250 - 5350 MHz / U-NII-2C 5470 - 5725 MHz / U-NII-3 5725 - 5850 MHz
Worldwide5180 - 5875 MHz
Channel Bandwidth20, 40, 80 MHz
ModulationBPSK (1⁄2), QPSK (1⁄2), QPSK (3⁄4), 16QAM (1⁄2), 16QAM (3⁄4), 64QAM (2⁄3), 64QAM (3⁄4), 64QAM (5⁄6), 256QAM (3⁄4), 256QAM (5⁄6), 1024QAM (3⁄4), 1024QAM (5⁄6)
Antenna Gain9 dBi
PolarizationDual-Linear
BeamwidthAzimuth: 3 dB 50° / Elevation: 3 dB 50°
Cross-Pol Isolation15 dB

Professional Overview

The Ubiquiti Wave-Pico is Lightweight, compact 60 GHz PtMP station powered by Wave Technology.. Key capabilities include max. link range:— wave ap: 1.3 km— wave ap micro: 0.9 km and max. total throughput: 2 gbps.

Performance specifications include total throughput of 2 Gbps.

The Wave-Pico integrates seamlessly with the Ubiquiti UniFi ecosystem, enabling centralized management through the UniFi Network application. Notable features include 5 ghz weatherproof backup radio (max. throughput: 800 mbps), (1) gbe rj45 port, integrated bluetooth.

Built to Ubiquiti's commercial-grade standards with a weight of Without mount: 347 g (12.2 oz) / With mount: 409 g (14.4 oz), featuring operating temperature range of -40 to 60° C (-40 to 140° F), FCC, IC, CE. Australian stock from ARC IP Networks with fast nationwide shipping and local support.

Max Throughput 2 Gbps
Coverage Area 44–54V DC / 22–27V DC
Brand Ubiquiti
