Ubiquiti UDM-Pro-Max-AU UniFi Dream Machine Pro Max with 2x HDD Bays 8 Port Switch Rackmount

https://arcip.com.au/web/image/product.template/3958/image_1920?unique=68bd5c0
The UDM-Pro-Max is a UniFi enterprise gateway. 10G Cloud Gateway with 200+ UniFi device / 2,000+ client support, 5 Gbps IPS routing, and redundant NVR storage.

1,108.46 1108.46 AUD 1,164.35 incl. GST

Not Available For Sale


  • Brand
  • Form Factor
  • IDS/IPS Throughput
  • Gateway Features

This combination does not exist.

In stock online
UniFi Gateway Rackmount Ubiquiti 5 Gbps IDS/IPS IDS/IPS VPN Firewall
UBIQUITI
UBIQUITI

Ubiquiti Inc. offers a wide range of networking solutions for service providers and enterprises, including fixed wireless broadband, wireless backhaul, routing, LAN infrastructure, and video surveillance. The company stands out through its proprietary software, advanced firmware, and innovative hardware design.

  • Stock

    Authorised Australian Reseller | Australian Stock | Genuine Local Warranty

  • Instalment
    Buy Now, Pay Later
  • [Warranty Information] Warranty
    Manufacturer Warranty
Estimate delivery
Shipping calculated at checkout
Estimate delivery times: 3-7 business days
Guaranteed Safe Checkout
Guaranteed Safe Checkout
SKU
UDM-Pro-Max
Barcode
810084693285
Tags
UDM-Pro-Max
Ubiquiti UniFi Dream Machine Pro Max — 5 Gbps IDS/IPS
UDM-Pro-Max
UDM-Pro-Max

Features

  • Enhanced computing power and memory for 2x the UniFi device and client capacity of Dream Machine Pro/SE
  • Includes full UniFi application suite for device management
  • 5 Gbps routing with IDS/IPS
  • (1) 10G SFP+*, (8) GbE RJ45 LAN ports
  • (1) 10G SFP+*, (1) 2.5 GbE RJ45 WAN ports
  • (2) 3.5" NVR HDD bays with RAID data protection
  • Built-in 128 GB SSD for NVR detection recordings
  • UniFi Power Backup ready
  • 1.3" touchscreen
  • *Pair with an official SFP+ Module or SFP+ to RJ45 Adapter for the best experience.

Specifications

Overview
Dimensions442.4 x 43.7 x 285.6 mm /
Managed UniFi Devices200+
Managed Cameras(50) HD / (25) 2K / (15) 4K
Managed Access Hubs150
Simultaneous Users Connected2,000+
Max. WAN Port Count8
Default WAN Ports(1) 10G SFP+ / (1) 2.5 GbE RJ45
1 GbE RJ458 / (1G/100M/10M)
2.5 GbE RJ451 / (2.5G/1G/100M/10M)
10G SFP+2 / (10G/1G)
IDS/IPS Throughput5 Gbps
Form FactorRack mount (1U)
RedundancyShadow Mode (VRRP) Gateway Failover / DC Power Backup
Security
IDS/IPS Signatures55,000+ / with CyberSecure
Networking
MAC Address Table Size4,000
Hardware
NVR Storage(2) 3.5" NVR HDD bays / Built-in 128 GB SSD for Faster Experience
Max. Power Consumption60W
Power Method(1) Universal AC input, 100–240V AC, 2A Max., 50/60 Hz / (1) USP-RPS DC input, 11.5V DC, 8.7A
Power SupplyAC/DC, internal, 100W
Supported Voltage Range100–240V AC
Heat Dissipation205 BTU/hr
ProcessorQuad-core ARM® Cortex®-A57 at 2.0 GHz
System Memory8 GB
On-board Storage32 GB eMMC / 128 GB SSD (Integrated)
Weight4.7 kg
Enclosure MaterialAluminium CNC, SGCC steel
Mount MaterialSGCC steel
LCM Display1.3" touchscreen
ManagementEthernet / Bluetooth
Button(1) Factory reset
ESD/EMP ProtectionAir: ± 15kV, contact: ± 8kV
Ambient Operating Temperature-10 to 40° C (14 to 104° F)
Ambient Operating Humidity5 to 95% noncondensing
CertificationsCE, FCC, IC, Anatel: 06369-24-08356, SRRC

Professional Overview

The Ubiquiti UDM-Pro-Max is a enterprise gateway for the UniFi ecosystem. 10G Cloud Gateway with 200+ UniFi device / 2,000+ client support, 5 Gbps IPS routing, and redundant NVR storage.

it delivers 5 Gbps IDS/IPS throughput for enterprise-grade security and traffic management.

Managed via the UniFi Network app for centralised configuration, DPI, and traffic analytics.

In a Rack mount (1U) form factor weighing 4.7 kg, the UDM-Pro-Max is designed for reliable 24/7 operation. Australian stock, fast shipping from ARC IP Networks.

Part of our Ubiquiti UniFi Routers range — browse and compare the full range of UniFi gateways, Dream Machines and routers.

Ubiquiti UDM-Pro-Max: the flagship 1U Dream Machine

The UniFi Dream Machine Pro Max is Ubiquiti's highest-capacity rack-mount Dream Machine. It is a 10G cloud gateway that runs the full UniFi application suite — Network, Protect, Access, Talk and Innerspace — from a single 1U appliance, with 5 Gbps IDS/IPS routing, support for 2,000+ clients and 200+ UniFi devices.

Ubiquiti positions it as roughly double the device and client capacity of the Dream Machine Pro and SE. That comes from a faster 2.0 GHz quad-core processor and 8 GB of memory, against 1.7 GHz and 4 GB in its siblings.

UDM-Pro-Max vs UDM-SE vs UDM-Pro

All three are 1U rack-mount Dream Machines sharing the same 55,000+ IDS/IPS signature set with CyberSecure, the same Shadow Mode (VRRP) gateway failover, and the same maximum of 8 WAN ports. The differences are capacity, storage and power.

UDM-Pro-MaxUDM-SEUDM-Pro
IDS/IPS throughput5 Gbps3.5 Gbps3.5 Gbps
Max. clients2,0001,0001,000
Managed UniFi devices200+100+100+
Managed cameras(50) HD / (25) 2K / (15) 4K(24) HD / (14) 2K / (8) 4K(24) HD / (14) 2K / (8) 4K
ProcessorQuad-core A57 @ 2.0 GHzQuad-core A57 @ 1.7 GHzQuad-core A57 @ 1.7 GHz
System memory8 GB4 GB4 GB
NVR HDD bays(2) 3.5"(1) 3.5"(1) 3.5"
Built-in SSD128 GB128 GBNone
PoE budgetNone180WNone
LAN ports(8) GbE + (1) 10G SFP+(8) GbE + (1) 10G SFP+(9) GbE + (1) 10G SFP+
Max. power consumption60W50W (excl. PoE)33W
Weight4.7 kg5 kg3.9 kg

Important: the Pro Max has no PoE

This is the detail that most often catches people upgrading, so it is worth stating plainly. The UDM-SE includes a 180W PoE budget and can power access points and cameras directly. The UDM-Pro-Max does not have PoE at all, and neither does the UDM-Pro.

If you are moving from a UDM-SE to a Pro Max for the extra capacity, you will need a PoE switch to power whatever the SE was feeding. Budget for it in the same order rather than discovering it during the cutover.

The trade-off is deliberate: the Pro Max spends its power and thermal headroom on compute and a second drive bay instead of PoE injection, which is the right call in a rack that already has switching.

Storage and video recording

The Pro Max is the only Dream Machine with two 3.5-inch NVR drive bays, which is what enables RAID data protection for surveillance footage — a single-bay recorder cannot protect against a drive failure.

Alongside those bays sit a built-in 128 GB SSD for detection recordings and faster UI responsiveness, plus 32 GB of eMMC for the system itself.

Camera capacity is 50 HD, 25 2K or 15 4K streams — roughly double the UDM-SE. If you need more than that, a dedicated recorder is the better path; our UniFi Protect NVR comparison covers the options, and the Protect camera range shows what pairs with it.

Ports, WAN and redundancy

  • LAN: (8) GbE RJ45 plus (1) 10G SFP+
  • WAN: (1) 10G SFP+ plus (1) 2.5 GbE RJ45 as defaults, and up to 8 WAN ports can be configured
  • Failover: Shadow Mode (VRRP) gateway failover, so a second unit can take over if the primary fails
  • Power redundancy: universal AC input plus a USP-RPS DC input, and it is UniFi Power Backup ready
  • Display: 1.3-inch touchscreen for status and setup

Ubiquiti recommends pairing the SFP+ ports with an official SFP+ module or SFP+ to RJ45 adapter for the best experience. Note that the eight LAN ports are gigabit, not 2.5 GbE — the multi-gig capability is on the SFP+ and the WAN port.

Who the UDM-Pro-Max is for

  • Sites that outgrew a UDM-Pro or SE. Double the clients, double the managed devices and a faster inspection engine, without changing platform.
  • Multi-tenant and larger business sites running 2,000+ clients across a substantial UniFi estate.
  • Deployments needing RAID-protected video where a single drive bay is not acceptable.
  • Full UniFi suite sites running Network, Protect, Access, Talk and Innerspace together on one appliance, with 150 managed Access hubs.
  • Anyone wanting 5 Gbps IPS — if you have a multi-gig internet service, the 3.5 Gbps of the Pro and SE becomes the ceiling.

Comparing across the range? See our Dream Machine comparison, the cloud gateway comparison and the rack-mount gateway guide.

Frequently Asked Questions

What is the difference between the UDM-Pro-Max and the UDM-SE?

The Pro Max has 5 Gbps IDS/IPS versus 3.5 Gbps, supports 2,000 clients versus 1,000, manages 200+ UniFi devices versus 100+, has 8 GB of memory versus 4 GB, and has two 3.5-inch drive bays versus one. The key thing the SE has that the Pro Max does not is a 180W PoE budget.

Does the UDM-Pro-Max have PoE?

No. Neither the UDM-Pro-Max nor the UDM-Pro provides PoE. Only the UDM-SE includes a PoE budget, at 180W. If you need to power access points or cameras from the gateway, you will need a separate PoE switch.

How many clients can the UDM-Pro-Max handle?

Up to 2,000 simultaneous clients and 200+ managed UniFi devices, which is roughly double the capacity of the Dream Machine Pro and SE.

How fast is the firewall?

5 Gbps of IDS/IPS routing throughput, with 55,000+ threat signatures when CyberSecure is enabled.

How many cameras can it record?

50 HD, 25 2K or 15 4K camera streams, using its two 3.5-inch NVR drive bays plus the built-in 128 GB SSD.

Can I run RAID on the UDM-Pro-Max?

Yes. It is the only Dream Machine with two 3.5-inch NVR bays, which allows RAID data protection for recorded video. Single-bay models cannot protect against a drive failure.

What hard drives does it take?

Two 3.5-inch drives in the NVR bays. Surveillance-rated drives are recommended for continuous recording.

What ports does the UDM-Pro-Max have?

Eight GbE RJ45 LAN ports and one 10G SFP+ LAN port, plus one 10G SFP+ and one 2.5 GbE RJ45 as default WAN ports. Up to eight WAN ports can be configured.

Are the LAN ports 2.5 GbE?

No. The eight LAN ports are gigabit. The multi-gig connectivity is on the 10G SFP+ ports and the 2.5 GbE WAN port.

Does it support redundant power?

Yes. It has a universal AC input and a USP-RPS DC input, and is UniFi Power Backup ready. It also supports Shadow Mode (VRRP) gateway failover for redundancy at the gateway level.

How much rack space does it need?

One rack unit. It measures 442.4 x 43.7 x 285.6 mm and weighs 4.7 kg.

Is there a licence or subscription fee?

No. UniFi has no recurring licensing costs. CyberSecure is the one optional paid add-on for the expanded threat signature set.

Is the UDM-Pro-Max available in Australia?

Yes. ARC IP Networks is an authorised Ubiquiti reseller holding Australian stock with full manufacturer warranty and fast domestic shipping.

ARC IP Networks, authorised Ubiquiti reseller in Australia — Australian stock, manufacturer warranty, fast shipping, trade pricing.
ARC IP Networks is an authorised Ubiquiti reseller in Australia — Australian stock, full manufacturer warranty, fast shipping and trade pricing. Call 1300 100 440 or read more about buying from an authorised reseller.

Buy the Ubiquiti UDM-Pro-Max in Australia

ARC IP Networks is an authorised Ubiquiti reseller supplying the UDM-Pro-Max from Australian stock, with full manufacturer warranty and fast shipping nationwide.

  • Authorised Ubiquiti reseller — genuine Australian stock, not grey import
  • Full manufacturer warranty with local RMA support
  • Competitive pricing, monitored against the Australian market daily
  • Fast dispatch Australia-wide, or collect from our warehouse
  • Trade and project pricing for installers, MSPs and multi-site rollouts

Building a full rack? Browse UniFi cloud gateways, UniFi switches and the Protect camera range, or read about buying from an authorised Ubiquiti reseller in Australia. Comparing models? Start with UDM-Pro and UDM-SE.

Brand UBIQUITI
Form Factor Rack mount (1U)
IDS/IPS Throughput 5 Gbps
Gateway Features IDS/IPS, DPI, VPN, Traffic Management
