Ubiquiti ECS-24S Enterprise Campus 24S,Enterprise-Grade 24-Port,Layer 3 Etherlighting™ Switch Stacking,High-Capacity 10GbE RJ45

https://arcip.com.au/web/image/product.template/10580/image_1920?unique=6bbe47d

The Ubiquiti ECS-24S (Switch Enterprise Campus 24S) is an enterprise-grade 24-port Layer 3 Etherlighting switch with switch stacking, redundant PSUs and fans. It has 16 10 GbE RJ45, 8 2.5 GbE RJ45 and 1 GbE RJ45 ports, 4 25G SFP28 and 2 100G QSFP28 ports, plus a console port. Switching capacity is 460 Gbps with a 342 Mpps forwarding rate. Two hot-swappable 550W power modules and four hot-swappable fans sit in a 1U full-depth chassis that requires a 4-post rack (or a centre-mount bracket or cantilever shelf on 2-post racks). Ubiquiti recommends pairing it with Enterprise Campus Aggregation. Request a quote from ARC IP Networks for project pricing via Ubiquiti deal registration.

This product is supplied under the Ubiquiti Enterprise Program.


  • Brand

This combination does not exist.

UBIQUITI
UBIQUITI

Ubiquiti Inc. offers a wide range of networking solutions for service providers and enterprises, including fixed wireless broadband, wireless backhaul, routing, LAN infrastructure, and video surveillance. The company stands out through its proprietary software, advanced firmware, and innovative hardware design.

  • Stock

    Authorised Australian Reseller | Australian Stock | Genuine Local Warranty

  • Instalment
    Buy Now, Pay Later
  • [Warranty Information] Warranty
    Manufacturer Warranty
Estimate delivery
Shipping calculated at checkout
Estimate delivery times: 3-7 business days
Guaranteed Safe Checkout
Guaranteed Safe Checkout
Accepted payments: Google Pay, Apple Pay, Visa, Mastercard and PayPal
SKU
ECS-24S
Barcode
810177163206

Ubiquiti ECS-24S at a glance

The Ubiquiti ECS-24S (Switch Enterprise Campus 24S) is an enterprise-grade 24-port, Layer 3 Etherlighting™ switch with Stacking support. It combines 16 x 10 GbE RJ45, 4 x 25G SFP28 and 2 x 100G QSFP28 ports with 460 Gbps switching capacity, and has two hot-swappable PSUs and four hot-swappable fans.

ARC IP Networks is an authorised Ubiquiti reseller in Australia. We supply the genuine UniFi Switch Enterprise Campus 24S under the Ubiquiti Enterprise programme with the full manufacturer's warranty. Contact us before ordering for project pricing and lead time.

Layer 3Etherlighting™ switch with Stacking
10 GbE RJ4516 ports
25G SFP284 ports
100G QSFP282 ports
Switching capacity460 Gbps
Redundancy2 PSUs, 4 fans, stacking
Max. power150W
Form factor1U, full-depth rack mount

Best for

  • High availability system design
  • Enterprise campus switching with 10 GbE and 25G connections
  • Stacked switch deployments

Consider instead

💼

Ubiquiti Enterprise Program

The Ubiquiti ECS-24S is supplied under the Ubiquiti Enterprise Program. Please contact ARC IP Networks before ordering for project pricing and lead time.

Key features

See the UniFi Switch Enterprise Campus 24S




Introducing: Next-Gen Enterprise Networking (Video: Ubiquiti)

Ubiquiti ECS-24S specifications

Overview

Dimensions442.4 x 44 x 496 mm / (17.4 x 1.7 x 19.5")
1 GbE RJ451 / (1G/100M/10M)
2.5 GbE RJ458 / (2.5G/1G/100M/10M)
10 GbE RJ4516 / (10G/5G/2.5G/1G/100M/10M)
25G SFP284 / (25G/10G/1G)
100G QSFP282 / (100G)
Console1
RedundancySwitch Stacking / (2) Hot-Swappable PSUs / (4) Hot-Swappable Fans
Form FactorRack Mount (1U, Full-Depth)

Performance

Switching Capacity460 Gbps
Total Non-Blocking Throughput230 Gbps
Forwarding Rate342 Mpps
Supported VLANs1,000
MAC Address Table Size32,000
IPv4 Static Routes512
Packet Buffer Size8 MB

Hardware

Max. Power Consumption150W
Power Method(2) Universal input, 100–240V AC, 50/60 Hz
Power Input Method(2) AC input, Hot-swappable power modules
Power Supply(2) Hot-swappable AC/DC 550W power modules
Supported Voltage Range100–240V AC
ManagementEthernet / OOB Management port / Serial Console / AR
Heat Dissipation512 BTU/hr
WeightWithout mounting brackets: 9.6 kg (21.1 lb) / With mounting brackets: 9.7 kg (21.3 lb)
Enclosure MaterialSGCC steel
Mount MaterialSGCC steel
Supported Rack Depth482.6 mm (19") four-post racks / Posts depths ranging from 650 to 1,000 mm (25.6–39.4”)
LCM Display1.3" touchscreen
Fan Method(4) Hot-swappable fan modules
ESD ProtectionAir: ± 12kV, contact: ± 8kV
Ambient Operating Temperature-5 to 40° C (23 to 104° F)
Ambient Operating Humidity10 to 90% noncondensing
CertificationsCE, FCC, IC

Software

UniFi NetworkVersion 10.6.101 and later

Specifications from Ubiquiti's official product data for the ECS-24S, checked October 2026.

The UniFi Switch Enterprise Campus 24S in depth

Enterprise-grade Layer 3 switching

The ECS-24S is a 24-port Layer 3 Etherlighting™ switch built for high availability system design. It supports Stacking and offers a mix of high-capacity connections: 16 x 10 GbE RJ45 ports, 8 x 2.5 GbE RJ45 ports, 1 x 1 GbE RJ45 port, 4 x 25G SFP28 ports and 2 x 100G QSFP28 ports. It also has a console port and an OOB management port.

Performance and redundancy

The switch provides 460 Gbps switching capacity, 230 Gbps total non-blocking throughput and a 342 Mpps forwarding rate. It supports 1,000 VLANs, a 32,000-entry MAC address table, 512 IPv4 static routes and an 8 MB packet buffer. For resilience it has Switch Stacking, two hot-swappable 550W AC/DC power modules (100–240V AC, 50/60 Hz) and four hot-swappable fan modules.

Hardware and installation

The 1U full-depth SGCC steel chassis measures 442.4 x 44 x 496 mm and weighs 9.6 kg without mounting brackets. A 1.3" touchscreen LCM display is built in. It requires a 4-post rack, or a centre-mount bracket or cantilever shelf on 2-post racks for optimal support. It is recommended to pair it with Enterprise Campus Aggregation, and it works with UniFi Network version 10.6.101 and later.

Frequently asked questions

Straight answers about the UniFi Switch Enterprise Campus 24S from the ARC IP Networks team. Last reviewed October 2026.

The Ubiquiti ECS-24S is the Switch Enterprise Campus 24S, an enterprise-grade 24-port Layer 3 Etherlighting™ switch with Stacking support. It offers 10 GbE RJ45, 25G SFP28 and 100G QSFP28 connections.

It has 1 x 1 GbE RJ45, 8 x 2.5 GbE RJ45, 16 x 10 GbE RJ45, 4 x 25G SFP28 and 2 x 100G QSFP28 ports. There is also 1 console port.

Yes. It has two hot-swappable AC/DC 550W power modules with 100–240V AC universal input, plus four hot-swappable fan modules. It also supports Switch Stacking.

It is a 1U full-depth rack-mount switch and requires a 4-post rack, or a centre-mount bracket or cantilever shelf on 2-post racks for optimal support. Supported post depths range from 650 to 1,000 mm.

The ambient operating temperature is -5 to 40° C, with 10 to 90% noncondensing humidity.

ARC IP Networks is an authorised Ubiquiti reseller. The ECS-24S is part of the Ubiquiti Enterprise programme, so contact us for project pricing via Ubiquiti deal registration.

Buy the Ubiquiti ECS-24S in Australia

ARC IP Networks is an authorised Ubiquiti reseller supplying UniFi networking, WiFi, camera and access products to businesses, schools, MSPs and installers across Australia.

  • Genuine Ubiquiti: sourced through Ubiquiti's authorised Australian distribution.
  • Ubiquiti Enterprise programme: project pricing via Ubiquiti deal registration.
  • Full manufacturer's warranty and local pre-sales and after-sales support.
  • Trade and project pricing available.

Planning an enterprise campus deployment with the ECS-24S?

Ask ARC IP Networks for project pricing or a configured quote, or call us to check the right model for your site.
