Ubiquiti NBE-M5-16 5GHz NanoBeam, AIRMAX, 16dB includes POE injector

https://arcip.com.au/web/image/product.template/3796/image_1920?unique=8867584
The Ubiquiti NanoBeam M5 16 is a compact, high-performance CPE for 5GHz networks. It integrates a 16dBi antenna and airMAX technology to deliver reliable connectivity for PtP and PtMP links.

113.85 113.85 AUD 113.85 incl. GST

Not Available For Sale


  • Brand

This combination does not exist.

Ubiquiti airMAX
UBIQUITI
UBIQUITI

Ubiquiti Inc. offers a wide range of networking solutions for service providers and enterprises, including fixed wireless broadband, wireless backhaul, routing, LAN infrastructure, and video surveillance. The company stands out through its proprietary software, advanced firmware, and innovative hardware design.

  • Stock

    Authorised Australian Reseller | Australian Stock | Genuine Local Warranty

  • Instalment
    Buy Now, Pay Later
  • [Warranty Information] Warranty
    Manufacturer Warranty
Estimate delivery
Shipping calculated at checkout
Estimate delivery times: 3-7 business days
Guaranteed Safe Checkout
Guaranteed Safe Checkout
SKU
NBE-M5-16
Barcode
810354024955
Tags
NBE-M5-16
Ubiquiti NBE-M5-16 5GHz NanoBeam, AIRMAX, 16dB includes POE injector

Features

  • airMAX® TDMA protocol for enhanced network performance
  • InnerFeed® technology integrates the radio into the antenna feedhorn
  • High-gain 16 dBi antenna for reliable links
  • Focused beamwidth for improved noise immunity
  • Compact, all-in-one design with ball-joint mount for flexible aiming
  • Powered by 24V Passive Power over Ethernet (PoE)

Specifications

Network
Frequency5170 - 5875 MHz
Gain16 dBi
Max. Throughput150+ Mbps
Networking Interface(1) 10/100 Ethernet Port
General
ProcessorAtheros MIPS 74Kc, 560 MHz
Memory64 MB DDR2
Power Method24V Passive PoE (Pairs 4, 5+; 7, 8 Return)
Max. Power Consumption6W
Wind Survivability200 km/h (125 mph)
MountingPole-Mount (Kit Included)
Dimensions140 x 140 x 54 mm
Weight0.320 kg

Professional Overview

The Ubiquiti NanoBeam M5 16 (NBE-M5-16) is a compact and highly efficient Customer Premises Equipment (CPE) device, renowned for its reliability and performance in 5 GHz wireless networks. It is a workhorse for Wireless Internet Service Providers (WISPs), serving as an ideal solution for short to mid-range Point-to-Point (PtP) bridges and as a robust client (station) in Point-to-MultiPoint (PtMP) deployments.

A key to the NanoBeam's excellent performance is Ubiquiti's InnerFeed® technology, which intelligently integrates the radio directly into the feedhorn of the antenna. This innovative design eliminates the need for a connecting cable, thereby preventing cable losses and resulting in a more efficient and powerful signal path. This is combined with Ubiquiti's proven airMAX Time Division Multiple Access (TDMA) protocol, which enhances network scalability, throughput, and latency performance, especially in multipoint networks.

The NBE-M5-16 is specifically designed to combat interference in the often-congested 5 GHz spectrum. Its 16 dBi antenna focuses the RF energy into a tight, uniform beamwidth. This directional focus filters out extraneous RF noise, significantly improving noise immunity and allowing the device to maintain a stable, high-quality link even in areas with numerous other wireless signals. The result is a more reliable and higher-performing connection for the end user.

Installation and deployment are made simple and efficient. The NanoBeam's all-in-one, weatherproof design is complemented by an innovative ball-joint mount that provides flexible three-axis adjustment for quick and precise aiming. Powered by 24V passive PoE, the device requires only a single Ethernet cable for both power and data, streamlining the installation process. Its combination of performance, noise immunity, and ease of use makes the NBE-M5-16 an exceptional value and a staple in professional wireless networks.
