D-Link DWM-314-G 5G Multi-Connect Dual SIM M2M VPN Router

Price:

1,031.84


Grandstream GRP2602G 2 Lines 4 SIP Accounts IP Phone w/Gigabit PoE
Grandstream GRP2602G 2 Lines 4 SIP Accounts IP Phone w/Gigabit PoE
93.06
93.06
Grandstream GRP2612 4 Lines, 2 SIP Accounts 2.4" Display DC Plug
Grandstream GRP2612 4 Lines, 2 SIP Accounts 2.4" Display DC Plug
106.92
106.92

D-Link DWM-314-G 5G Multi-Connect Dual SIM M2M VPN Router

https://arcip.com.au/web/image/product.template/8733/image_1920?unique=2a91b2c
D-Link DWM-314-G is a 5G SA/NSA + 4G LTE Cat.19 M2M VPN router with dual Micro-SIM auto-failover, 4× Gigabit Ethernet LAN ports, OpenVPN and WireGuard VPN client support, DC 9–36 V input, and a zinc-plated corrosion-resistant industrial chassis rated −30 to 70 °C. Mounts on a wall or DIN rail, managed via Web UI, SSH, or D-Link D-ECS cloud platform. Ideal for EV chargers, parking meters, ATMs, kiosks, smart bus stops, and remote surveillance. Australian stock from ARC IP Networks.

1,031.84 1031.84 AUD 1,031.84 incl. GST

Not Available For Sale


  • Brand
  • Form Factor
  • Network Connectivity
  • LAN Ports
  • Use Case
  • WAN Type
  • SIM Slots
  • VPN Support
  • Power Input
  • Operating Temperature

This combination does not exist.

  • Stock

    Authorised Australian Reseller | Australian Stock | Genuine Local Warranty

  • Instalment
    Buy Now, Pay Later
  • [Warranty Information] Warranty
    Manufacturer Warranty
Estimate delivery
Shipping calculated at checkout
Estimate delivery times: 3-7 business days
Guaranteed Safe Checkout
Guaranteed Safe Checkout
SKU
DWM-314-G
DWM-314-G
D-Link DWM-314-G — 5G NR + 4G LTE Cat.19 Dual Micro-SIM M2M VPN Router with 4× Gigabit LAN

Features

  • 5G NR (Sub-6 GHz) SA and NSA — up to 3.4 Gbps downlink / 550 Mbps uplink (NSA), 2.4 Gbps / 900 Mbps (SA)
  • 4G LTE Cat.19 DL / Cat.18 UL — up to 1.6 Gbps downlink / 200 Mbps uplink as fallback
  • Dual Micro-SIM (3FF) with automatic failover between carriers for uninterrupted WAN connectivity
  • 4× Gigabit Ethernet LAN ports — no extra switch required for multi-device M2M deployments
  • Secure VPN tunnels: OpenVPN and WireGuard client modes
  • Integrated firewall: IPS, Block WAN Ping, Packet Filter, MAC access control
  • DHCP server, port forwarding (virtual server), DDNS (DynDNS, No-IP, Dynamic DO), static routing, IPv4/v6 dual-stack
  • 4× SMA(F) external cellular antenna connectors for optimal signal placement
  • Wide 9–36 V DC power input with 2-pin terminal block — suits vehicle, industrial, and solar deployments
  • Zinc-plated corrosion-resistant steel case rated −30 to 70 °C operating, 10–95% humidity
  • Wall or DIN-rail mount — compact 131 × 99 × 40 mm chassis
  • Management via Web UI, SSH, Command Script, and optional D-Link D-ECS cloud platform (license required)
  • SMS service for data-usage warnings and event notifications

Specifications

Cellular / WAN
Cellular Module5G/4G 3GPP Rel. 16
Cellular Standards5G NR (Sub-6 GHz), 4G LTE (DL Cat.19 / UL Cat.18)
Max 5G NSA Throughput3.4 Gbps DL / 550 Mbps UL
Max 5G SA Throughput2.4 Gbps DL / 900 Mbps UL
Max LTE Throughput1.6 Gbps DL / 200 Mbps UL
SIM Slots2× Micro-SIM (3FF) with auto-failover
Antennas4× SMA(F) cellular antenna connectors
Network MonitorICMP checking
WAN NATSupported
LAN / Ethernet
LAN Ports4× Gigabit Ethernet
DHCPDHCP Server
Port ForwardVirtual Server
DDNSDynDNS, No-IP, Dynamic DO
RoutingStatic route, Routing information, IPv4/v6 dual-stack
VPN / Security / Firewall
VPN TunnelOpenVPN, WireGuard (Client mode)
FirewallIPS, Block WAN Ping
Access ControlPacket Filter, MAC control
Management
ConfigurationWeb UI, Command Script, SSH
Cloud ManagementD-Link D-ECS (license applies)
SystemFirmware Upgrade, Reboot & Reset, System Time, NTP Service, System Log
SchedulingReboot rule policy, working-day schedule
SMS ServiceSMS Inbox, SMS Event Management, Data-usage warning ratio
Status MonitoringCellular modem info, cellular signal quality, data usage, VPN status, client list
Physical / Environmental
Dimensions131 × 99 × 40 mm
Power InputDC 9–36 V (TB 2-pin terminal block)
Operating Temperature−30 to 70 °C
Storage Temperature−40 to 85 °C
Operating Humidity10–95% non-condensing
Storage Humidity0–95% non-condensing
MountingWall mount or DIN rail
Case MaterialZinc-plated corrosion-resistant steel
Certifications
StandardsCE, UKCA, RCM
Barcode / UPC790069475252

DWM-314-G FAQ

Does the DWM-314-G work with Australian 5G carriers (Telstra, Optus, Vodafone)?

Yes. The DWM-314-G supports 3GPP Rel. 16 5G NR Sub-6 GHz (SA and NSA) and 4G LTE Cat.19, and is RCM-certified for Australia — compatible with Telstra, Optus, and Vodafone/TPG 5G and 4G networks via standard 3FF Micro-SIM cards. Band 28 support covers Australian low-band 4G coverage.

How does the dual-SIM auto-failover work?

The DWM-314-G has two Micro-SIM (3FF) slots. Insert two SIMs from different carriers and the router will automatically fail over to the secondary SIM if the primary connection becomes unavailable — critical for mission-sensitive M2M deployments such as EV chargers, ATMs, smart parking meters, and remote surveillance where downtime is expensive.

What VPN protocols does the DWM-314-G support?

The DWM-314-G supports two modern VPN clients natively: OpenVPN and WireGuard. Both run in client mode and terminate a VPN tunnel from the device to a central concentrator, securing all traffic from the connected LAN devices. This is ideal for site-to-cloud or site-to-headquarters M2M security.

Does the DWM-314-G have any Wi-Fi, or is it purely cellular + Ethernet?

The DWM-314-G is purely a cellular + Ethernet device — it provides 5G/4G WAN connectivity and four Gigabit Ethernet LAN ports, but does not have built-in Wi-Fi. Pair it with a separate Wi-Fi access point (for example D-Link DBR-X3000-AP) on one of the Ethernet ports if you need wireless clients.

Can the DWM-314-G run in vehicles or outdoor enclosures?

Yes. The industrial zinc-plated corrosion-resistant steel case, wide 9–36 V DC input (2-pin terminal block), DIN-rail / wall mounting, and −30 to 70 °C operating range make the DWM-314-G suitable for vehicles, outdoor cabinets, solar-powered remote sites, and industrial enclosures where traditional consumer routers fail.

How do I manage the DWM-314-G remotely?

Management options include the local Web UI, SSH, and command scripts for provisioning, plus the optional D-Link D-ECS cloud platform for centralised fleet management (license required). SMS event management and data-usage warning SMS provide out-of-band notifications. Australian stock from ARC IP Networks.

Professional Overview

The D-Link DWM-314-G is a ruggedised 5G Multi-Connect Dual-SIM M2M VPN router purpose-built for industrial and infrastructure applications. It combines 3GPP Release 16 5G NR (SA + NSA), 4G LTE Cat.19 fallback, and four Gigabit Ethernet LAN ports in a compact zinc-plated steel enclosure.

Dual Micro-SIM (3FF) slots with automatic failover deliver always-on WAN connectivity across two carrier networks — essential for unattended deployments such as EV chargers, ATMs, parking meters, vending machines, smart kiosks, bus stops, and remote surveillance where a single-carrier outage cannot bring the site offline.

OpenVPN and WireGuard VPN clients, a built-in firewall with IPS and WAN Ping blocking, and MAC/packet access control secure data in transit from the connected LAN to a central concentrator. Four SMA(F) external antenna connectors let integrators place antennas for optimum cellular reception inside metal enclosures or behind obstructions.

A wide 9–36 V DC input, DIN-rail and wall-mount options, and an operating range of −30 to 70 °C make the DWM-314-G viable for vehicles, solar sites, outdoor cabinets, and cold-chain logistics. Remote management is available via Web UI, SSH, command script, and the optional D-Link D-ECS cloud platform (license required), with SMS event alerts and data-usage warnings for out-of-band diagnostics.

Housed in a 131 × 99 × 40 mm compact industrial chassis and certified for Australia (RCM) alongside CE and UKCA, the DWM-314-G is a dependable 5G/4G M2M foundation for critical business and public-infrastructure deployments. Australian stock from ARC IP Networks.

Brand D-LINK
Form Factor Industrial DIN-Rail / Wall Mount
Network Connectivity Wired + Cellular
LAN Ports 4 x GbE
Use Case M2M / Industrial / Outdoor
WAN Type 5G NR (SA + NSA) + 4G LTE Cat.19
SIM Slots Dual Micro-SIM (3FF) with auto-failover
VPN Support OpenVPN, WireGuard
Power Input DC 9–36 V (wide input)
Operating Temperature −30 to 70 °C
DWM-314-G_Datasheet.pdf
