Ubiquiti USW-WAN UniFi 10G SFP+ WAN Switch linking two Shadow Mode High Availability UniFi Gateways to a single ISP

Price:

477.51


Ubiquiti USW-Ultra-60W Unifi Switch
Ubiquiti USW-Ultra-60W Unifi Switch
257.50
263.45 (2% OFF)
Ubiquiti USW-WAN-RJ45 UniFi 10GbE WAN Switch linking two Shadow Mode High Availability UniFi Gateways to a single ISP
Ubiquiti USW-WAN-RJ45 UniFi 10GbE WAN Switch linking two Shadow Mode High Availability UniFi Gateways to a single ISP
477.51
487.30 (2% OFF)

Ubiquiti USW-WAN UniFi 10G SFP+ WAN Switch linking two Shadow Mode High Availability UniFi Gateways to a single ISP

https://arcip.com.au/web/image/product.template/4061/image_1920?unique=d79c493
The Ubiquiti USW-WAN is a Layer 2 managed switch with (1) GbE + (3) 10G SFP+. 10G SFP+ WAN Switch linking two Shadow Mode High Availability UniFi Gateways to a single ISP.

477.51 477.51 AUD 487.30 incl. GST

Not Available For Sale


  • Brand
  • Switching Capacity
  • Network Layer
  • Form Factor
  • Port Speed
  • Ports
  • Network Connectivity
  • Uplink
  • PoE Specification
  • Switch Features

This combination does not exist.

10GbE UniFi Switch Rackmount SFP+ Managed Switch Ubiquiti 4-Port 20 Gbps
UBIQUITI
UBIQUITI

Ubiquiti Inc. offers a wide range of networking solutions for service providers and enterprises, including fixed wireless broadband, wireless backhaul, routing, LAN infrastructure, and video surveillance. The company stands out through its proprietary software, advanced firmware, and innovative hardware design.

  • Stock

    Authorised Australian Reseller | Australian Stock | Genuine Local Warranty

  • Instalment
    Buy Now, Pay Later
  • [Warranty Information] Warranty
    Manufacturer Warranty
Estimate delivery
Shipping calculated at checkout
Estimate delivery times: 3-7 business days
Guaranteed Safe Checkout
Guaranteed Safe Checkout
SKU
USW-WAN
Barcode
810084699928
Tags
USW-WAN
Ubiquiti UniFi UniFi WAN Switch — 20 Gbps Switching
USW-WAN
USW-WAN

Features

  • Combine with Shadow Mode High Availability to ensure uninterrupted connectivity
  • (1) 10G SFP+ ISP uplink and (2) 10G SFP+ downlink ports
  • (2) AC inputs for power redundancy
  • (1) GbE port for management with UniFi Network
  • *Use an additional USW-WAN switch for ISP failover deployments.

Specifications

Overview
Dimensions442.4 x 120 x 43.7 mm
1 GbE RJ451 / (1G/100M/10M)
10G SFP+3 / (10G/1G)
Redundancy(2) AC inputs
Form FactorRack mount (1U)
Performance
Switching Capacity20 Gbps
Total Non-Blocking Throughput10 Gbps
Forwarding Rate15 Mpps
Hardware
Max. Power Consumption13W
Power Method(2) Universal input, 100–240V AC, 50/60 Hz
Power Input MethodAC input
Power Supply(2) AC/DC, internal, 36W
Supported Voltage Range100–240V AC
ManagementEthernet
WeightWithout mounting brackets: 2.2 kg / With mounting brackets: 2.3 kg
Enclosure MaterialSGCC steel
Mount MaterialSGCC steel
ESD ProtectionAir: ± 16kV, contact: ± 22kV
Ambient Operating Temperature-5 to 40° C (23 to 104° F)
Ambient Operating Humidity10 to 90% noncondensing
CertificationsCE, FCC, IC, Anatel: 03715-25-08356
Software
UniFi NetworkVersion 9.1.119 and later

Professional Overview

The Ubiquiti USW-WAN is a Layer 2 managed switch with (1) GbE + (3) 10G SFP+. 10G SFP+ WAN Switch linking two Shadow Mode High Availability UniFi Gateways to a single ISP.

With 20 Gbps switching capacity and 10 Gbps non-blocking throughput at 15 Mpps forwarding rate, the switch delivers wire-speed performance for demanding network environments.

The USW-WAN features (2) AC inputs redundancy, a Rack mount (1U) form factor measuring 442.4 x 120 x 43.7 mm. It integrates with the UniFi Network ecosystem for centralised management, VLAN configuration, and traffic monitoring.

Weighing Without mounting brackets: 2.2 kg / With mounting brackets: 2.3 kg, the USW-WAN is engineered for reliable 24/7 operation. Australian stock, fast shipping from ARC IP Networks.

Brand UBIQUITI
Switching Capacity 20 Gbps
Network Layer Layer 2
Form Factor Rack mount (1U)
Port Speed (1) GbE + (3) 10G SFP+
Ports 4 Ports
Network Connectivity Wired
Uplink 3 10G SFP+
PoE Specification Non-PoE
Switch Features (2) AC inputs
