Ubiquiti USW-WAN-RJ45 UniFi 10GbE WAN Switch linking two Shadow Mode High Availability UniFi Gateways to a single ISP

https://arcip.com.au/web/image/product.template/4062/image_1920?unique=35ef4ca
The Ubiquiti USW-WAN-RJ45 is a 10GbE WAN aggregation switch designed to ensure maximum network uptime. It enables High Availability for your UniFi network by linking two gateways in Shadow Mode to a single ISP connection for seamless failover.

487.30 487.3 AUD 487.30 incl. GST

Not Available For Sale


  • Brand

This combination does not exist.

UniFi Ubiquiti
UBIQUITI
UBIQUITI

Ubiquiti Inc. offers a wide range of networking solutions for service providers and enterprises, including fixed wireless broadband, wireless backhaul, routing, LAN infrastructure, and video surveillance. The company stands out through its proprietary software, advanced firmware, and innovative hardware design.

  • Stock

    Authorised Australian Reseller | Australian Stock | Genuine Local Warranty

  • Instalment
    Buy Now, Pay Later
  • [Warranty Information] Warranty
    Manufacturer Warranty
Estimate delivery
Shipping calculated at checkout
Estimate delivery times: 3-7 business days
Guaranteed Safe Checkout
Guaranteed Safe Checkout
SKU
USW-WAN-RJ45
Tags
USW-WAN-RJ45
Ubiquiti USW-WAN-RJ45 UniFi 10GbE WAN Switch linking two Shadow Mode High Availability UniFi Gateways to a single ISP

Features

  • Enables UniFi Gateway High Availability in Shadow Mode
  • (3) 10GbE RJ45 ports and (1) 1G SFP port
  • Ideal for copper-based multi-gigabit ISP handoffs
  • Supports redundant WAN connections
  • Compact, desktop form factor
  • Flexible power options: 802.3af PoE or USB-C
  • Managed seamlessly by the UniFi Network application

Specifications

Network
Interfaces(3) 1/2.5/5/10G RJ45
(1) 1G SFP
Management InterfaceEthernet In-Band
General
Power Method802.3af PoE
USB Type C (5V/3A)
Max. Power Consumption10W
Enclosure MaterialPolycarbonate
Dimensions141.6 x 100 x 30 mm (approx.)
Weight400 g (approx.)

Professional Overview

The Ubiquiti UniFi Switch WAN RJ45 (USW-WAN-RJ45) is a specialized, mission-critical Layer 2 switch designed to bring enterprise-level redundancy to your UniFi network. Its singular purpose is to enable UniFi Gateway High Availability (HA), effectively eliminating your primary internet gateway as a single point of failure. For any business, institution, or organization where continuous internet connectivity is non-negotiable, the USW-WAN-RJ45 is an essential investment in network resilience.

The USW-WAN-RJ45 works by facilitating UniFi's "Shadow Mode" for gateways. It acts as an intelligent bridge between your Internet Service Provider (ISP) and a pair of UniFi gateways. One gateway operates in an active state, handling all network traffic, while the second gateway runs in a passive, standby state, continuously mirroring the configuration of the primary. If the active gateway goes offline for any reason—be it a hardware failure, a firmware update issue, or manual reboot—the UniFi Network application instantly directs the USW-WAN-RJ45 to switch all traffic to the standby gateway, ensuring a seamless, near-instantaneous failover with minimal disruption to your users.

Engineered for high-speed performance, this switch features three 10GbE RJ45 ports: one for the primary ISP connection and two for connecting to your gateways. This makes it the ideal solution for modern copper-based multi-gigabit internet services. It also includes a 1G SFP port for a secondary ISP connection or an alternative fiber link, providing flexible connectivity options. Its compact, desktop form factor and versatile power options—either 802.3af PoE or a standard USB-C connection—allow for discreet and convenient placement in any network closet.

As a native component of the UniFi ecosystem, the USW-WAN-RJ45 is seamlessly adopted and managed within the UniFi Network application. This makes the entire high-availability setup process remarkably simple and intuitive. By providing a low-cost insurance policy against internet downtime, the UniFi Switch WAN RJ45 transforms your UniFi network into a truly fault-tolerant, enterprise-class system.

Brand UBIQUITI
