Ubiquiti UBB Unifi Building to Building Bridge

https://arcip.com.au/web/image/product.template/3943/image_1920?unique=13c12ef
The Ubiquiti UBB is a WiFi 5 single-band access point with 2 spatial streams, covering 500 m (1,640 ft). 60 GHz wireless point-to-point bridge with a 5 GHz backup radio.

910.01 910.01 AUD 957.00 incl. GST

Not Available For Sale


  • Brand
  • Form Factor
  • WiFi Standard
  • Frequency Band
  • Max Throughput
  • PoE Requirement
  • Coverage Area
  • AP Features

This combination does not exist.

In stock online
Indoor UniFi Access Point PoE Ubiquiti Ceiling Mount MU-MIMO WiFi 5
UBIQUITI
UBIQUITI

Ubiquiti Inc. offers a wide range of networking solutions for service providers and enterprises, including fixed wireless broadband, wireless backhaul, routing, LAN infrastructure, and video surveillance. The company stands out through its proprietary software, advanced firmware, and innovative hardware design.

  • Stock

    Authorised Australian Reseller | Australian Stock | Genuine Local Warranty

  • Instalment
    Buy Now, Pay Later
  • [Warranty Information] Warranty
    Manufacturer Warranty
Estimate delivery
Shipping calculated at checkout
Estimate delivery times: 3-7 business days
Guaranteed Safe Checkout
Guaranteed Safe Checkout
SKU
UBB
Barcode
817882029582
Tags
UBB
Ubiquiti UniFi Building-to-Building Bridge — WiFi 5 Access Point
UBB
UBB

Features

  • 500 m (1,640 ft) maximum range
  • 60 GHz & 5 GHz dual-radio redundancy
  • Includes PoE power adapters
  • Built-in LED alignment indicators

Specifications

Overview
Dimensions⌀140 x 90 mm
WiFi StandardWiFi 5
Spatial Streams2
Coverage Area500 m (1,640 ft)
Mounting LocationsWall, pole
WeatherproofingIPX6
Power MethodPoE
Performance
5 GHz2 x 2 (DL MU-MIMO)
60 GHz1.7 Gbps
5 GHz866.6 Mbps (BW80)
60 GHz17.2 dBi
5 GHz10 dBi
2.4 GHz2 dBi (BLE)
60 GHz19 dBm
5 GHz25 dBm
802.11ac (WiFi 5)6.5 Mbps to 867 Mbps (MCS0 - MCS9 NSS1/2, VHT 20/40/80)
802.11n6.5 Mbps to 300 Mbps (MCS0 - MCS15, HT 20/40)
802.11g6, 9, 12, 18, 24, 36, 48, 54 Mbps
802.11b1, 2, 5.5, 11 Mbps
802.11a6, 9, 12, 18, 24, 36, 48, 54 Mbps
Wireless SecurityWPA2 AES
Hardware
Max. Power Consumption11W
Supported Voltage Range44–57V DC
Networking Interface(1) GbE RJ45 port
Weight376 g (13.3 oz)
Operating ModesPtP
Wind Loading56 N at 200 km/h
ManagementEthernet / Bluetooth
Channel BandwidthMain radio (60 GHz): 1,080/2,160 MHz / Backup radio (5 GHz): HT 20/40 MHz, VHT 20/40/80 MHz
Enclosure MaterialUV-resistant polycarbonate
Button(1) Factory reset
SystemR/G/B
Operating FrequencyMain radio (60 GHz): 57 - 66 GHz / Backup radio (5 GHz): / US/CA / U-NII-1: 5150 - 5250 MHz / U-NII-2A: 5250 - 5350 MHz / U-NII-2C: 5470 - 5725 MHz / U-NII-3: 5725 - 5850 MHz / / Worldwide / 5150 - 5850 MHz
Bluetooth (MHz)Worldwide: 2400 - 2483.5 MHz
Ambient Operating Temperature-40 to 70° C (-40 to 158° F)
Ambient Operating Humidity5 to 95% noncondensing
CertificationsCE, FCC, IC

Professional Overview

The Ubiquiti UBB is a WiFi 5 access point with 2 spatial streams, designed for 500 m (1,640 ft) coverage. 60 GHz wireless point-to-point bridge with a 5 GHz backup radio.

On 5 GHz, the UBB delivers 866.6 Mbps (BW80).

The UBB features a uplink and is powered via PoE. It integrates seamlessly with the UniFi Network ecosystem for centralised management, zero-touch provisioning, and seamless roaming.

Weighing 376 g (13.3 oz) with dimensions of ⌀140 x 90 mm, the UBB is built for reliable 24/7 operation. Australian stock, fast shipping from ARC IP Networks.

Ubiquiti UBB: WiFi 5 access point

The Building-to-Building Bridge is a UniFi WiFi 5 access point with 2 spatial streams and a rated coverage area of 500 m (1,640 ft).

On the wired side it is powered by PoE, and draws at most 11W.

It carries a IPX6 rating, so unlike an ordinary indoor AP it can be mounted outside under normal Australian conditions. Read the rating literally: it covers water, not immersion, and it is not a reason to site the unit where it will sit in standing water.

Radios and throughput

BandMIMOMax. throughputAntenna gainMax. TX power
60 GHz1.7 Gbps17.2 dBi19 dBm
5 GHz2 x 2 (DL MU-MIMO)866.6 Mbps (BW80)10 dBi25 dBm
2.4 GHz2 dBi (BLE)
Spatial streams2
WiFi standardWiFi 5
Channel bandwidthMain radio (60 GHz): 1,080/2,160 MHz Backup radio (5 GHz): HT 20/40 MHz, VHT 20/40/80 MHz

Supported data rates

802.11ac (WiFi 5)6.5 Mbps to 867 Mbps (MCS0 - MCS9 NSS1/2, VHT 20/40/80)
802.11n6.5 Mbps to 300 Mbps (MCS0 - MCS15, HT 20/40)

These are modulation-coding-scheme ceilings measured at the radio, not speeds a client will see. Real throughput depends on the client's own radio, the channel width you can actually use, distance and how much of the band your neighbours are already occupying. Our UniFi access point comparison puts the range side by side.

Uplink and power

Networking interface(1) GbE RJ45 port
Power methodPoE
Max. power consumption11W
Supported voltage range44–57V DC
ManagementEthernet Bluetooth

Power comes down the Ethernet run as PoE, drawing up to 11W. On a switch that shares one PoE budget across every port, add up the draw of every AP before you commit — the UniFi switch range lists the total availability for each model.

Sold and deployed as a pair — a link needs a unit at each end.

Who the UBB suits

  • Building-to-building links where trenching fibre is impractical
  • Campuses, farms and multi-shed sites needing a gigabit-class hop
  • Temporary or leased sites where cabling cannot be installed
  • Links with clear line of sight between the two mounting points

Physical and mounting

Dimensions⌀140 x 90 mm (⌀5.5 x 3.5")
Weight376 g (13.3 oz)
WeatherproofingIPX6
Wind loading56 N at 200 km/h (12.6 lbf at 125 mph)
Enclosure materialUV-resistant polycarbonate
Status LEDR/G/B
Operating temperature-40 to 70° C (-40 to 158° F)
Operating humidity5 to 95% noncondensing
CertificationsCE, FCC, IC

Rated for -40 to 70° C (-40 to 158° F). Worth checking against a roof space in an Australian summer, which routinely runs hotter than an occupied room.

Management and requirements

ManagementEthernet Bluetooth

Like every UniFi access point, the UBB is adopted and managed by a UniFi controller — a Cloud Gateway or Dream Machine, a Cloud Key, or UniFi hosting. The AP does not run the controller itself, and it is not a standalone router: it provides the WiFi, while routing, firewall and VLANs live on the gateway.

Frequently Asked Questions

What is the UBB?

The Building-to-Building Bridge is a UniFi WiFi 5 access point with 2 spatial streams and a rated coverage area of 500 m (1,640 ft).

What area does the UBB cover?

500 m (1,640 ft) is the published figure. Coverage in a real building depends on what the signal has to pass through: plasterboard costs little, double brick, foil-backed insulation and concrete cost a great deal.

How is the UBB powered?

PoE over the Ethernet run, drawing up to 11W, within a supported voltage range of 44–57V DC.

Can the UBB be used outdoors?

It is rated IPX6, so it is built for outdoor mounting. Treat the rating literally — it covers water, not immersion.

Does the UBB need a UniFi controller?

Yes. UniFi access points are adopted and managed by a controller — a Cloud Gateway, Dream Machine, Cloud Key or UniFi hosting. The AP supplies the WiFi; routing, firewall and VLANs live on the gateway.

Is the UBB available in Australia?

Yes. ARC IP Networks is an authorised Ubiquiti reseller holding Australian stock with full manufacturer warranty and fast domestic shipping.

ARC IP Networks, authorised Ubiquiti reseller in Australia — Australian stock, manufacturer warranty, fast shipping, trade pricing.
ARC IP Networks is an authorised Ubiquiti reseller in Australia — Australian stock, full manufacturer warranty, fast shipping and trade pricing. Call 1300 100 440 or read more about buying from an authorised reseller.

Buy the Ubiquiti UBB in Australia

ARC IP Networks is an authorised Ubiquiti reseller supplying the UBB from Australian stock, with full manufacturer warranty and fast shipping nationwide.

  • Authorised Ubiquiti reseller — genuine Australian stock, not grey import
  • Full manufacturer warranty with local RMA support
  • Competitive Australian pricing, monitored against the local market daily
  • Fast dispatch Australia-wide, or collect from our warehouse
  • Trade and project pricing for installers, MSPs and multi-site rollouts

Browse the full UniFi access point range, plus cloud gateways, switches and the Protect camera range. New to UniFi? Start with the complete UniFi buying guide, or compare the APs directly in our access point comparison. More on buying from an authorised Ubiquiti reseller in Australia.

Brand UBIQUITI
Form Factor Ceiling Mount
WiFi Standard WiFi 5 (802.11ac)
Frequency Band Single-Band (5 GHz)
Max Throughput 866.6 Mbps (BW80)
PoE Requirement PoE
Coverage Area 500 m (1,640 ft)
AP Features Mesh, Band Steering, MU-MIMO
