Ruijie RG-RAP62-Wall-Lite, Wi-Fi 6 AX3000 Dual-Band Wall-Plate Access Point

Price:

166.98


Ruijie RG-RAP62-Wall, Wi-Fi 6 AX3000 Dual-Band Wall-Plate Access Point with 4 x GbE and PoE Out
Ruijie RG-RAP62-Wall, Wi-Fi 6 AX3000 Dual-Band Wall-Plate Access Point with 4 x GbE and PoE Out
303.71
303.71

Ruijie RG-RAP62-Wall-Lite, Wi-Fi 6 AX3000 Dual-Band Wall-Plate Access Point

https://arcip.com.au/web/image/product.template/10370/image_1920?unique=97531d6
Ruijie Reyee RG-RAP62-Wall-Lite AX3000 Wi-Fi 6 wall-plate access point. 2401 Mbps on 5 GHz, 2 x Gigabit ports, 86x86mm square plate, only 24.8mm exposed, PoE powered. Australian stock from ARC IP Networks.

166.98 166.98 AUD 166.98 incl. GST

Not Available For Sale


  • Brand
  • Form Factor
  • Ports
  • Network Connectivity
  • PoE Specification
  • WiFi Standard
  • Frequency Band

This combination does not exist.

WiFi 6 Indoor Access Point Ruijie Cloud Managed Wall Mount WiFi Reyee
  • Stock

    Authorised Australian Reseller | Australian Stock | Genuine Local Warranty

  • Instalment
    Buy Now, Pay Later
  • [Warranty Information] Warranty
    Manufacturer Warranty
Estimate delivery
Shipping calculated at checkout
Estimate delivery times: 3-7 business days
Guaranteed Safe Checkout
Guaranteed Safe Checkout
SKU
RG-RAP62-WALL-LITE
Tags
RG-RAP62-Wall-Lite Wi-Fi 6 AX3000 Dual-Band Wall-Plate Access Point
Ruijie Reyee

Features

  • Wi-Fi 6 AX3000 speeds: Maximum 2401 Mbps in 5 GHz + Maximum 573 Mbps in 2.4 GHz
  • Compatible with 86-mm and EU standard junction boxes
  • Blending into the indoor environment
  • Thickness-segmented design, with only 24.8 mm (0.98 in.) exposed on the wall
  • Centralized management on Ruijie Cloud
Ruijie RG-RAP62-WALL-LITE product view 1
Ruijie RG-RAP62-WALL-LITE product view 2
Ruijie RG-RAP62-WALL-LITE product view 3

Specifications

Wi-Fi Radio
Standard802.11ax (Wi-Fi 6), AX3000
Radio DesignDual-radio, 4 spatial streams; 2.4 GHz 2x2 MU-MIMO, 5 GHz 2x2 MU-MIMO
Maximum Data Rate2,974 Mbps aggregate
5 GHz Data Rate2,401 Mbps
2.4 GHz Data Rate573 Mbps
Antennas1 built-in 5 GHz omnidirectional plus 2 built-in dual-band omnidirectional
Ports and Power
Ethernet Ports2 x 10/100/1000BASE-T
PoE InPoE / PoE+ (IEEE 802.3af/at)
PoE OutNot supported
Local Power SupplyNot supported — PoE only
Maximum Power Consumption11.2 W
Capacity
Maximum Associated Clients64 on 2.4 GHz, 256 on 5 GHz, 256 with both enabled
Devices Manageable in Self-Organising Mode300
Physical
Dimensions86 x 38 x 86 mm
Exposed Depth24.8 mm above the wall
Weight≤ 0.25 kg
Mounting86 mm and EU standard junction boxes
Operating Temperature0°C to +40°C

Professional Overview

The Ruijie RG-RAP62-Wall-Lite delivers the same AX3000 Wi-Fi 6 radio as the RAP62-Wall — 2,401 Mbps on 5 GHz and 573 Mbps on 2.4 GHz across a dual-radio 2x2 MU-MIMO design — in a smaller, cheaper 86 x 86 mm square faceplate with two Gigabit ports instead of five. It is the right choice wherever the room needs coverage and one wired port, not a switch.

The square 86 x 86 mm footprint fits 86 mm and EU standard junction boxes and matches the outline of the light switches and data plates already on the wall, which is why it is specified in refurbishments and in serviced apartments where a rectangular AP would look out of place. A thickness-segmented design puts only 24.8 mm of the body proud of the wall, so it sits close to flush and is hard to knock.

Client capacity is 64 on 2.4 GHz and 256 on 5 GHz, which suits per-room deployment where each AP serves a handful of devices at close range at full rate — the pattern that gives guests high throughput without the co-channel interference of corridor-mounted APs trying to cover through walls. In self-organising mode the AP can manage a network of up to 300 devices.

Power is PoE or PoE+ only, with an 11.2 W maximum draw and no DC input, so one Cat6 run per room is the whole installation. In Australia this is a 2.4/5 GHz dual-band access point and does not use the 6 GHz band. Ruijie Cloud management is included for the life of the product — zero-touch provisioning, remote monitoring, firmware management and configuration from the Ruijie Reyee app or a browser, at no subscription cost. Australian stock from ARC IP Networks.

Part of the Ruijie Reyee range at ARC IP Networks — an authorised Australian Ruijie reseller. Genuine Australian stock with the full manufacturer’s warranty, and free lifetime Ruijie Cloud management.
Ruijie Reyee Australia · Ruijie access points · Ruijie Cloud

RG-RAP62-WALL-LITE — frequently asked questions

How fast is the RG-RAP62-WALL-LITE?

The RG-RAP62-WALL-LITE is rated at 2974 Mbps aggregate — 2401 Mbps on 5 GHz, 573 Mbps on 2.4 GHz. These are manufacturer PHY maximums; real-world throughput depends on client capability, channel width and interference.

What is the operating temperature of the RG-RAP62-WALL-LITE?

The RG-RAP62-WALL-LITE is specified for 0°C to 40°C (32°F to 104°F). For hot roof spaces, unventilated cabinets or inland summer conditions, confirm the cabinet stays inside that range.

How is the RG-RAP62-WALL-LITE powered?

Maximum power consumption is 11.2 W, supplied via poe/poe+.

Does the RG-RAP62-WALL-LITE need a licence or a controller?

No. Ruijie Cloud management is included free for the life of the hardware — there is no subscription, no per-device licence and no controller appliance to buy. See our Ruijie Cloud guide.

Where can I buy the RG-RAP62-WALL-LITE in Australia?

From ARC IP Networks. We are an authorised Australian Ruijie reseller and hold the access point range as genuine Australian stock with the full manufacturer’s warranty — not grey import. Browse the Ruijie access point range.

Brand Ruijie
Form Factor Wall Plate
Ports 2 Ports
Network Connectivity Wi-Fi 6
PoE Specification PoE-in 802.3af/at
WiFi Standard 802.11ax (WiFi 6)
Frequency Band Dual-Band (2.4 + 5 GHz)
