Cisco ANT-7-5G4WL2G1-O= 7-in-1 Outdoor Antenna, 4x 5G/LTE, 2x Wi-Fi, 1x GNSS, IP67

Price:

$ 1,742.28


Cisco ANT-5G-OMNI-OUT-N= Outdoor Omnidirectional 4G LTE / 5G FR1 Antenna, 617-7125 MHz, N-Type, IP67
Cisco ANT-5G-OMNI-OUT-N= Outdoor Omnidirectional 4G LTE / 5G FR1 Antenna, 617-7125 MHz, N-Type, IP67
$ 316.78
$ 316.78
Cisco ANT-GNSS-OUT-TNC= Outdoor Active GNSS Antenna, GPS/GLONASS/BeiDou, 30 dB LNA, TNC Male, IP67
Cisco ANT-GNSS-OUT-TNC= Outdoor Active GNSS Antenna, GPS/GLONASS/BeiDou, 30 dB LNA, TNC Male, IP67
$ 437.36
$ 437.36

Cisco ANT-7-5G4WL2G1-O= 7-in-1 Outdoor Antenna, 4x 5G/LTE, 2x Wi-Fi, 1x GNSS, IP67

https://arcip.com.au/web/image/product.template/11713/image_1920?unique=f69e2bd

Cisco ANT-7-5G4WL2G1-O= multi-element 7-in-1 LTE/5G, Wi-Fi and GNSS antenna. Four cellular elements 617-960 and 1710-5925 MHz (avg peak 2.1/5.3 dBi), two Wi-Fi elements 2.4 and 5 GHz (5.8/5.5 dBi), one GNSS element. 0.6m RG-316 cables with SMA and RP-SMA plugs, 5.2m RG-174 GNSS cable. 275.3x123.3x92.3mm, IP67, -40 to +85°C. Roof mount on vehicles or fixed structures. Genuine Cisco from ARC IP Networks, a Cisco Registered Partner.

$ 1,742.28 1742.28 AUD $ 1,742.28 incl. GST

Not Available For Sale


  • Brand

This combination does not exist.

  • Stock

    Authorised Australian Reseller | Australian Stock | Genuine Local Warranty

  • Instalment
    Buy Now, Pay Later
  • [Warranty Information] Warranty
    Manufacturer Warranty
Estimate delivery
Shipping calculated at checkout
Estimate delivery times: 3-7 business days
Guaranteed Safe Checkout
Guaranteed Safe Checkout
Accepted payments: Google Pay, Apple Pay, Visa, Mastercard and PayPal
SKU
ANT-7-5G4WL2G1-O=

Cisco ANT-7-5G4WL2G1-O= at a glance

The Cisco ANT-7-5G4WL2G1-O= is a 7-in-1 roof-mount antenna for vehicles or fixed structures with four cellular (4G/5G) elements covering 617-960 and 1710-5925 MHz, two Wi-Fi elements for 2.4 and 5 GHz and one active GNSS element. It is IP67 rated, operates from -40 to +85°C and mounts through a 27.0mm hole.

ARC IP Networks is a Cisco Registered Partner in Australia. We supply the genuine Cisco ANT-7-5G4WL2G1-O= through Cisco's authorised Australian distribution, with a GST tax invoice on every order.

Elements4x 5G/LTE, 2x Wi-Fi, 1x GNSS
Peak gainLTE 5.3 dBi, Wi-Fi 5.8 dBi
RatingIP67, -40 to +85°C
MountRoof, 27.0mm hole

Best for

  • Transit vehicles needing 5G, passenger Wi-Fi and GNSS
  • Fixed outdoor kiosks or cabinets with 5G routers
  • Single-penetration installs replacing several antennas

Key features

Seven elements: four cellular (4G/5G), two Wi-Fi and one GNSS.

LTE/5G 617-960 and 1710-5925 MHz, including Band 71; average peak gain 2.1/5.3 dBi.

Wi-Fi 2400-2500 and 4900-5925 MHz; average peak gain 5.8/5.5 dBi.

GNSS 1561.098, 1575.42 and 1602.5625 MHz; noise figure < 2.4dB, 3.3-5 Vdc.

LTE cables 0.6m RG-316 with SMA plugs; Wi-Fi 0.6m RG-316 with reverse polarity SMA plugs.

GNSS cable 5.2m RG-174 with SMA plug.

IP67 UV-stable rugged thermoplastic housing; -40 to +85°C.

Roof mount through a 27.0mm hole; 275.3x123.3x92.3mm.

Cisco ANT-7-5G4WL2G1-O= specifications

Cisco ANT-7-5G4WL2G1-O= technical specifications
SpecificationValue
Cellular
Frequency617-960 / 1710-5925 MHz
Average peak gain2.1 / 5.3 dBi
Connector / cableSMA plug, 0.6m RG-316
Wi-Fi
Frequency2400-2500 / 4900-5925 MHz
Average peak gain5.8 / 5.5 dBi
Connector / cableReverse polarity SMA plug, 0.6m RG-316
GNSS
Bands1561.098, 1575.42, 1602.5625 MHz
Noise figure< 2.4dB
Supply3.3-5 Vdc, < 11 mA
Connector / cableSMA plug, 5.2m RG-174
Mechanical and environment
Dimensions (L x W x H)275.3x123.3x92.3mm
Mounting hole27.0mm
IngressIP67
Temperature-40 to +85°C
VSWR (LTE/Wi-Fi)3:1 / 2.5:1

Figures from Cisco's official data sheet.

The Cisco ANT-7-5G4WL2G1-O= in depth

5G, Wi-Fi and GNSS together

The ANT-7-5G4WL2G1-O= combines 4x4 cellular for 4G/5G, 2x2 Wi-Fi and GNSS in a single monopole antenna with built-in ground plane. Cisco states it meets or exceeds a variety of environmental ruggedisation specifications for transportation applications.

Installation

Mount it on the roof of a vehicle or fixed structure through a 27.0mm hole using an open-ended wrench and drill. LTE and Wi-Fi cables are 0.6m; the GNSS cable is 5.2m.

Frequently asked questions

Straight answers about the Cisco ANT-7-5G4WL2G1-O= from the ARC IP Networks team. Last reviewed October 2026.

Four cellular (4G/5G) elements, two Wi-Fi elements and one GNSS element.

SMA plug (male) for LTE and GNSS, and reverse polarity SMA plug (male) for Wi-Fi.

Yes. The LTE/5G range is 617-960 and 1710-5925 MHz, including Band 71 (617-698 MHz).

Outdoor IP67, -40 to +85°C, tested to industrial, vehicular and transportation standards.

ARC IP Networks is a Cisco Registered Partner and supplies the genuine Cisco ANT-7-5G4WL2G1-O= through Cisco's authorised Australian distribution, with a GST tax invoice.

Explore the full Cisco range: Cisco Australia hub · Shop all Cisco

Buy the Cisco ANT-7-5G4WL2G1-O= in Australia

ARC IP Networks is a Cisco Registered Partner, supplying Cisco switching, wireless, collaboration and security products to businesses, schools and integrators across Australia.

  • Genuine Cisco: sourced through Cisco's authorised Australian distribution, never grey import.
  • Australia-wide delivery, with Australian power where a power supply is included.
  • Manufacturer's warranty and local pre-sales help choosing the right model and licence.
