Cisco ANT-GNSS-OUT-TNC= Outdoor Active GNSS Antenna, GPS/GLONASS/BeiDou, 30 dB LNA, TNC Male, IP67

https://arcip.com.au/web/image/product.template/11714/image_1920?unique=f69e2bd

Cisco ANT-GNSS-OUT-TNC= outdoor active GNSS patch antenna for GPS, GLONASS and BeiDou, 1560 to 1606 MHz, for timing and location-based services. 30dB LNA gain, 1dBic gain, RHCP, under 10mA. Integrated 4572 mm LMR-100 cable with TNC male connector. Grey polycarbonate, IP66 and IP67, -40 to 85° C. Includes pole mount bracket and U bolt. Genuine Cisco from ARC IP Networks, a Cisco Registered Partner.

$ 437.36 437.36 AUD $ 437.36 incl. GST

Not Available For Sale


  • Brand

This combination does not exist.

  • Stock

    Authorised Australian Reseller | Australian Stock | Genuine Local Warranty

  • Instalment
    Buy Now, Pay Later
  • [Warranty Information] Warranty
    Manufacturer Warranty
Estimate delivery
Shipping calculated at checkout
Estimate delivery times: 3-7 business days
Guaranteed Safe Checkout
Guaranteed Safe Checkout
Accepted payments: Google Pay, Apple Pay, Visa, Mastercard and PayPal
SKU
ANT-GNSS-OUT-TNC=

Cisco ANT-GNSS-OUT-TNC= at a glance

The Cisco ANT-GNSS-OUT-TNC= is an outdoor active patch antenna covering 1560 to 1606 MHz for GPS, GLONASS and BeiDou, used for timing and location services. It has a 30 dB LNA, draws under 10 mA, comes with a 4572 mm LMR-100 cable ending in a TNC male connector, includes a pole mount bracket and U-bolt, and is rated IP66 and IP67.

ARC IP Networks is a Cisco Registered Partner in Australia. We supply the genuine Cisco ANT-GNSS-OUT-TNC= through Cisco's authorised Australian distribution, with a GST tax invoice on every order.

SystemsGPS, GLONASS, BeiDou
LNA gain30 dB ± 2 dB
ConnectorTNC male, 4572 mm cable
RatingIP66 and IP67

Best for

  • Timing reference for Cisco routers and grid equipment
  • Location-based services on fixed sites
  • Multi-constellation GNSS reception outdoors

Key features

Covers 1560 to 1606 MHz: 1561.1, 1575.42 and 1602.6 MHz bands.

Supports GPS, GLONASS and BeiDou; active antenna for timing and location services.

30dB ± 2dB LNA gain; antenna gain 1dBic ± 1dB, RHCP.

Current consumption under 10mA.

Integrated LMR-100 cable, 4572 mm, VW-1/FT-1 flame rating, with TNC male connector.

Grey polycarbonate housing rated IP66 and IP67.

Operating and storage temperature -40 to 85° C.

Package includes the antenna, a pole mount bracket and a U bolt.

Cisco ANT-GNSS-OUT-TNC= specifications

Cisco ANT-GNSS-OUT-TNC= technical specifications
SpecificationValue
RF
Frequency1561.1 ± 2.1, 1575.42 ± 1.023, 1602.6 ± 4.0 MHz
TypePatch, active
Gain1dBic ± 1dB
LNA gain30dB ± 2dB
PolarisationRHCP
Impedance50 Ω
Electrical and cable
Current<10mA
CableLMR-100, 4572 mm, VW-1/FT-1
ConnectorTNC male
Mechanical and environment
HousingGrey polycarbonate
IngressIP66 and IP67
Temperature-40 to 85° C
MountingPole mount bracket with U bolt (included)

Figures from Cisco's official data sheet.

The Cisco ANT-GNSS-OUT-TNC= in depth

Multi-constellation timing

The ANT-GNSS-OUT-TNC= receives GPS, GLONASS and BeiDou across 1560 to 1606 MHz, giving Cisco equipment an outdoor reference for precise timing and location-based services.

Ready to mount

It ships with a pole mount bracket and U-bolt, and a 4572 mm flame-rated LMR-100 cable ending in a TNC male connector.

Frequently asked questions

Straight answers about the Cisco ANT-GNSS-OUT-TNC= from the ARC IP Networks team. Last reviewed October 2026.

GPS, GLONASS and BeiDou, across 1560 to 1606 MHz.

An integrated 4572 mm LMR-100 cable with a TNC male connector.

Yes. The package includes the antenna, a pole mount bracket and a U bolt.

ANT-GNSS-OUT-TNC= covers GPS, GLONASS and BeiDou across 1560 to 1606 MHz with a 30 dB LNA; ANT-GPS-OUT-TNC is Cisco's GPS-only outdoor antenna.

ARC IP Networks is a Cisco Registered Partner and supplies the genuine Cisco ANT-GNSS-OUT-TNC= through Cisco's authorised Australian distribution, with a GST tax invoice.
