Ubiquiti UACC-Cable-DoorLockRelay-1P UniFi Access Door Lock Relay Cable 152.4m

Price:

$ 226.70


Ubiquiti UACC-PSU-12V-150W Hot-Swappable Power Module 150W 12V
Ubiquiti UACC-PSU-12V-150W Hot-Swappable Power Module 150W 12V
$ 237.59
$ 256.30 (7% OFF)
Ubiquiti UA-Reader Lite UniFi Access Reader Lite NFC and Handwave Unlock
Ubiquiti UA-Reader Lite UniFi Access Reader Lite NFC and Handwave Unlock
$ 205.82
$ 222.20 (7% OFF)

Ubiquiti UACC-Cable-DoorLockRelay-1P UniFi Access Door Lock Relay Cable 152.4m

https://arcip.com.au/web/image/product.template/10130/image_1920?unique=c58e5fc
The Ubiquiti UACC-Cable-DoorLockRelay-1P is a 152.4 m spool of one-pair low-voltage cable for connecting an electric or magnetic lock to a UniFi Access Hub. It carries two 18 AWG solid bare copper conductors under a thermoplastic elastomer (TPE) jacket, and weighs 4.58 kg. The two-pair version, UACC-Cable-DoorLockRelay-2P, adds two 22 AWG conductors for a door position sensor and is the option to choose if the door needs position sensing as well as lock control.

$ 226.70 226.7 AUD $ 250.80 incl. GST

Not Available For Sale


  • Brand
  • Length
  • Colour
  • Connector Type
  • Cable Category
  • Conductor

This combination does not exist.

UniFi Ubiquiti Door Access UniFi Access Bulk Cable
UBIQUITI
UBIQUITI

Ubiquiti Inc. offers a wide range of networking solutions for service providers and enterprises, including fixed wireless broadband, wireless backhaul, routing, LAN infrastructure, and video surveillance. The company stands out through its proprietary software, advanced firmware, and innovative hardware design.

  • Stock

    Authorised Australian Reseller | Australian Stock | Genuine Local Warranty

  • Instalment
    Buy Now, Pay Later
  • [Warranty Information] Warranty
    Manufacturer Warranty
Estimate delivery
Shipping calculated at checkout
Estimate delivery times: 3-7 business days
Guaranteed Safe Checkout
Guaranteed Safe Checkout
Accepted payments: Google Pay, Apple Pay, Visa, Mastercard and PayPal
SKU
UACC-Cable-DoorLockRelay-1P
Barcode
810084691632
Tags

Ubiquiti UACC-Cable-DoorLockRelay-1P at a glance

The Ubiquiti UACC-Cable-DoorLockRelay-1P (Door Lock Relay Cable, 1-pair) is a 152.4 m (500 ft) spool of low-voltage cable that connects an electric/magnetic lock to an Access Hub. It has (2) 18 AWG solid bare copper conductors, a white TPE jacket and a VW-1 flame rating.

ARC IP Networks is an authorised Ubiquiti reseller in Australia. We supply the genuine Door Lock Relay Cable (1-pair) from Australian stock with the full manufacturer's warranty.

Length152.4 m (500 ft)
Conductors2 x 18 AWG
Current rating2A (18AWG, 500 ft)
JacketWhite TPE
Flame ratingVW-1
Operating temp-45 to 65° C

Best for

  • Wiring an electric/magnetic lock to an Access Hub
  • Low-voltage door access runs on a 152.4 m spool

Consider instead

Key features

1-Pair Relay Cable: Connects an electric/magnetic lock to an Access Hub

2-Pair Relay Cable: Connects an electric/magnetic lock and door position sensor to an Access Hub

1-Pair Relay Cable:

— (2) 18 AWG conductors for an electric/magnetic lock

2-Pair Relay Cable:

— (2) 18 AWG conductors for an electric/magnetic lock

— (2) 22 AWG conductors for a door position sensor

Cable length 152.4 m

Ubiquiti UACC-Cable-DoorLockRelay-1P specifications

Overview

Length152.4 m (500 ft)
MaterialConductor: Solid bare copper / Jacket: Thermoplastic elastomer (TPE) / Insulation: Semi-rigid polyvinyl chloride (SR-PVC)
InsulationUACC-Cable-DoorLockRelay-2P: black/red (18AWG), amber/white (22AWG) / UACC-Cable-DoorLockRelay-1P: black/red (18AWG)
Current Rating18AWG: 2A for 500 ft length / 22AWG: 1A for 500 ft length
Flame RatingVW-1
Conductor Wire GaugeUACC-Cable-DoorLockRelay-2P: 18/22 AWG / UACC-Cable-DoorLockRelay-1P: 18 AWG
WeightUACC-Cable-DoorLockRelay-2P: 5.6 kg (12.3 lb) / UACC-Cable-DoorLockRelay-1P: 4.58 kg (10.1 lb)
Jacket Outer DiameterUACC-Cable-DoorLockRelay-2P: 4.5 mm (0.18") / UACC-Cable-DoorLockRelay-1P: 4.2 mm (0.17")
Jacket ColorWhite
Bend RadiusUACC-Cable-DoorLockRelay-2P: 56 mm (2.2") / UACC-Cable-DoorLockRelay-1P: 33 mm (1.3")
Pulling TensionUACC-Cable-DoorLockRelay-2P: 24.2 kgf / UACC-Cable-DoorLockRelay-1P: 16.4 kgf
Conductor DCRUACC-Cable-DoorLockRelay-2P: 23.2 ohm/km (18AWG), 59.4 ohm/km (22AWG) / UACC-Cable-DoorLockRelay-1P: 23.2 ohm/km (18AWG)
Supported Voltage Range36V DC
Number of ConductorsUACC-Cable-DoorLockRelay-2P: 4 / UACC-Cable-DoorLockRelay-1P: 2
Ambient Storage Temperature-45 to 65° C (-49 to 149° F)
Ambient Operating Temperature-45 to 65° C (-49 to 149° F)

Specifications from Ubiquiti's official product data for the UACC-Cable-DoorLockRelay, checked October 2026.

The Door Lock Relay Cable (1-pair) in depth

Relay cable for an electric or magnetic lock

The UACC-Cable-DoorLockRelay-1P is the 1-pair version of the Door Lock Relay Cable, supplied as a 500-foot (152.4 m) spool of low-voltage cable. It connects an electric/magnetic lock to an Access Hub using (2) 18 AWG conductors, with black/red insulation.

Construction and ratings

The conductors are solid bare copper, with semi-rigid PVC (SR-PVC) insulation and a thermoplastic elastomer (TPE) white jacket. The 18AWG conductors are rated at 2A for a 500 ft length, with a supported voltage range of 36V DC and a conductor DCR of 23.2 ohm/km. The cable carries a VW-1 flame rating and is specified for operation and storage from -45 to 65° C.

Size and handling

The 1-pair cable has a jacket outer diameter of 4.2 mm, a bend radius of 33 mm and a pulling tension of 16.4 kgf. The spool weighs 4.58 kg. If you also need to connect a door position sensor, the 2-pair version adds (2) 22 AWG conductors for that purpose.

Frequently asked questions

Straight answers about the Door Lock Relay Cable (1-pair) from the ARC IP Networks team. Last reviewed October 2026.

It is a 152.4 m (500 ft) spool of 1-pair, low-voltage Door Lock Relay Cable with (2) 18 AWG conductors. It connects an electric/magnetic lock to an Access Hub.

The 1-pair cable has 2 conductors (18 AWG) for an electric/magnetic lock. The 2-pair cable has 4 conductors, adding (2) 22 AWG conductors for a door position sensor.

The 18AWG conductors are rated at 2A for a 500 ft length. The supported voltage range is 36V DC.

The conductor is solid bare copper, the insulation is semi-rigid PVC (black/red for 18AWG) and the jacket is white thermoplastic elastomer (TPE).

Both ambient operating and storage temperature are -45 to 65° C (-49 to 149° F).

ARC IP Networks is an authorised Ubiquiti reseller and supplies the UACC-Cable-DoorLockRelay-1P from Australian stock with the full manufacturer's warranty.

Related Ubiquiti products

Ubiquiti UACC-Lock-Strike-Secure-15mm

UniFi Access Electric Lock (UA-Lock-Electric)

Ubiquiti UACC-Lock-Strike-Safe-15mm

UniFi Access Fail-Safe Electric Strike Lock 15mm

Ubiquiti UACC-Lock-Bolt-Secure

Access Fail-Secure Bolt Lock

Ubiquiti UACC-Junction-Utility

Access Junction Utility

Browse the full range: Ubiquiti accessories · Why buy Ubiquiti from ARC IP Networks

Buy the Ubiquiti UACC-Cable-DoorLockRelay-1P in Australia

ARC IP Networks is an authorised Ubiquiti reseller supplying UniFi networking, WiFi, camera and access products to businesses, schools, MSPs and installers across Australia.

  • Genuine Ubiquiti: sourced through Ubiquiti's authorised Australian distribution.
  • Australian stock with the correct AU power supply where one is included.
  • Full manufacturer's warranty and local pre-sales and after-sales support.
  • Trade and project pricing available.

ARC IP Networks, authorised Ubiquiti reseller in Australia — Australian stock, manufacturer warranty, fast shipping, trade pricing.

Wiring a lock to your Access Hub with the Door Lock Relay Cable?

Ask ARC IP Networks for project pricing or a configured quote, or call us to check the right model for your site.

Brand UBIQUITI
Length 152.4 m
Colour Black
Connector Type Unterminated (Bulk Cable)
Cable Category Low-Voltage Lock Cable
Conductor 18 AWG Solid Bare Copper
