TP-Link TL-SF1016DS 16-Port 10/100Mbps Desktop/Rackmount Switch

https://arcip.com.au/web/image/product.template/11298/image_1920?unique=6fa8c04

The TP-Link TL-SF1016DS is a 16-port 10/100 Mbps desktop/rackmount switch in a 13-inch steel case. All 16 RJ45 ports support auto-negotiation and auto MDI/MDIX for plug-and-play setup, and non-blocking store-and-forward switching delivers 3.2 Gbps switching capacity and a 2.38 Mpps forwarding rate with an 8K MAC address table. It is fanless, uses an internal 100-240 V power supply with a maximum draw of 2.06 W, and includes a rackmount kit and rubber feet. Supplied by ARC IP Networks from Australian stock with the full manufacturer's warranty.

$ 100.64 100.64 AUD $ 100.64 incl. GST

Not Available For Sale


  • Brand

This combination does not exist.

  • Stock

    Authorised Australian Reseller | Australian Stock | Genuine Local Warranty

  • Instalment
    Buy Now, Pay Later
  • [Warranty Information] Warranty
    Manufacturer Warranty
Estimate delivery
Shipping calculated at checkout
Estimate delivery times: 3-7 business days
Guaranteed Safe Checkout
Guaranteed Safe Checkout
Accepted payments: Google Pay, Apple Pay, Visa, Mastercard and PayPal
SKU
TL-SF1016DS
Barcode
6935364021535

The TP-Link TL-SF1016DS is a 16-port 10/100 Mbps unmanaged switch in a 13-inch steel case that sits on a desk or mounts in a rack. All 16 RJ45 ports auto-negotiate and support auto MDI/MDIX, the non-blocking architecture gives 3.2 Gbps switching capacity and a 2.38 Mpps forwarding rate, and it runs fanless from an internal 100-240 V power supply with TP-Link's energy-efficient Green Technology.

TL-SF1016DS overview

The TL-SF1016DS is TP-Link's 16-port 10/100 Mbps desktop/rackmount switch. TP-Link describes it as a high-performance, low-cost and easy-to-use way to upgrade an older network to 100 Mbps, and positions it as very cost-effective for environments of fewer than 16 users. It has sixteen 10/100 Mbps RJ45 ports, and every port supports auto-negotiation and auto MDI/MDIX: auto-negotiation senses the link speed of each connected device (10 or 100 Mbps) and adjusts for compatibility and optimal performance, while auto MDI/MDIX removes the need for crossover cables, so there is no need to worry about the cable type. It supports IEEE 802.3i, 802.3u and 802.3x. As an unmanaged switch there is nothing to configure: you plug in the power cord and network cables and it starts switching, learning MAC addresses automatically.

Performance comes from a non-blocking switching architecture that forwards and filters packets at full wire speed for maximum throughput. TP-Link lists a switching capacity of 3.2 Gbps, a packet forwarding rate of 2.38 Mpps, an 8K MAC address table, 2 Mb of buffer memory and store-and-forward transmission. To keep traffic flowing under load, IEEE 802.3x flow control works in full-duplex mode and backpressure works in half-duplex mode, which TP-Link says alleviates congestion and keeps the switch working reliably. Network media are UTP category 3, 4 or 5 cable for 10BASE-T and category 5, 5e or above for 100BASE-TX, both up to 100 m.

The switch is built into a standard 13-inch steel case with a safety-certified internal power supply, so there is no external power brick, and TP-Link calls the combination a robust design. It runs from 100-240 V AC at 50/60 Hz and is fanless for silent operation. TP-Link's Green Technology automatically adjusts power consumption according to link status and cable length, which TP-Link says saves up to 75% of power, and the maximum power consumption is just 2.06 W at 220 V, with a maximum heat dissipation of 7.03 BTU/h. The switch complies with RoHS, and TP-Link notes that most of the packaging material can be recycled. TP-Link also lists physical security lock support.

For installation, the TL-SF1016DS can sit on a desk or shelf on the included rubber feet, or be mounted in a rack with the included rackmount kit. It measures 294 x 180 x 44 mm and is rated for operation from 0 °C to 40 °C at 10% to 90% non-condensing humidity, with storage from -40 °C to 70 °C. Certifications are FCC, CE and RoHS. In the box are the 16-port switch, a power cord, an installation guide, a rackmount kit and rubber feet. ARC IP Networks supplies the TL-SF1016DS from Australian stock with the full manufacturer's warranty.

Key features

16 x 10/100 Mbps ports

Sixteen RJ45 ports with auto-negotiation and auto MDI/MDIX.

Plug and play

Unmanaged, with no configuration required and MAC address self-learning.

3.2 Gbps switching

Non-blocking architecture with a 2.38 Mpps forwarding rate at full wire speed.

Flow control

IEEE 802.3x flow control for full duplex and backpressure for half duplex.

Desktop or rackmount

13-inch steel case with rackmount kit and rubber feet included.

Internal power supply

Safety-certified internal 100-240 V supply, no external adapter.

Fanless and silent

No fan, with a maximum power consumption of 2.06 W.

Green Technology

Adjusts power to link status and cable length, saving up to 75% of power.

Security lock slot

A physical security lock slot on the chassis.

TL-SF1016DS specifications

At a glance

16 x 10/100 Mbps RJ45
3.2 Gbps switching
2.38 Mpps forwarding
8K MAC table
Unmanaged, plug and play
Fanless
Internal power supply
Desktop / rackmount
TL-SF1016DS full specifications
Hardware Features
Standards and ProtocolsIEEE 802.3i, IEEE 802.3u, IEEE 802.3x
Interface16 10/100Mbps RJ45 Ports (Auto Negotiation/Auto MDI/MDIX)
Network Media10BASE-T: UTP category 3, 4, 5 cable (maximum 100m); 100BASE-TX: UTP category 5, 5e or above cable (maximum 100m)
Fan QuantityFanless
Physical Security LockYes
Power Supply100-240VAC, 50/60Hz
Dimensions ( W x D x H )11.6×7.1×1.7 in. (294×180×44 mm)
MountingRack Mountable
Max. Power Consumption2.06W(220V/50Hz)
Max. Heat Dissipation7.03BTU/h
Performance
Switching Capacity3.2Gbps
Packet Forwarding Rate2.38Mpps
MAC Address Table8K
Buffer Memory2Mb
Advanced FeaturesGreen Technology; 802.3X Flow Control
Transmission MethodStore-and-Forward
Others
CertificationFCC, CE, RoHS
EnvironmentOperating Temperature: 0℃~40℃ (32℉~104℉);; Storage Temperature: -40℃~70℃ (-40℉~158℉);; Operating Humidity: 10%~90% non-condensing; Storage Humidity: 5%~90% non-condensing

Source: TP-Link's published specifications for this model (TP-Link Australia product page). throughput figures are TP-Link's lab results. TP-Link may change specifications without notice.

What's in the box

  • 16-Port 10/100Mbps Desktop/Rackmount Switch
  • Power Cord
  • Installation Guide
  • Rackmount Kit
  • Rubber Feet

Source: TP-Link's published package contents.

Who the TL-SF1016DS is for

Small offices and shops

  • Up to 16 wired devices at 10/100 Mbps
  • No configuration needed
  • Cost-effective for under 16 users

Comms cabinets and racks

  • 13-inch steel case with rackmount kit
  • Internal power supply, no adapter
  • Fanless, 2.06 W maximum

TL-SF1016DS compared

The TL-SF1016DS sits between TP-Link's 24-port 10/100 TL-SF1024D, which uses the same 294 x 180 x 44 mm case, and the 16-port gigabit TL-SG1016 rackmount switch.

SpecificationTL-SF1016DSTL-SF1024DTL-SG1016
Ports16 x 10/100 Mbps24 x 10/100 Mbps16 x 10/100/1000 Mbps
Switching capacity3.2 Gbps4.8 Gbps32 Gbps
Forwarding rate2.38 Mpps3.57 Mpps23.8 Mpps
MAC address table8K8K8K
Max. power consumption2.06 W3.19 W10.68 W
CoolingFanlessFanlessFanless
Dimensions294 x 180 x 44 mm294 x 180 x 44 mm440 x 140 x 44 mm

Source: TP-Link Australia product pages for each model.

Buy the TL-SF1016DS from ARC IP Networks

ARC IP Networks supplies genuine TP-Link products from Australian stock at competitive prices, with the full manufacturer's warranty, Australia-wide delivery and trade pricing for installers and MSPs.

  • Genuine TP-Link: new TP-Link product from Australian stock.
  • Manufacturer warranty: the full TP-Link manufacturer's warranty for this model.
  • Australia-wide delivery to every state and territory.
  • Trade and project pricing: call 1300 100 440 or email info@arcip.com.au.

Frequently asked questions

Straight answers about the TL-SF1016DS from the ARC IP Networks team.

Last reviewed October 2026.

No. It has sixteen 10/100 Mbps RJ45 ports. For gigabit ports TP-Link's equivalent 16-port rackmount model is the TL-SG1016.

No. It is an unmanaged plug-and-play switch with auto-negotiation, auto MDI/MDIX and MAC address self-learning.

Yes. It has a 13-inch steel case and comes with a rackmount kit, plus rubber feet for desktop use.

No. The TL-SF1016DS is fanless, with a maximum power consumption of 2.06 W at 220 V.

No. It has a safety-certified internal power supply rated 100-240 V AC, 50/60 Hz, and comes with a power cord.

3.2 Gbps, with a packet forwarding rate of 2.38 Mpps, an 8K MAC address table and 2 Mb of buffer memory.

No. Auto MDI/MDIX on every port removes the need for crossover cables.

Category 5, 5e or better UTP for 100BASE-TX, or category 3, 4 or 5 for 10BASE-T, up to 100 m.

Yes. TP-Link's Green Technology adjusts power to link status and cable length, which TP-Link says saves up to 75% of power.

294 x 180 x 44 mm, the same case size as the 24-port TL-SF1024D.

The switch, a power cord, an installation guide, a rackmount kit and rubber feet.

Need more than one TL-SF1016DS for an office or cabinet fit-out?

Ask ARC IP Networks for volume and project pricing on genuine TP-Link products.
