TP-Link FC111PB-20 10/100Mbps WDM Media Converter with 1-Port PoE

https://arcip.com.au/web/image/product.template/9299/image_1920?unique=874d354

The TP-Link FC111PB-20 (TL-FC111PB-20) is a 10/100 Mbps WDM media converter with 1-port PoE. It provides 1 x 10/100 Mbps PoE RJ45 port (auto-MDI/MDIX) and 1 x 100 Mbps SC fibre port, converting between electrical and optical signals over a single 9/125 um single-mode fibre for up to 20 km. It transmits at 1310 nm and receives at 1550 nm, so it pairs with the TL-FC111A-20. The 802.3af PoE output makes remote camera deployment easier, the unit is powered by a 48 V / 0.5 A adapter, and it works standalone or in TP-Link's TL-FC1420 rack.

$ 52.51 52.51 AUD $ 52.51 incl. GST

Not Available For Sale


  • Brand

This combination does not exist.

  • Stock

    Authorised Australian Reseller | Australian Stock | Genuine Local Warranty

  • Instalment
    Buy Now, Pay Later
  • [Warranty Information] Warranty
    Manufacturer Warranty
Estimate delivery
Shipping calculated at checkout
Estimate delivery times: 3-7 business days
Guaranteed Safe Checkout
Guaranteed Safe Checkout
Accepted payments: Google Pay, Apple Pay, Visa, Mastercard and PayPal
SKU
TL-FC111PB-20
Barcode
4897098683064

The TP-Link FC111PB-20 (TL-FC111PB-20) is a 10/100 Mbps WDM media converter with 802.3af PoE output. It has one 10/100 Mbps PoE RJ45 port and one 100 Mbps SC fibre port, sends and receives on a single strand of single-mode fibre up to 20 km (1310 nm TX, 1550 nm RX), and powers a camera or other PoE device at the far end from its 48 V / 0.5 A adapter. It pairs with the TL-FC111A-20.

FC111PB-20 overview

The FC111PB-20, also listed by TP-Link as the TL-FC111PB-20, is a 10/100 Mbps media converter with 802.3af PoE output. It provides one 10/100 Mbps PoE RJ45 port and one 100 Mbps SC fibre port, and converts between electrical and optical signals. TP-Link says that with up to 20 km of fibre transmission distance and 802.3af PoE output, it is designed to address the needs of flexible long-range surveillance deployment with optical fibre, and that it provides an economical path towards extending the distance of an existing network. In practice it sits at the remote end of a fibre run, next to an IP camera or access point, and powers that device over its RJ45 cable while carrying its data back over fibre.

Like the rest of the series it uses WDM (wavelength division multiplexing) to send and receive over one strand of single-mode fibre, which TP-Link says saves half of the cable deployment cost. The FC111PB-20 transmits at 1310 nm and receives at 1550 nm. The device used with it must therefore transmit at 1550 nm and receive at 1310 nm, and TP-Link names the TL-FC111A-20 as a product that can cooperate with the TL-FC111PB-20. A typical link is a TL-FC111A-20 at the switch end, a single-mode fibre of up to 20 km, and an FC111PB-20 at the camera end powering the camera with PoE. Two converters of this same model cannot be paired with each other, because both transmit on 1310 nm.

The PoE output is the main difference from the TL-FC111A-20. The FC111PB-20 RJ45 port is a PoE port with its own PoE LED next to the PWR and Link/Act indicators, and the converter is powered by a 48 V / 0.5 A adapter rather than the 5 V / 0.6 A adapter used by the TL-FC111A-20. TP-Link highlights that the 802.3af PoE output makes remote camera deployment easier and more convenient. The fibre port is rated for 9/125 um single-mode fibre up to 20 km, and the RJ45 port for 100BASE-TX over 2-pair UTP or STP of Category 5 or above up to 100 m. The converter complies with IEEE 802.3, 802.3i and 802.3u and auto-negotiates half-duplex or full-duplex transfer mode.

The FC111PB-20 measures 94.5 x 73.0 x 27.0 mm (3.7 x 2.9 x 1.1 in). TP-Link says it can be used as a standalone device with no rack required, or with TP-Link's TL-FC1420 rack, with auto-MDI/MDI-X on the TX port and automatic duplex negotiation. TP-Link highlights its wide operating temperature of 0 to 50 degrees C; storage is -40 to 70 degrees C, with 10 to 90% RH operating and 5 to 90% RH storage humidity, non-condensing. The box contains the TL-FC111PB-20 media converter, a power adapter and an installation guide.

Key features

802.3af PoE output

Powers a camera or other PoE device at the far end of the fibre.

Single-fibre WDM

Transmits and receives on one single-mode fibre strand.

Up to 20 km

Extends fibre distance up to 20 km on 9/125 um single-mode fibre.

1310 nm TX / 1550 nm RX

Pairs with the TL-FC111A-20 at the other end of the link.

PoE RJ45 and SC fibre ports

One 10/100 Mbps PoE RJ45 port and one 100 Mbps SC fibre port.

48 V adapter

Powered by a 48 V / 0.5 A adapter, included.

Standalone or rack

Use on its own or in TP-Link's TL-FC1420 rack.

FC111PB-20 specifications

At a glance

10/100 Mbps
1 x PoE RJ45
802.3af PoE out
1 x SC fibre
1310 nm TX / 1550 nm RX
Up to 20 km
48 V / 0.5 A adapter
0 to 50 degrees C
FC111PB-20 full specifications
Network
Standards and ProtocolsIEEE802.3, IEEE802.3i, IEEE802.3u
Hardware Features
Interface1× 10/100 Mbps PoE RJ45 port (Auto MDI/MDIX); 1× 100 Mbps SC fibre port
Network Media100BASE-Tx: 2-pair UTP/STP of Cat. 5 or above (≤100 m)
Power Supply48 V/0.5 A
LEDPWR, Link/Act, PoE
Wave Length1310 nm TX, 1550 nm RX
Dimensions ( W x D x H )3.7×2.9×1.1 in (94.5×73.0×27.0 mm)
Media Converter & Module
Fibre Type9/125 μm single-mode fber (≤20 km)
Environment
Operating Temperature0–50 °C (32–122 °F)
Storage Temperature-40–70 °C (-40–158 °F)
Operating Humidity10–90% RH non-condensing
Storage Humidity5–90% RH non-condensing

Source: TP-Link's published specifications for this model (TP-Link Australia product page). Some features run only in Standalone Mode or only under an Omada Controller; throughput figures are TP-Link's lab results. TP-Link may change specifications without notice.

What's in the box

  • Media Converter TL-FC111PB-20
  • Power Adapter
  • Installation Guide

Source: TP-Link's published package contents.

Who the FC111PB-20 is for

Remote IP cameras

  • 802.3af PoE to the camera
  • Up to 20 km over fibre
  • Flexible long-range surveillance

Powering devices without local PoE

  • PoE from the converter's 48 V adapter
  • PoE status LED
  • One cable to the device

Single-fibre links

  • One strand of single-mode fibre
  • Pairs with the TL-FC111A-20
  • Standalone or TL-FC1420 rack

FC111PB-20 compared

The FC111PB-20 is the PoE end of TP-Link's 100 Mbps WDM pair; the TL-FC111A-20 is the matching head-end unit. Use one of each, as their transmit and receive wavelengths are reversed.

SpecificationFC111PB-20TL-FC111A-20
Wavelength1310 nm TX, 1550 nm RX1550 nm TX, 1310 nm RX
RJ45 port1 x 10/100 Mbps PoE1 x 10/100 Mbps
PoE output802.3af, max 15.4 WNone
Fibre port1 x 100 Mbps SC1 x 100 Mbps SC
Fibre9/125 um single-mode, up to 20 km9/125 um single-mode, up to 20 km
Power supply48 V / 0.5 A adapter5 V / 0.6 A adapter
LEDsPWR, Link/Act, PoEPWR, Link/Act

Source: TP-Link Australia product pages for each model.

Buy the FC111PB-20 from ARC IP Networks

ARC IP Networks supplies TP-Link Omada products from Australian stock at competitive prices, with the full manufacturer's warranty, Australia-wide delivery and trade pricing for installers and MSPs.

  • New TP-Link Omada product from Australian stock.
  • Manufacturer warranty: the full TP-Link manufacturer's warranty for this model.
  • Australia-wide delivery to every state and territory.
  • Trade and project pricing: call 1300 100 440 or email info@arcip.com.au.

Frequently asked questions

Straight answers about the FC111PB-20 from the ARC IP Networks team.

Last reviewed October 2026.

A 10/100 Mbps WDM media converter with one PoE RJ45 port and one SC fibre port. TP-Link lists it as FC111PB-20 (TL-FC111PB-20).

802.3af PoE. TP-Link's series datasheet lists a maximum PoE output of 15.4 W, for the TL-FC111PB-20 only.

A unit that transmits at 1550 nm and receives at 1310 nm. TP-Link names the TL-FC111A-20. Two converters of this same model cannot be paired.

Up to 20 km on 9/125 um single-mode fibre, using a single strand.

By a 48 V / 0.5 A power adapter, included in the box. That adapter also supplies the PoE output.

The FC111PB-20 adds 802.3af PoE output and a PoE LED, uses a 48 V adapter instead of 5 V, and has the opposite wavelengths (1310 nm TX, 1550 nm RX).

100BASE-TX over 2-pair UTP or STP of Category 5 or above, up to 100 m.

It can be used standalone or with TP-Link's TL-FC1420 rack.

The TL-FC111PB-20 media converter, a power adapter and an installation guide.
