Ruijie RG-NBS3300-16MG4XS-HP at a glance

The Ruijie RG-NBS3300-16MG4XS-HP is a Reyee Layer 2+ cloud managed switch with sixteen 10/100/1000/2500 Mbps RJ45 ports and four 10G SFP+ uplinks. Ports 1-4 support IEEE 802.3bt PoE++ and ports 5-16 support PoE/PoE+, sharing a 370 W PoE budget, with 160 Gbps switching capacity.

ARC IP Networks is an authorised Ruijie reseller in Australia. We supply the genuine Ruijie RG-NBS3300-16MG4XS-HP from Australian stock, with a GST tax invoice on every order.

Ports16 x 2.5G RJ45 + 4 x 10G SFP+
PoE budget370W (4 x PoE++, 12 x PoE+)
Switching160 Gbps
ManagementRuijie Cloud, app, eWeb

Best for

  • Powering Wi-Fi 6 and Wi-Fi 7 access points over 2.5G links, including PoE++ devices
  • Multi-gigabit access layers with up to four 10G fibre uplinks
  • Cloud-managed offices, schools and hospitality sites

Key features

16 x 10/100/1000/2500BASE-T RJ45 ports and 4 x 10GE SFP+ uplink ports.

Ports 1-4: IEEE 802.3af/at/bt PoE/PoE+/PoE++; ports 5-16: IEEE 802.3af/at PoE/PoE+.

370 W total PoE budget.

160 Gbps switching capacity and 119.04 Mpps forwarding rate.

Layer 2+ features: 4094 VLANs, voice VLAN, STP/RSTP/MSTP, ERPS, LACP and IPv4/IPv6 static routing.

CPU Protection Policy (CPP), DHCP snooping, ARP anti-spoofing, IP source guard, ACLs and 802.1X authentication.

Managed via Ruijie Cloud, the Ruijie Reyee App, eWeb or SNMP v1/v2c/v3, with camera detection and PoE alarms.

PoE watchdog and cable test for easier troubleshooting.

Rack-mount metal chassis (440 x 267.5 x 43.6 mm) with 2 fixed fans and automatic speed adjustment.

5-year Ruijie warranty.

Ruijie RG-NBS3300-16MG4XS-HP specifications

Ruijie RG-NBS3300-16MG4XS-HP technical specifications
SpecificationValue
Ports
10/100/1000/2500BASE-T RJ4516
10GE SFP+4
Reset button1
PoE
PoE standardPorts 1–4: IEEE 802.3af/at/bt; ports 5–16: IEEE 802.3af/at
PoE++ ports4
PoE/PoE+ ports12
PoE budget370 W
PoE power pinsPorts 1–4: 1–2(-), 3–6(+), 4–5(+), 7–8(-); ports 5–16: 1–2 (+), 3–6 (-)
Performance
Switching capacity160 Gbps
Forwarding rate119.04 Mpps
RAM512 MB
Flash256 MB
Product categoryLayer 2+
Layer 2 and Layer 3
VLANs4094, IEEE 802.1Q, voice VLAN
Spanning treeSTP, RSTP, MSTP
Ring protectionERPS
Link aggregationStatic and LACP
MAC address entries16000
LLDP / LLDP-MEDYes
MulticastIGMP v1/v2/v3 snooping, IGMP filtering
Jumbo frame (MTU)9216 bytes
Static routingIPv4 and IPv6 (64 static routes each)
ARP entries1000
DHCPClient and relay
IPv6Yes
QoS and security
QoS802.1p and DSCP classification, SP, WRR, SP+WRR
Rate limitingInbound/outbound per interface
AuthenticationRADIUS, 802.1X (port and MAC based), guest VLAN
SecurityDHCP snooping, IP source guard, ARP anti-spoofing, IP-MAC-port binding, port isolation, storm control, ACLs (1900 inbound ACEs), CPU Protection Policy (CPP)
Management
ManagementRuijie Cloud, Ruijie Reyee App, eWeb (HTTP/HTTPS), SNMP v1/v2c/v3
MonitoringPort mirroring, syslog, cable test, loop alarm, camera detection, PoE alarms
ReliabilitySystem dual backup (factory ReyeeOS 2.320 or later), PoE watchdog
Power and physical
Power supplyFixed, 100 V AC to 240 V AC, 50/60 Hz, 6 A max
Maximum power consumption40 W with no PoE load; 460 W with full PoE load
Dimensions (W x D x H)440 x 267.5 x 43.6 mm
MountingRack
Cooling2 x fixed fans, automatic speed adjustment
Acoustic noise40 dB at 25°C
Environment and compliance
Operating temperature0°C to 50°C
Storage temperature-40°C to +70°C
Operating humidity10% to 90% RH, non-condensing
MTBF400,000 hours
Surge protectionService port ±6 kV; power connector ±6 kV common and differential mode
CertificationCE, FCC
Warranty5 years
In the boxSwitch, 4 rubber pads, power cord retention clip, 8 x M4 x 8 mm screws, 1 m grounding cable, 1.5 m power cord, 2 rack-mount brackets, user manual, warranty card

Figures from Ruijie's official product page and datasheet.

The Ruijie RG-NBS3300-16MG4XS-HP in depth

2.5G everywhere, PoE++ where needed

All sixteen RJ45 ports run at up to 2.5 Gbps, giving Wi-Fi 6 and Wi-Fi 7 access points more than a gigabit of uplink. The first four ports add IEEE 802.3bt PoE++ for higher-power devices, and the remaining twelve provide PoE/PoE+, all from a 370 W budget.

10G uplinks and cloud management

Four 10G SFP+ ports connect to the core or aggregation layer over fibre. The switch can be managed through Ruijie Cloud, the Ruijie Reyee App, eWeb or SNMP, with VLANs, spanning tree, ERPS, LACP, IGMP snooping and static routing.

Secure and serviceable

CPU Protection Policy, DHCP snooping, ARP anti-spoofing, ACLs and 802.1X protect the network, and PoE watchdog, camera detection and PoE alarms simplify day-to-day support. Ruijie rates the MTBF at 400,000 hours with a 5-year warranty.

Frequently asked questions

Straight answers about the Ruijie RG-NBS3300-16MG4XS-HP from the ARC IP Networks team. Last reviewed October 2026.

Four. Ports 1-4 support IEEE 802.3af/at/bt (PoE/PoE+/PoE++) and ports 5-16 support IEEE 802.3af/at (PoE/PoE+).

370 W. Maximum power consumption is 460 W at full PoE load.

Yes. All 16 RJ45 ports are 10/100/1000/2500BASE-T, plus there are 4 x 10GE SFP+ uplink ports.

Through Ruijie Cloud, the Ruijie Reyee App, the eWeb interface (HTTP/HTTPS) or SNMP v1/v2c/v3.

Ruijie lists a 5-year warranty for the RG-NBS3300-16MG4XS-HP.

ARC IP Networks is an authorised Ruijie reseller and supplies the RG-NBS3300-16MG4XS-HP from Australian stock with a GST tax invoice.

Explore the full Ruijie range: Ruijie Australia hub · Shop all Ruijie Reyee

Buy the Ruijie RG-NBS3300-16MG4XS-HP in Australia

ARC IP Networks is an authorised Ruijie reseller, supplying Ruijie Reyee access points, switches, routers and wireless bridges to businesses, installers and integrators across Australia.

  • Genuine Ruijie with the full manufacturer's warranty, supplied from Australian stock.
  • Australian stock, shipped Australia-wide.
  • Manufacturer's warranty and local help with warranty claims and choosing the right model.
  • GST tax invoice on every order, with trade and project pricing available.

Planning a Ruijie network?

Ask ARC IP Networks for project pricing or a configured quote, or call us to check the right Ruijie model for your site.

Brand Ruijie
Switching Capacity 160 Gbps
Network Layer Layer 2+
Form Factor Rack Mount
Ports 16 Ports
Network Connectivity Wired
Uplink 4 x 10G SFP+
PoE Specification PoE++ 802.3bt / 370 W budget
