Ruijie RG-AP820-L(V2) Wi-Fi 6 Dual-Radio 2.402 Gbps Indoor Access Point, Gigabit PoE, Fat/Fit/Cloud

https://arcip.com.au/web/image/product.template/10352/image_1920?unique=306b97f

Ruijie RG-AP820-L(V2) Wi-Fi 6 dual-radio indoor access point. 802.11ax, 2x2 MU-MIMO per radio, selectable 2.4 + 5 GHz (1.775 Gbps) or 5 + 5 GHz (2.402 Gbps) modes, OFDMA, 1024-QAM. One Gigabit port with 802.3af PoE in, or 48 V DC; 12.95 W maximum. Up to 1,024 clients, WPA3, 802.1X, PPSK, WIDS. Fat/Fit/Cloud switchover for RG-WS controllers, Eweb or Ruijie Cloud. Bluetooth 5.0. 153 x 193 x 26 mm, wall or ceiling mount, Kensington lock. Genuine Ruijie from ARC IP Networks, authorised Ruijie reseller with Australian stock.

$ 253.01 253.01 AUD $ 253.01 incl. GST

Not Available For Sale


  • Brand
  • Form Factor
  • Ports
  • Network Connectivity
  • PoE Specification
  • WiFi Standard
  • Frequency Band

This combination does not exist.

In stock online
WiFi 6 Indoor Access Point Rackmount Ruijie Cloud Managed Ceiling Mount WiFi Reyee
  • Stock

    Authorised Australian Reseller | Australian Stock | Genuine Local Warranty

  • Instalment
    Buy Now, Pay Later
  • [Warranty Information] Warranty
    Manufacturer Warranty
Estimate delivery
Shipping calculated at checkout
Estimate delivery times: 3-7 business days
Guaranteed Safe Checkout
Guaranteed Safe Checkout
Accepted payments: Google Pay, Apple Pay, Visa, Mastercard and PayPal
SKU
RG-AP820-L-V2
Barcode
6971693271432
Tags

Ruijie RG-AP820-L(V2) at a glance

The Ruijie RG-AP820-L(V2) is an enterprise Wi-Fi 6 dual-radio indoor access point with selectable 2.4 GHz + 5 GHz or 5 GHz + 5 GHz radio modes, reaching 1.775 Gbps or 2.402 Gbps combined respectively. It has a Gigabit PoE port, is only 26 mm high, mounts on a wall or ceiling and switches between Fat, Fit and Cloud modes.

ARC IP Networks is an authorised Ruijie reseller in Australia. We supply the genuine Ruijie RG-AP820-L(V2) from Australian stock, with a GST tax invoice on every order.

Wi-FiWi-Fi 6, up to 2.402 Gbps
Radio modes2.4+5 GHz or 5+5 GHz
Power802.3af PoE or 48 V DC, 12.95 W
ModesFat / Fit / Cloud

Best for

  • Meeting rooms, classrooms, libraries and leisure areas with dense client counts
  • Hotels, offices, hospitals and schools needing discreet wall or ceiling APs
  • Campus networks managed by Ruijie RG-WS controllers or Ruijie Cloud

Key features

Wi-Fi 6 (802.11ax) dual-radio design with 2 x 2 MU-MIMO per radio and four spatial streams.

Radio 1 selectable between 2.4 GHz and 5 GHz: 1.775 Gbps in 2.4 + 5 GHz mode or 2.402 Gbps in 5 + 5 GHz mode.

OFDMA, 1024-QAM and 80 MHz channels; 802.11k/v/r client steering in Fit mode.

One 10/100/1000BASE-T port with 802.3af PoE input and 802.3az Energy Efficient Ethernet.

Local 48 V DC/0.3 A power option (adapter sold separately); 12.95 W maximum power consumption.

Up to 1,024 associated clients (120 recommended active devices) and 32 BSSIDs.

WPA3, 802.1X, PPSK and PSK authentication, WIDS with rogue AP detection.

Flexible Fat/Fit/Cloud switchover with ZTP in Fit mode; PPPoE, NAT and IPsec VPN for branches.

26 mm high, wall or ceiling mounting with bracket included, securing latch and Kensington lock.

Bluetooth 5.0 radio.

Ruijie RG-AP820-L(V2) specifications

Ruijie RG-AP820-L(V2) technical specifications
SpecificationValue
Wi-Fi radio
Standards802.11ax, 802.11ac Wave 2/Wave 1, 802.11n
Radio designRadio 1: 2.4 GHz/5 GHz 2x2 MU-MIMO; Radio 2: 5 GHz 2x2 MU-MIMO
Combined peak data rate1.775 Gbps (2.4 + 5 GHz) or 2.402 Gbps (5 + 5 GHz)
Per-radio rates2.4 GHz 574 Mbps; 5 GHz 1.201 Gbps
ModulationUp to 1024-QAM, OFDMA
AntennasBuilt-in omnidirectional: 2 x 2.4 GHz, 4 x 5 GHz; 5 dBi
Maximum transmit power20 dBm per radio (17 dBm per chain)
Bluetooth
VersionBluetooth 5.0
Maximum transmit power10 dBm
Ports and power
Service port1 x 10/100/1000BASE-T, 802.3af PoE in, 802.3az EEE
Management port1 x RJ45 console
DC input48 V DC/0.3 A, 2.1 mm/5.5 mm centre-positive (adapter sold separately)
Maximum power consumption12.95 W
WLAN and software
Associated clientsUp to 1,024 (120 recommended active devices)
BSSIDs32 (up to 16 per radio)
RoamingLayer 2 and Layer 3 (Fit mode)
SecurityWPA, WPA2, WPA3, 802.1X, PEAP, PPSK, PSK, web; WIDS, rogue AP detection
RoutingPPPoE client, NAT, DHCP server, IPv4/IPv6 static routing, IPsec VPN, LLDP
Software versionRGOS 11.9(6)W3B1 or later
Management
ModesFat / Fit / Cloud switchover
PlatformsRuijie Cloud, Eweb, RG-WS series controllers, Ruijie Reyee App
AccessConsole, Telnet, SSH, SNMPv1/v2c/v3, TFTP
Physical and environmental
Dimensions (W x D x H)153 x 193 x 26 mm
MountingWall / ceiling (bracket included)
LockSecuring latch and Kensington lock
ColourWhite
Operating temperature-10°C to +50°C
Operating humidity5% to 95% RH, non-condensing
MTBF200,000 hours at 25°C
Package contents
In the boxAccess point, mounting bracket, 2 x wall anchors, 2 x M4 x 20 mm screws, warranty card, quick start guide

Figures from Ruijie's official product page and datasheet.

The Ruijie RG-AP820-L(V2) in depth

Wi-Fi 6 with a dual 5 GHz option

The RG-AP820-L(V2) is a Ruijie enterprise Wi-Fi 6 indoor AP whose first radio can run on 2.4 GHz or 5 GHz. In 2.4 + 5 GHz mode it reaches 1.775 Gbps combined; in 5 + 5 GHz mode it reaches 2.402 Gbps, adding capacity where clients are dense.

Slim and flexible to install

At 26 mm high with a concealed LAN port and discreet cabling, it mounts on a wall or ceiling using the supplied bracket. Power comes from 802.3af PoE or a 48 V DC adapter, with 12.95 W maximum consumption.

Controller, standalone or cloud

The AP switches between Fat, Fit and Cloud modes. With an RG-WS controller it gains centralised or local forwarding, 802.11k/v/r steering and Layer 3 roaming; with Ruijie Cloud it gains AI-based wireless optimisation and a Wi-Fi heat map.

Frequently asked questions

Straight answers about the Ruijie RG-AP820-L(V2) from the ARC IP Networks team. Last reviewed October 2026.

Up to 1.775 Gbps combined in 2.4 GHz + 5 GHz mode, or 2.402 Gbps in 5 GHz + 5 GHz mode.

By IEEE 802.3af PoE on its Gigabit port or a 48 V/0.3 A DC adapter (sold separately). Maximum power consumption is 12.95 W.

Up to 1,024 associated clients, with 120 recommended active devices per AP.

Ruijie states the RG-AP820-L(V3) adds an optical SFP port. The V2 has a single Gigabit Ethernet port, a selectable dual 5 GHz radio mode and a slim 26 mm high body.

Yes. It supports wall and ceiling mounting, and a mounting bracket is delivered with the AP.

ARC IP Networks is an authorised Ruijie reseller and supplies the RG-AP820-L(V2) from Australian stock with a GST tax invoice.

Explore the full Ruijie range: Ruijie Australia hub · Shop all Ruijie Reyee

Buy the Ruijie RG-AP820-L(V2) in Australia

ARC IP Networks is an authorised Ruijie reseller, supplying Ruijie Reyee access points, switches, routers and wireless bridges to businesses, installers and integrators across Australia.

  • Genuine Ruijie with the full manufacturer's warranty, supplied from Australian stock.
  • Australian stock, shipped Australia-wide.
  • Manufacturer's warranty and local help with warranty claims and choosing the right model.
  • GST tax invoice on every order, with trade and project pricing available.

Planning a Ruijie network?

Ask ARC IP Networks for project pricing or a configured quote, or call us to check the right Ruijie model for your site.

Brand Ruijie
Form Factor Ceiling Mount
Ports 1 Port
Network Connectivity Wi-Fi 6
PoE Specification PoE-in 802.3af
WiFi Standard 802.11ax (WiFi 6)
Frequency Band Dual-Band (2.4 + 5 GHz)
RG-AP820-L_V2__Wi-Fi_6_Dual-Radio_Indoor_Access_Point_Datasheet.pdf
