IDS-9632NXI-P16
Hikvision IDS-9632NXI-P16 — DeepinMind Pro 32-Channel NVR, 16-Bay, 8K Output, Guanlan Large-Scale AI Models

Key Features

  • Up to 32 IP cameras supported with resolutions up to 32 MP per channel
  • 8K (7680 × 4320) HDMI 1 output at 30 Hz for ultra-high-definition monitoring walls
  • 16 SATA interfaces supporting 3.5‑inch HDDs up to 20 TB each — up to 320 TB raw capacity
  • RAID 0, 1, 5, 6, and 10 support for enterprise-grade data redundancy
  • Intelligent analytics powered by Guanlan Large‑Scale AI Models for superior accuracy
  • Up to 32‑ch AcuSeek and AcuSearch for rapid forensic search across 600,000 targets/day
  • Up to 16‑ch live facial recognition for video stream; 32‑ch face picture comparison
  • Up to 24‑ch perimeter protection (with Large Model secondary analysis support)
  • Up to 16‑ch video structuralization for intelligent metadata extraction
  • 320 Mbps incoming and 400 Mbps outgoing bandwidth for high-density deployments
  • Dual HDMI and dual VGA outputs for flexible multi-monitor control room configurations
  • RCM certified — compliant for sale and installation in Australia

Specifications

Video & Audio
IP Video Input32‑ch; up to 32 MP resolution (NVR supports up to 8‑ch 32 MP/24 MP inputs)
Incoming Bandwidth320 Mbps
Outgoing Bandwidth400 Mbps
HDMI 1 Output8K (7680 × 4320)/30 Hz; 4K (3840 × 2160)/60 Hz; 4K/30 Hz; 2K (2560 × 1440)/60 Hz; 1920 × 1080/60 Hz
HDMI 2 Output4K (3840 × 2160)/60 Hz; 4K/30 Hz; 2K/60 Hz; 1080P/60 Hz (max 1080p when HDMI 1 is at 8K)
VGA 1 / VGA 2 Output1920 × 1080/60 Hz each
CVBS Output1‑ch, BNC (1.0 Vp‑p, 75 Ω); PAL: 704 × 576; NTSC: 704 × 480
Audio Output2‑ch, RCA (Linear, 1 kΩ)
Two‑Way Audio1‑ch, RCA (2.0 Vp‑p, 1 kΩ)
Recording & Decoding
Decoding FormatH.265/H.265+/H.264/H.264+
Decoding Capability2‑ch@32 MP (30 fps) / 2‑ch@24 MP (30 fps) / 4‑ch@16 MP (30 fps) / 8‑ch@8 MP (30 fps) / 16‑ch@4 MP (30 fps) / 32‑ch@2 MP (30 fps)
Synchronous Playback16‑ch
Recording Resolution32 MP / 24 MP / 12 MP / 8 MP / 6 MP / 5 MP / 4 MP / 3 MP / 1080p / UXGA / 720p / VGA / 4CIF / DCIF / 2CIF / CIF / QCIF
HDD & Storage
SATA Interfaces16 SATA interfaces; 3.5‑inch HDD
eSATA1 eSATA interface
Maximum Capacity per HDDUp to 20 TB
RAID TypesRAID 0, RAID 1, RAID 5, RAID 6, RAID 10
Network
Network Interface2 × RJ‑45 10/100/1000 Mbps self‑adaptive Ethernet
Remote Connections128
Network ProtocolsTCP/IP, DHCP, IPv4, IPv6, DNS, DDNS, NTP, RTSP, SADP, SMTP, SNMP, NFS, iSCSI, ISUP, UPnP, HTTP, HTTPS, ONVIF, OTAP
APIONVIF (Profile S/G); SDK; ISAPI
Compatible BrowsersIE11, Chrome V57, Firefox V52, Safari V12, Edge V89, or above
Decoding & AI Engine
AI by NVRFacial recognition, perimeter protection, video structuralization, AcuSearch
AI by CameraFacial recognition, perimeter protection, video structuralization, AcuSearch, motion detection 2.0, ANPR, people counting, VCA
GPU Engines2 GPU engines; each engine configurable: facial recognition 8‑ch (4 MP); perimeter protection 12‑ch (2 MP); video structuralization 8‑ch (2 MP); AcuSearch 16‑ch (2 MP)
Facial Recognition (Live)Up to 16‑ch video stream; up to 32‑ch face picture comparison; 32 libraries up to 100,000 faces
AcuSearchAll channels via camera; up to 16‑ch 2 MP / 8‑ch 4 MP / 4‑ch 8 MP by NVR; 600,000 targets/day
Perimeter Protection (NVR)24‑ch 2 MP or 16‑ch 4 MP or 8‑ch 8 MP (without Large Model); 12‑ch 2 MP with Large Model
Video Structuralization16‑ch 2 MP / 12‑ch 4 MP / 6‑ch 8 MP structured analysis by NVR
ANPRAll channels via camera; vehicle brand, color, type, plate number, plate color, plate type
Interface
USB InterfacesFront: 2 × USB 2.0; Rear: 2 × USB 3.0
Serial Interfaces1 × RS‑232; 1 × RS‑485 (full‑duplex)
Alarm In/Out16 inputs / 9 outputs
Ctrl 12V / DC 12V12 VDC, 1 A each (Ctrl 12V triggered by alarm output 9)
General
Power Supply100–240 VAC, 50–60 Hz
Power Consumption≤ 50 W (without HDD)
Working Temperature−10 °C to 55 °C (14 °F to 131 °F)
Working Humidity10–90%
CertificationsCE, IC, CB, RoHS, REACH, WEEE, RCM, UKCA, LOA

Frequently Asked Questions

What is the IDS-9632NXI-P16 and what series does it belong to?

The IDS-9632NXI-P16 is Hikvision's DeepinMind Pro NVR, a 32-channel professional network video recorder equipped with 16 SATA HDD bays and 8K output capability. It belongs to the DeepinMind series, which uses Guanlan Large-Scale AI Models to power advanced intelligent analytics including facial recognition, perimeter protection, and AcuSeek forensic search.

How many cameras can be connected to the IDS-9632NXI-P16?

The IDS-9632NXI-P16 supports up to 32 IP cameras simultaneously. It accepts resolutions up to 32 MP per channel, with an incoming bandwidth of 320 Mbps. The NVR natively supports up to 8 channels of 32 MP or 24 MP inputs, while the remaining channels support up to 8 MP (4K) resolution.

What storage capacity does the IDS-9632NXI-P16 support?

The IDS-9632NXI-P16 features 16 SATA interfaces for 3.5-inch HDDs, each supporting up to 20 TB, giving a maximum raw capacity of 320 TB. In addition, one eSATA port allows external storage expansion. RAID levels 0, 1, 5, 6, and 10 are supported for data redundancy and performance tuning in enterprise deployments.

What AI and intelligent analytics capabilities does the DeepinMind Pro NVR provide?

The IDS-9632NXI-P16 DeepinMind Pro NVR includes two configurable GPU engines running Guanlan Large-Scale AI Models. It provides: up to 16-ch live facial recognition and 32-ch face picture comparison with up to 100,000 stored faces across 32 libraries; up to 24-ch perimeter protection; up to 16-ch video structuralization; 32-ch AcuSeek forensic video search capable of modeling 600,000 targets per day; and full-channel ANPR for vehicle attribute detection via camera.

Is the IDS-9632NXI-P16 compliant for use in Australia?

Yes. The IDS-9632NXI-P16 holds RCM (Regulatory Compliance Mark) certification, confirming it meets Australian and New Zealand electromagnetic compatibility and electrical safety requirements. It is supplied from Australian stock by ARC IP Networks.

What video output options does the IDS-9632NXI-P16 support?

The IDS-9632NXI-P16 provides dual HDMI and dual VGA outputs for flexible control room configurations. HDMI 1 supports resolutions up to 8K (7680 × 4320) at 30 Hz and up to 4K (3840 × 2160) at 60 Hz. HDMI 2 supports up to 4K at 60 Hz (limited to 1080p when HDMI 1 is running at 8K). Both VGA 1 and VGA 2 outputs deliver up to 1920 × 1080 at 60 Hz. A BNC CVBS output is also included for legacy monitor connectivity.

Professional Overview

The Hikvision iDS-9632NXI-P16 DeepinMind Pro NVR represents the pinnacle of AI-driven video recording for large-scale professional and enterprise surveillance installations. Engineered to accept 32 IP cameras at resolutions up to 32 MP, the P16 delivers an 8K (7680 × 4320) HDMI output alongside a second 4K HDMI port, enabling operators to build immersive, high-definition monitoring walls that reveal fine scene detail invisible to conventional HD systems. Its 320 Mbps incoming and 400 Mbps outgoing bandwidth are sufficient to handle dense multi-megapixel camera deployments without frame-rate compromise.

Storage architecture is central to the P16's enterprise credentials. Sixteen SATA ports accommodate 3.5-inch HDDs of up to 20 TB each — reaching 320 TB raw capacity — while full RAID 0/1/5/6/10 software RAID eliminates single points of failure and provides read-performance acceleration. An eSATA port further extends storage for long-term archival. Synchronous 16-channel playback allows investigators to review events across a large camera network at full resolution without bottlenecks.

The NVR's two reconfigurable GPU engines power Guanlan Large‑Scale AI Models across every key analytics domain. Operators can run up to 24-channel perimeter protection, 16-channel facial recognition against libraries of up to 100,000 faces, 16-channel video structuralization, and the acclaimed AcuSeek forensic search — capable of modeling 600,000 objects per day — simultaneously or in any user‑defined combination. When paired with Hikvision AcuSense cameras that push AcuSearch metadata to the recorder, all 32 channels contribute to forensic search targets, dramatically accelerating post-event investigations in transport hubs, stadiums, campuses, and critical infrastructure sites.

Connectivity is equally comprehensive: dual Gigabit Ethernet interfaces, RS‑232 and RS‑485 serial ports, 16 alarm inputs, 9 alarm outputs, and front‑ and rear‑panel USB ports cover virtually every integration requirement. The device operates from 100–240 VAC across a −10 °C to 55 °C temperature range, drawing only 50 W (without HDDs) — a notable efficiency figure for a 3U chassis with 16 active drive bays. RCM‑certified and backed by Hikvision's global firmware support, the iDS-9632NXI-P16 is the reference NVR choice for integrators demanding maximum channel density, AI depth, and storage capacity in a single platform. Australian stock from ARC IP Networks.

Brand Hikvision
HDD Bays 16
Max Resolution 32 MP
Channels 32
Incoming Bandwidth 320 Mbps
AI Series DeepinMind Pro
IDS-9632NXI-P16_Datasheet.pdf
