TP-Link EAP615GP-Wall Omada AX1800 Wi-Fi 6 GPON Wall Plate Access Point

Price:

$ 156.00


TP-Link EAP610 Omada AX1800 Wi-Fi 6 Dual-Band Ceiling Access Point
TP-Link EAP610 Omada AX1800 Wi-Fi 6 Dual-Band Ceiling Access Point
$ 158.09
$ 203.32 (22% OFF)
TP-Link EAP625GP-Wall Omada AX1800 Wi-Fi 6 Wall Plate GPON Access Point with PoE Out
TP-Link EAP625GP-Wall Omada AX1800 Wi-Fi 6 Wall Plate GPON Access Point with PoE Out
$ 129.81
$ 129.81

TP-Link EAP615GP-Wall Omada AX1800 Wi-Fi 6 GPON Wall Plate Access Point

https://arcip.com.au/web/image/product.template/8067/image_1920?unique=713cb58

The TP-Link EAP615GP-Wall is an Omada AX1800 Wi-Fi 6 wall-mount GPON access point designed for fibre-to-the-room and fibre-to-the-home projects such as hotels and MDUs. It is part of the Omada Optical Networking Solution with Omada OLTs, ONUs, switches and gateways. One SC/APC GPON port (ITU-T G.984.x, G.988, Class B+, 2.488 Gbps down / 1.244 Gbps up over single-mode fibre up to 20 km) feeds 1201 Mbps 5 GHz and 574 Mbps 2.4 GHz Wi-Fi 6, two Gigabit RJ45 ports and one FXS port for VoIP. It runs from 100-240 V AC, covers up to 50 m², supports 120+ clients, PPSK, multiple portals, Omada mesh and seamless roaming.

$ 156.00 156.0 AUD $ 188.16 incl. GST

Not Available For Sale


  • Brand
  • WiFi Standard

This combination does not exist.

In stock online
WiFi 6 Access Point TP-Link Omada
  • Stock

    Authorised Australian Reseller | Australian Stock | Genuine Local Warranty

  • Instalment
    Buy Now, Pay Later
  • [Warranty Information] Warranty
    Manufacturer Warranty
Estimate delivery
Shipping calculated at checkout
Estimate delivery times: 3-7 business days
Guaranteed Safe Checkout
Guaranteed Safe Checkout
Accepted payments: Google Pay, Apple Pay, Visa, Mastercard and PayPal
SKU
EAP615GP-WALL
Barcode
8885020620528
Tags

The TP-Link EAP615GP-Wall is an Omada AX1800 Wi-Fi 6 wall plate GPON access point for FTTR and FTTH deployments. A single fibre into its SC/APC GPON port (2.488/1.244 Gbps, Class B+, up to 20 km) carries data, voice and video, and the unit provides 1201 Mbps on 5 GHz plus 574 Mbps on 2.4 GHz, two Gigabit RJ45 ports and an FXS phone port. It is mains powered, covers up to 50 m² with 120+ clients and integrates with Omada OLTs, switches and gateways.

EAP615GP-Wall overview

The EAP615GP-Wall is TP-Link's Omada AX1800 Wi-Fi 6 wall plate GPON access point, shown as V1 on the Australian page. TP-Link describes it as specially designed for FTTR/FTTH deployments: it integrates with the Omada Optical Networking Solution to deliver enterprise-grade Gigabit Passive Optical Networking, and with a single fibre it can connect multiple devices such as cameras, PCs and TVs. That makes it ideal, in TP-Link's words, for point-to-multipoint environments like hotels and MDUs. Within the solution, Omada GPON APs, switches, gateways, OLTs and ONUs all support unified management, easy adoption and zero-touch provisioning.

The uplink is the key difference from Ethernet wall plate APs. The GPON port is SC/APC, built to ITU-T G.984.x and G.988 with Class B+ optics, and runs at 2.488 Gbps downstream and 1.244 Gbps upstream over 9/125 µm single-mode fibre with a maximum cable length of 20 km. TP-Link describes one fibre carrying multiple services: wired, wireless, voice, VoIP, data and HD video. On the room side there are two Gigabit RJ45 ports for wired devices and one FXS port (RJ11) for an analogue phone. Because the uplink is fibre, there is no PoE input: the EAP615GP-Wall is mains powered from 100-240 V AC, 50/60 Hz, 0.5 A, with a maximum consumption of 12.2 W.

Wi-Fi is AX1800 Wi-Fi 6 to IEEE 802.11a/b/g/n/ac/ax: up to 1201 Mbps on 5 GHz and 574 Mbps on 2.4 GHz, with 2x2 MU-MIMO on both bands, HE80 (80 MHz) channels and OFDMA. The internal omni antennas are rated at 4 dBi on 2.4 GHz and 6.5 dBi on 5 GHz. TP-Link lists coverage of up to 50 m² (600 ft²) and 120+ concurrent clients; coverage is a laboratory value, and actual capacity depends on the environment and client traffic. Wireless features include 16 SSIDs (eight per band), a guest network, automatic channel assignment, beamforming, band steering, load balance, airtime fairness, rate limits and WMM QoS. Omada mesh and 802.11k/v roaming are listed for a consistently smooth connection.

Installation follows TP-Link's five-step process, starting by detaching the faceplate of the junction box, and a wall mounting kit is included. The unit measures 143 x 86 x 37.6 mm and weighs 0.32 kg, with a 0 to 40 °C operating range. For management, the EAP615GP-Wall works with Omada hardware controllers (OC300, OC200), the Omada software controller and the Omada cloud-based controller, plus the Omada app; cloud access requires one of those controllers and zero-touch provisioning requires the cloud-based controller. The datasheet highlights unified management for OLTs and Omada devices, PPSK, multiple portals, one-click pairing and automatic adoption, and lists Omada Controller V5.15.24 and above and Omada App V5.0 and above. Security includes captive portal authentication, access control, MAC filtering, client isolation, VLAN, rogue AP detection, 802.1X and WPA3. It is CE, FCC and IC certified.

Key features

GPON uplink

SC/APC GPON port, 2.488 Gbps down / 1.244 Gbps up, Class B+, up to 20 km.

One fibre, multiple services

Data, voice, VoIP, HD video, wired and wireless over a single fibre.

AX1800 Wi-Fi 6

1201 Mbps on 5 GHz plus 574 Mbps on 2.4 GHz, 2x2 MU-MIMO and OFDMA.

In-room ports

Two Gigabit RJ45 ports and one FXS phone port.

Mains powered

100-240 V AC input; no PoE needed on a fibre feed. 12.2 W maximum.

50 m² and 120+ clients

Room-level coverage based on laboratory testing.

Omada Optical Networking

Unified management with Omada OLTs, ONUs, switches and gateways.

Mesh, roaming and PPSK

Omada mesh, 802.11k/v roaming, PPSK and multiple portals.

EAP615GP-Wall specifications

At a glance

AX1800 Wi-Fi 6
1 x GPON (SC/APC)
2 x Gigabit RJ45
1 x FXS port
100-240 V AC powered
Up to 50 m²
120+ clients
Omada SDN
EAP615GP-Wall full specifications
Hardware Features
Interface1x GPON Port; 1x FXS Port; 2x Gigabit RJ45 Ports
GPON InterfacePort Type: SC-APC; Standards and Protocols: ITU-984.x, G.988, Class B+; Data Rate: 2.488 Gbps (Downstream); 1.244 Gbps (Upstream); Fibre Type: 9/125 um Single mode; Max. Cable Length: 20 km
ButtonReset; LED
Power Supply100–240V~ 50/60Hz, 0.5A
Max. Power Consumption12.2W
Weight320g
Dimensions ( W x D x H )5.6 × 3.4 × 1.5 in (143 × 86 × 37.6 mm)
AntennaInternal Omni; 2.4 GHz: 2× 4 dBi; 5 GHz: 2× 6.5 dBi
MountingWall Mounting (Kits included)
Management Features
Omada AppYes
Centralised ManagementOmada Hardware Controller (OC300, OC200); Omada Software Controller; Omada Cloud-Based Controller
Cloud AccessYes. Require the use of OC300, OC200, Omada Cloud-Based Controller, or Omada Software Controller.
Email AlertsYes
LED ON/OFF ControlYes
Management MAC Access ControlYes
SNMPv1, v2c, v3
System Logging Local/Remote SyslogSystem Log
SSHYes
Web-based ManagementYes
Zero-Touch ProvisioningYes. Require the use of Omada Cloud-Based Controller.
Wireless Features
Coverage50㎡(600ft²)
Concurrent Clients120+
Wireless StandardsIEEE 802.11 a/b/g/n/ac/ax
Frequency2.4 GHz and 5 GHz
Signal Rate5 GHz: 1201 Mbps; 2.4 GHz: 574 Mbps
Wireless Functions2×2 (2.4G & 5G) MU-MIMO; HE80 (80 MHz Bandwidth); OFDMA; Seamless Roaming; Multiple SSIDs (16 SSIDs, 8 on each band); Enable/Disable SSID Broadcast; Enable/Disable Wireless Radio; Guest Network; Automatic Channel Assignment; Beamforming; Rate Limit; Band Steering; Load Balance; Airtime Fairness; Transmit Power Control (Adjust Transmit Power on dBm); QoS (WMM); RADIUS Accounting; MAC Authentication; Reboot Schedule; Wireless Schedule and Statistics; Static IP/Dynamic IP
Wireless SecurityCaptive Portal Authentication; Access Control; Wireless Mac Address Filtering; Wireless Isolation Between Clients; VLAN; Rogue AP Detection; 802.1X Support; WPA-Personal/Enterprise, WPA2-Personal/Enterprise, WPA3-Personal/Enterprise
Transmission PowerCE:; FCC:
Others
CertificationCE, FCC, IC
System RequirementsMicrosoft Windows XP, Vista, Windows 7, Windows 8, Windows10, Windows11, Linux
EnvironmentOperating Temperature: 0–40 ℃ (32–104 ℉); Storage Temperature: -40–70 ℃ (-40–158 ℉); Operating Humidity: 10–90% RH non-condensing; Storage Humidity: 5–90% RH non-condensing

Source: TP-Link's published specifications for this model (TP-Link Australia product page and datasheet). Some features run only in Standalone Mode or only under an Omada Controller; throughput figures are TP-Link's lab results. TP-Link may change specifications without notice.

What's in the box

  • EAP615GP-Wall
  • Wall Mounting Kit
  • Installation Guide

Source: TP-Link's published package contents.

Who the EAP615GP-Wall is for

Hotels and MDUs on fibre

  • FTTR/FTTH deployments
  • Point-to-multipoint GPON
  • Wi-Fi in each room

Converged in-room services

  • Data, VoIP and HD video on one fibre
  • FXS port for an analogue phone
  • Two Gigabit ports for TVs and PCs

Omada optical networks

  • Unified OLT and Omada management
  • Zero-touch provisioning
  • PPSK and multiple portals

EAP615GP-Wall compared

The EAP615GP-Wall and EAP625GP-Wall are both Omada AX1800 Wi-Fi 6 GPON wall plate APs. The EAP615GP-Wall is mains powered with two Gigabit ports and an FXS port; the EAP625GP-Wall adds 802.3af PoE output on one port. Against the Ethernet-fed EAP615-Wall, the EAP615GP-Wall swaps the PoE uplink for a GPON fibre port.

SpecificationEAP615GP-WallEAP615-Wall
Wi-FiAX1800, 1201 + 574 MbpsAX1800, 1201 + 574 Mbps
Uplink1 x GPON (SC/APC)1 x Gigabit Ethernet (PoE in)
Wired ports2 x Gigabit3 x Gigabit downlinks
Phone port1 x FXSNot listed
Power100-240 V AC802.3af/at PoE
Coverage / clients50 m² / 120+50 m² / 120+
Weight0.32 kg0.22 kg

Source: TP-Link Australia product pages for each model.

Buy the EAP615GP-Wall from ARC IP Networks

ARC IP Networks supplies TP-Link Omada products from Australian stock at competitive prices, with the full manufacturer's warranty, Australia-wide delivery and trade pricing for installers and MSPs.

  • New TP-Link Omada product from Australian stock.
  • Manufacturer warranty: the full TP-Link manufacturer's warranty for this model.
  • Australia-wide delivery to every state and territory.
  • Trade and project pricing: call 1300 100 440 or email info@arcip.com.au.

Frequently asked questions

Straight answers about the EAP615GP-Wall from the ARC IP Networks team.

Last reviewed October 2026.

It is an Omada Wi-Fi 6 wall plate access point fed by GPON fibre, designed for FTTR/FTTH projects such as hotels and multi-dwelling units.

An SC/APC GPON port to ITU-T G.984.x and G.988, Class B+, at 2.488 Gbps downstream and 1.244 Gbps upstream, over single-mode fibre up to 20 km.

No. It is powered from mains, 100-240 V AC, 50/60 Hz. Maximum consumption is 12.2 W.

One GPON port, two Gigabit RJ45 ports and one FXS port for an analogue phone.

AX1800 Wi-Fi 6: up to 1201 Mbps on 5 GHz and 574 Mbps on 2.4 GHz, with 2x2 MU-MIMO and OFDMA.

Up to 50 m² (600 ft²) with 120+ concurrent clients, based on laboratory testing.

The Omada Optical Networking Solution: Omada OLTs, ONUs, switches and gateways, managed by OC300/OC200, the Omada software controller or the cloud-based controller.

Both are AX1800 GPON wall plate APs. The EAP625GP-Wall adds 802.3af PoE output on one port; the EAP615GP-Wall has no PoE output.

Need more than one EAP615GP-Wall for a hotel or MDU fibre-to-the-room project?

Ask ARC IP Networks for volume and project pricing on TP-Link Omada products.
