Cisco AIR-ANT2524V4C-RS= Ceiling Omni Antenna 4-Port 2/4 dBi RP-TNC Self-Identifying

Price:

$ 1,110.23


Cisco AIR-ANT2524DG-R= Aironet Dual-Band Articulating Dipole Antenna 2/4 dBi RP-TNC Grey
Cisco AIR-ANT2524DG-R= Aironet Dual-Band Articulating Dipole Antenna 2/4 dBi RP-TNC Grey
$ 65.29
$ 65.29
Cisco AIR-ANT2535SDW-RS= Aironet Short Dual-Band Dipole Antenna 3/5 dBi RP-TNC White
Cisco AIR-ANT2535SDW-RS= Aironet Short Dual-Band Dipole Antenna 3/5 dBi RP-TNC White
$ 132.62
$ 132.62

Cisco AIR-ANT2524V4C-RS= Ceiling Omni Antenna 4-Port 2/4 dBi RP-TNC Self-Identifying

https://arcip.com.au/web/image/product.template/11656/image_1920?unique=bb4c154

Cisco AIR-ANT2524V4C-RS= Aironet 4-port dual-band ceiling-mount omnidirectional self-identifying antenna. 2.400–2.484 GHz and 5.150–5.850 GHz, 2 dBi at 2.4 GHz and 4 dBi at 5 GHz, elevation beamwidth 69 degrees at 2.4 GHz and 60 degrees at 5 GHz. Four 91 cm plenum-rated cables with RP-TNC male connectors, 18.4 x 18.4 x 2.5 cm, ceiling mount hardware included. For Aironet 1830, 1850, 2800, 3800 and Catalyst 9115AX, 9120AX and 9130AX access points; Catalyst 9130AXE via AIR-CAB002-D8-R=. Genuine Cisco from ARC IP Networks, a Cisco Registered Partner.

$ 1,110.23 1110.23 AUD $ 1,110.23 incl. GST

Not Available For Sale


  • Brand

This combination does not exist.

  • Stock

    Authorised Australian Reseller | Australian Stock | Genuine Local Warranty

  • Instalment
    Buy Now, Pay Later
  • [Warranty Information] Warranty
    Manufacturer Warranty
Estimate delivery
Shipping calculated at checkout
Estimate delivery times: 3-7 business days
Guaranteed Safe Checkout
Guaranteed Safe Checkout
Accepted payments: Google Pay, Apple Pay, Visa, Mastercard and PayPal
SKU
AIR-ANT2524V4C-RS=

Cisco AIR-ANT2524V4C-RS= at a glance

The Cisco AIR-ANT2524V4C-RS= is a 4-port, dual-band, ceiling-mount omnidirectional antenna for indoor access points with external antenna ports. It gives 2 dBi at 2.4 GHz and 4 dBi at 5 GHz, has four 91 cm plenum-rated cables with RP-TNC connectors, and is a self-identifying antenna.

ARC IP Networks is a Cisco Registered Partner in Australia. We supply the genuine Cisco AIR-ANT2524V4C-RS= through Cisco's authorised Australian distribution, with a GST tax invoice on every order.

Bands2.4 / 5 GHz
Gain2 / 4 dBi
Ports4 x RP-TNC
MountCeiling

Best for

  • Moving antennas off the access point to a ceiling position in offices and venues
  • Clean ceiling installs where the access point sits above the ceiling or in a cabinet
  • Catalyst 9130AXE deployments using the DART-8 breakout cable

Key features

Ceiling-mount omnidirectional antenna with four dual-band elements.

Frequency range 2.400 to 2.484 GHz and 5.150 to 5.850 GHz.

Gain of 2 dBi at 2.4 GHz and 4 dBi at 5 GHz.

Elevation 3 dB beamwidth of 69 degrees at 2.4 GHz and 60 degrees at 5 GHz.

Four plenum-rated 91 cm pigtail cables with RP-TNC male connectors.

Ceiling mount hardware included.

Self-identifying antenna; Cisco supports SIA from IOS XE 17.5.1 on C9800 controllers.

Connects to the Catalyst 9130AXE through the AIR-CAB002-D8-R= breakout cable.

Cisco AIR-ANT2524V4C-RS= specifications

Cisco AIR-ANT2524V4C-RS= technical specifications
SpecificationValue
RF
Antenna typeOmnidirectional, 4 ports (all dual band)
Frequency range2.400–2.484 GHz; 5.150–5.850 GHz
Gain2 dBi (2.4 GHz); 4 dBi (5 GHz)
PolarisationLinear
Elevation 3 dB beamwidth69° (2.4 GHz); 60° (5 GHz)
VSWR2:1
Physical
Connectors4 x RP-TNC male
Cables91 cm, plenum rated
Dimensions18.4 x 18.4 x 2.5 cm
MountingCeiling (hardware included)
Compatibility
Access pointsAironet 1830, 1850, 2800 and 3800 Series and Catalyst 9115AX, 9120AX and 9130AX Series
Catalyst 9130AXEVia AIR-CAB002-D8-R= breakout cable
Self-identificationSupported from IOS XE 17.5.1 on C9800 controllers

Figures from Cisco's official data sheet.

The Cisco AIR-ANT2524V4C-RS= in depth

Four-port ceiling omni

This antenna puts four dual-band elements in one 18.4 x 18.4 cm ceiling housing, with 2 dBi at 2.4 GHz and 4 dBi at 5 GHz. Four 91 cm plenum-rated cables run to the access point RP-TNC ports.

Self-identifying

The RS version contains self-identifying circuitry so a Catalyst 9800 controller running IOS XE 17.5.1 or later can recognise the antenna and its gain automatically.

Frequently asked questions

Straight answers about the Cisco AIR-ANT2524V4C-RS= from the ARC IP Networks team. Last reviewed October 2026.

Cisco designs it for access points with dual-band ports, such as the Aironet 1830, 1850, 2800 and 3800 Series and Catalyst 9115AX, 9120AX and 9130AX Series. The Catalyst 9130AXE connects through the AIR-CAB002-D8-R= cable.

It has four plenum-rated pigtail cables, each 91 cm, with RP-TNC male connectors.

Yes. Cisco states the antenna comes with ceiling mount hardware.

The antenna carries circuitry that lets the system detect it and configure it automatically. Cisco supports self-identifying antennas from IOS XE 17.5.1 on C9800 controllers.

2 dBi at 2.4 GHz and 4 dBi at 5 GHz, omnidirectional.

ARC IP Networks is a Cisco Registered Partner and supplies the genuine Cisco AIR-ANT2524V4C-RS= through Cisco's authorised Australian distribution, with a GST tax invoice.
