QNAP TS-433EU 4-Bay 1U Short-Depth Rackmount NAS, ARM Cortex-A55 Quad-Core 2.0GHz, 4GB, 2 x 2.5GbE, NPU

Price:

$ 1,289.18


QNAP TS-433-4G 4-Bay NAS, ARM Cortex-A55 Quad-Core 2.0GHz, 4GB RAM, 2.5GbE + GbE, NPU
QNAP TS-433-4G 4-Bay NAS, ARM Cortex-A55 Quad-Core 2.0GHz, 4GB RAM, 2.5GbE + GbE, NPU
$ 779.79
$ 779.79
QNAP TS-435XEU-4G 4-Bay 1U Short Depth Rackmount NAS, ARM Quad-Core 2.2GHz, 4GB, 2 x 10GbE SFP+, 2 x 2.5GbE, 2 x M.2
QNAP TS-435XEU-4G 4-Bay 1U Short Depth Rackmount NAS, ARM Quad-Core 2.2GHz, 4GB, 2 x 10GbE SFP+, 2 x 2.5GbE, 2 x M.2
$ 1,345.28
$ 1,345.28

QNAP TS-433EU 4-Bay 1U Short-Depth Rackmount NAS, ARM Cortex-A55 Quad-Core 2.0GHz, 4GB, 2 x 2.5GbE, NPU

https://arcip.com.au/web/image/product.template/8338/image_1920?unique=874d354

QNAP TS-433EU 4-bay 1U short-depth rackmount NAS, 292.3 mm deep. ARM Cortex-A55 64-bit quad-core 2.0GHz CPU with Mali-G52 GPU and NPU, 4GB on-board RAM (non-expandable). 4 x 3.5-inch SATA 6Gb/s bays (also 2.5-inch SATA SSD), drives not included. 2 x 2.5GbE, 2 x USB 3.2 Gen 1. AES hardware encryption, SMB signing acceleration, Qsync, backup and surveillance apps. 60W PSU, 3 x 40mm fans. 3-year warranty, extendable up to 5 years. Genuine QNAP from ARC IP Networks, authorised QNAP reseller with Australian stock.

$ 1,289.18 1289.18 AUD $ 1,289.18 incl. GST

Not Available For Sale


  • Brand

This combination does not exist.

In stock online
  • Stock

    Authorised Australian Reseller | Australian Stock | Genuine Local Warranty

  • Instalment
    Buy Now, Pay Later
  • [Warranty Information] Warranty
    Manufacturer Warranty
Estimate delivery
Shipping calculated at checkout
Estimate delivery times: 3-7 business days
Guaranteed Safe Checkout
Guaranteed Safe Checkout
Accepted payments: Google Pay, Apple Pay, Visa, Mastercard and PayPal
SKU
TS-433EU
Barcode
4711103085943

QNAP TS-433EU at a glance

The QNAP TS-433EU is a 4-bay 1U short-depth rackmount NAS with an ARM Cortex-A55 quad-core 2.0GHz processor, 4GB on-board RAM, a built-in NPU and two 2.5GbE ports. Its chassis is only 292.3 mm deep for space-limited racks, and it carries a 3-year standard warranty.

ARC IP Networks is an authorised QNAP reseller in Australia. We supply the genuine QNAP TS-433EU from Australian stock, with a GST tax invoice on every order.

Drive bays4 x 3.5-inch SATA
Form factor1U short depth (292.3 mm)
CPUCortex-A55 4-core 2.0GHz
Network2 x 2.5GbE

Best for

  • Space-limited racks in factories, small offices, AV rooms and surveillance rooms
  • Small business file server with backup and real-time sync
  • NAS-hosted surveillance supporting over 8000 ONVIF cameras

Key features

1U short-depth rackmount chassis only 292.3 mm deep.

ARM Cortex-A55 64-bit quad-core 2.0GHz processor with Mali-G52 graphics.

4GB on-board RAM (non-expandable).

Four 3.5-inch SATA 6Gb/s bays that also accept 2.5-inch SATA SSDs.

Two 2.5GbE ports as standard.

Built-in NPU boosts AI image recognition and reduces CPU workload.

AES hardware-accelerated encryption and SMB signing acceleration.

Windows AD, Azure AD and LDAP support, with QVPN and QuWAN SD-WAN.

Two USB 3.2 Gen 1 ports.

QNAP TS-433EU specifications

QNAP TS-433EU technical specifications
SpecificationValue
Processor and memory
CPUARM 4-core Cortex-A55 2.0GHz
Architecture64-bit ARM
GraphicsMali-G52
Encryption engineYes
Hardware-accelerated transcodingYes
NPUYes
System memory4 GB on board (non-expandable); some RAM reserved as shared graphics memory
Flash memory4 GB (dual boot OS protection)
Storage
Drive bays4 x 3.5-inch SATA 6Gb/s, 3Gb/s
Drive compatibility3.5-inch SATA HDD; 2.5-inch SATA SSD
Hot-swappableYes
Connectivity
2.5GbE ports2 (2.5G/1G/100M)
Wake on LANYes
Jumbo frameYes
USB 3.2 Gen 12
Physical
Form factor1U Short Depth Rackmount
Dimensions (HxWxD)43.3 × 430 × 292.3 mm
LED indicatorsSystem Status, LAN, USB, HDD1~4
ButtonsPower, Reset
Fans3 x 40mm, 12VDC
Kensington security slotYes
Power and environment
Power supply60W, 100-240VAC
Power consumption (disk standby)9.32 W
Power consumption (operating, typical)23.74 W, tested with drives fully populated
Operating temperature0 - 40 °C
Storage temperature-20 - 70 °C
Relative humidity5-95% RH non-condensing
Warranty and limits
Standard warranty3 years
Max concurrent CIFS connections (max memory)200

Figures from QNAP's official product page and hardware specifications.

The QNAP TS-433EU in depth

Short-depth 1U chassis

At only 292.3 mm deep, the TS-433eU fits space-limited environments such as factories, small offices, audiovisual rooms and surveillance rooms, maximising rack space. It comes with two 2.5GbE ports as standard to avoid the bottleneck of 1GbE-only NAS.

Efficient ARM with NPU

An energy-efficient Cortex-A55 quad-core CPU and 4GB RAM handle multitasking, AES hardware encryption protects data, and the NPU accelerates AI image recognition in QuMagie. In QNAP's testing it reached 282 MB/s read and 286 MB/s write over 1 x 2.5GbE.

Business backup and security

Backup apps support Rsync, FTP and CIFS/SMB with secondary backup and restore, Qsync keeps teams in sync, and Qsirch adds AI-powered search. QVPN, QuWAN SD-WAN, AD/LDAP integration and Security Center help secure the NAS, and DA Drive Analyzer predicts drive failures.

Frequently asked questions

Straight answers about the QNAP TS-433EU from the ARC IP Networks team. Last reviewed October 2026.

It is a 1U short-depth unit measuring 43.3 × 430 × 292.3 mm (HxWxD).

It has two 2.5GbE ports (2.5G/1G/100M) and two USB 3.2 Gen 1 ports.

No. It has 4GB on-board RAM that is non-expandable.

QNAP lists the RAIL-B02 rail kit and the RAIL-S01 short-depth rail kit among its optional accessories; a rail kit is not stated as included.

It is backed by a 3-year warranty, and QNAP offers warranty extensions up to 5 years.

ARC IP Networks is an authorised QNAP reseller and supplies the TS-433EU from Australian stock with a GST tax invoice.
