QNAP TL-R1620SDC at a glance

The QNAP TL-R1620SDC is a 16-bay 3U SAS 12Gb/s JBOD with two controllers, built to expand QNAP dual-controller NAS running QES 2.1.1 or later. Each controller has three Mini-SAS HD (SFF-8644) wide ports for up to 48Gbps, and redundant cross-loop cabling keeps the expansion reachable if a path disconnects. It has dual 550W power supplies.

ARC IP Networks is an authorised QNAP reseller in Australia. We supply the genuine QNAP TL-R1620SDC from Australian stock, with a GST tax invoice on every order.

Drive bays16 x 3.5-inch SAS
Host interface3 x SFF-8644 per controller
DesignDual controller (HA)
Power2 x 550W redundant

Best for

  • Expanding QNAP dual-controller QES NAS for mission-critical storage
  • Redundant cross-loop JBOD configurations with path failover
  • Enterprise capacity growth without interrupting service

Key features

16 x 3.5-inch bays for 3.5-inch and 2.5-inch SAS 12Gb/s or 6Gb/s drives; shipped without drives.

Dual-controller design with three 12Gb/s SAS 3.0 (4-wide) Mini-SAS HD SFF-8644 ports per controller.

Each SAS wide port combines four 12Gb/s channels for up to 48Gbps bandwidth.

Redundant cross-loop configuration gives expansion units redundant paths to the base NAS.

Low-power 28nm SAS35x28R SAS expander with Broadcom SAS DataBolt bandwidth optimisation.

Drives appear to the host NAS as local drives; configure RAID groups, storage pools and snapshots in Storage Manager.

Managed via the NAS QES OS and JBOD Manager for Windows; OLED button and status LEDs on the front.

Dual 550W power supplies, three 80mm fans and a 5-year warranty at no extra cost.

QNAP TL-R1620SDC specifications

QNAP TL-R1620SDC technical specifications
SpecificationValue
Storage
JBOD connection interfaceSAS
Drive bays16 x 3.5-inch (shipped without drives)
Drive compatibility3.5-inch SAS 12Gb/s, 6Gb/s HDDs; 2.5-inch SAS 12Gb/s, 6Gb/s HDDs and SSDs
Drive typesOne disk type (HDD or SSD) per RAID group
Connectivity
Host interface3 x 12Gb/s SAS 3.0 wide ports (4-wide port) Mini-SAS HD (SFF-8644) for each controller
BandwidthUp to 48Gbps per wide port
SAS expander28nm SAS35x28R
Included cablesTwo Mini-SAS SFF-8644 to SFF-8644 cables
Host requirementDual-controller QNAP NAS with QES 2.1.1 or later
Management
Managed viaNAS QES OS and JBOD Manager for Windows
Physical
Form factor3U Rackmount
Dimensions (H x W x D)131.3 x 482.2 x 425.3 mm (excludes ear hook and protruding PSU)
LED indicatorsHDD 1-16, Status, Power, Fan, Temperature, SAS connector status
ButtonsPower, OLED
Fans3 x 80mm, 12VDC
Power and environment
Power supply550W (x2), 100-240V
Power consumption (operating, typical)212.24 W (drives fully populated)
Operating temperature0 - 40 °C
Storage temperature-20 - 70 °C
Relative humidity5-95% RH non-condensing
Warranty
Standard warranty5 years

Figures from QNAP's official product page and hardware specifications.

The QNAP TL-R1620SDC in depth

Expansion for dual-controller QES NAS

The TL-R1620SDC is designed for QNAP's dual-controller NAS running QES. Cabled in a redundant cross loop, every expansion unit keeps a path to the base NAS even if one or more connections drop, protecting mission-critical workloads.

Plug in and manage from the host

Once connected and powered on, the host NAS sees the TL-R1620SDC drives as newly installed local drives, ready for RAID groups, storage pools and snapshots in Storage Manager. DataBolt lets 6Gb/s drives benefit from the host's 12Gb/s SAS links.

Frequently asked questions

Straight answers about the QNAP TL-R1620SDC from the ARC IP Networks team. Last reviewed October 2026.

QNAP requires a dual-controller NAS with QES 2.1.1 or later, using Mini-SAS HD (SFF-8644) or Mini-SAS (SFF-8088) ports or a PCIe SAS expansion card.

QNAP's specification lists management via the NAS QES OS and JBOD Manager for Windows; QTS and QuTS hero hosts are not listed for this model.

Each of its two controllers has three 12Gb/s SAS 3.0 Mini-SAS HD (SFF-8644) wide ports, and each wide port provides up to 48Gbps.

QNAP states two Mini-SAS SFF-8644 to SFF-8644 cables are included; additional cables depend on how the JBODs are connected.

QNAP backs the TL-R1620SDC with a 5-year warranty at no extra cost.

ARC IP Networks is an authorised QNAP reseller and supplies the TL-R1620SDC from Australian stock with a GST tax invoice.
