TP-Link MC210CS Gigabit Single-Mode Media Converter

Price:

$ 49.01


TP-Link AC50 Wireless Controller
TP-Link AC50 Wireless Controller
$ 125.44
$ 125.44
TP-Link TL-SF1024 24-Port 10/100Mbps Rackmount Switch
TP-Link TL-SF1024 24-Port 10/100Mbps Rackmount Switch
$ 138.57
$ 138.57

TP-Link MC210CS Gigabit Single-Mode Media Converter

https://arcip.com.au/web/image/product.template/9137/image_1920?unique=b6a9817

The TP-Link MC210CS is an Omada Gigabit single-mode media converter that converts 1000BASE-LX fibre to 1000BASE-T copper media or vice versa. It complies with IEEE 802.3i, 802.3u, 802.3ab, 802.3z and 802.3x, has 2 x 1000M SC/UPC fibre ports and 1 x 10/100/1000M RJ45 port with auto-MDI/MDIX, and works at 1310 nm on transmit and receive. TP-Link rates it for up to 20 km over single-mode fibre with auto-negotiation of half/full duplex. It can be used standalone or in the MC1400 chassis, is powered by an external adapter and has PWR and Link/Act LEDs.

$ 49.01 49.01 AUD $ 49.01 incl. GST

Not Available For Sale


  • Brand

This combination does not exist.

In stock online
  • Stock

    Authorised Australian Reseller | Australian Stock | Genuine Local Warranty

  • Instalment
    Buy Now, Pay Later
  • [Warranty Information] Warranty
    Manufacturer Warranty
Estimate delivery
Shipping calculated at checkout
Estimate delivery times: 3-7 business days
Guaranteed Safe Checkout
Guaranteed Safe Checkout
Accepted payments: Google Pay, Apple Pay, Visa, Mastercard and PayPal
SKU
TL-MC210CS
Barcode
1210002611053

The TP-Link MC210CS is an Omada Gigabit single-mode media converter. It converts 1000BASE-LX fibre to 1000BASE-T copper and back, with SC/UPC fibre connections and one 10/100/1000 Mbps RJ45 port, working at 1310 nm for up to 20 km on single-mode fibre. It works standalone or in TP-Link's MC1400 chassis and draws a listed 1.8 W maximum from an external adapter.

MC210CS overview

The MC210CS is TP-Link's Omada Gigabit single-mode media converter. TP-Link describes it as a media converter designed to convert 1000BASE-LX fibre to 1000BASE-T copper media or vice versa, designed under the IEEE 802.3ab 1000BASE-T and IEEE 802.3z 1000BASE-LX standards; the full standards list adds IEEE 802.3i 10BASE-T, 802.3u 100BASE-T and 802.3x flow control. It is designed for single-mode fibre cable using the SC-type connector, with TP-Link listing two 1000M SC/UPC ports and one 10/100/1000M RJ45 port with auto-MDI/MDIX. TP-Link says it supports the longwave (LX) laser specification at a full wire-speed forwarding rate and works at 1310 nm on both transmitting and receiving data.

Reach is the reason to choose single-mode. TP-Link says the MC210CS will transmit at extended fibre-optic distances using single-mode fibre of up to 20 kilometres, ten times the 2 km TP-Link lists for its multi-mode MC100CM, and it runs at Gigabit rather than 100 Mbps. That makes it suitable for linking buildings across a site, connecting a remote shed or gatehouse, or carrying a Gigabit uplink from a distant switch back to the core. On the copper side, 1000BASE-T runs over UTP Category 5 or 5e cable up to 100 m or EIA/TIA-568 100 ohm STP up to 100 m. The converter auto-negotiates half-duplex or full-duplex transfer mode.

TP-Link notes that the MC210CS can be used as a standalone device with no chassis required, or with the MC1400 chassis, with auto-MDI/MDI-X on the TX port and front-panel status LEDs. The product page lists PWR and Link/Act LEDs; the series datasheet lists PWR, FX Link/Act and TP Link/Act. Power is from an external power adapter, which is in the box, and the product page lists maximum power consumption of 1.8 W; TP-Link's combined media converter datasheet lists 2.04 W for the MC210CS v7.20, so allow for the higher figure if budgeting power. The AU product page shows hardware version 7.20.

The MC210CS measures 94.5 x 73.0 x 27.0 mm (3.7 x 2.9 x 1.1 in), the same housing as TP-Link's other MC-series converters. It is rated for operation from 0 to 50 degrees C and storage from -40 to 70 degrees C, with 10 to 90% operating and 5 to 90% storage humidity, non-condensing. The product page lists FCC, CE and RoHS safety and emission approvals, and the datasheet lists CE and FCC certification. The box contains the MC210CS, a power adapter and an installation guide. TP-Link's datasheet places the MC210CS in a family that also includes the multi-mode Gigabit MC200CM and the SFP-based MC220L, so check the fibre type before ordering: the MC210CS is for single-mode fibre with SC connectors.

Key features

Gigabit fibre to copper

Converts 1000BASE-LX fibre to 1000BASE-T copper and back.

Single-mode, up to 20 km

Extends fibre distance up to 20 km on single-mode fibre.

SC/UPC fibre ports

2 x 1000M SC/UPC ports and 1 x 10/100/1000M RJ45 port with auto-MDI/MDIX.

1310 nm LX laser

Longwave laser at 1310 nm on transmit and receive, at full wire speed.

Auto duplex

Auto-negotiation of half-duplex or full-duplex transfer mode.

Standalone or chassis

Use on its own or in TP-Link's MC1400 chassis.

Status LEDs

Front-panel LEDs for power and link activity.

MC210CS specifications

At a glance

Gigabit
Single-mode fibre
SC/UPC
1 x 10/100/1000 RJ45
1310 nm
Up to 20 km
1.8 W max (page)
MC1400 chassis fit
MC210CS full specifications
Media Converter & Module
Standards and ProtocolsIEEE 802.3i 10BASE-T; IEEE 802.3u 100BASE-T; IEEE 802.3ab 1000BASE-T; IEEE 802.3z 1000BASE-LX; IEEE 802.3x Flow Control
Basic FunctionAuto-negotiation of Half-Duplex / Full-Duplex transfer mode Extends fibre distance up to 20km
Interface2× 1000M SC/UPC ports; 1× 10/100/1000M RJ45 port (Auto MDI/MDIX)
Wave Length1310nm
Network Media 1000BASE-LXSingle-mode Fibre
Network Media 1000BASE-TUTP category 5, 5e cable (maximum 100m); EIA/TIA-568 100Ω STP (maximum 100m)
Dimensions ( W x D x H )3.7 2.9 1.1 in. (94.5 73.0 27.0 mm)
Power SupplyExternal Power Adapter
Max. Power Consumption1.8W
LEDPWR, Link/Act
Safety & EmissionFCC, CE, RoHS
EnvironmentOperating Temperature: 0℃~50℃ (32℉~122℉); Storage Temperature: -40℃~70℃ (-40℉~158℉); Operating Humidity: 10%~90% non-condensing; Storage Humidity: 5%~90% non-condensing

Source: TP-Link's published specifications for this model (TP-Link Australia product page and datasheet). Some features run only in Standalone Mode or only under an Omada Controller; throughput figures are TP-Link's lab results. TP-Link may change specifications without notice.

What's in the box

  • MC210CS
  • Power Adapter
  • Installation Guide

Source: TP-Link's published package contents.

Who the MC210CS is for

Inter-building Gigabit links

  • Up to 20 km on single-mode fibre
  • Full wire-speed Gigabit
  • 1000BASE-LX standard

Remote switch uplinks

  • 10/100/1000 Mbps RJ45
  • Auto-MDI/MDIX
  • Auto duplex negotiation

Comms rooms

  • Fits the MC1400 chassis
  • Or standalone
  • Compact 94.5 x 73 x 27 mm

MC210CS compared

The MC210CS and MC100CM use the same compact MC-series housing and both fit the MC1400 chassis. The MC210CS is the Gigabit single-mode model for distances up to 20 km; the MC100CM is the 10/100 Mbps multi-mode model for up to 2 km.

SpecificationMC210CSMC100CM
Speed10/100/1000 Mbps RJ45, 1000BASE-LX fibre10/100 Mbps
Fibre typeSingle-modeMulti-mode
Max fibre distance20 km2 km
Wavelength1310 nm1310 nm
Fibre ports2 x 1000M SC/UPC2 x 100M SC/UPC
Max power consumption1.8 W (page), 2.04 W (datasheet)1.19 W
Operating temperature0 to 50 degrees C0 to 40 degrees C (page)

Source: TP-Link Australia product pages for each model.

Buy the MC210CS from ARC IP Networks

ARC IP Networks supplies TP-Link Omada products from Australian stock at competitive prices, with the full manufacturer's warranty, Australia-wide delivery and trade pricing for installers and MSPs.

  • New TP-Link Omada product from Australian stock.
  • Manufacturer warranty: the full TP-Link manufacturer's warranty for this model.
  • Australia-wide delivery to every state and territory.
  • Trade and project pricing: call 1300 100 440 or email info@arcip.com.au.

Frequently asked questions

Straight answers about the MC210CS from the ARC IP Networks team.

Last reviewed October 2026.

1000BASE-LX single-mode fibre to 1000BASE-T copper Ethernet, or the reverse.

Up to 20 km over single-mode fibre.

SC-type fibre connectors (TP-Link lists 2 x 1000M SC/UPC ports) and one 10/100/1000 Mbps RJ45 port.

It is designed for single-mode fibre. For multi-mode fibre TP-Link offers other models, such as the 10/100 Mbps MC100CM.

1310 nm on both transmit and receive.

Yes. It works standalone or with the MC1400 chassis.

The product page lists 1.8 W maximum; TP-Link's combined datasheet lists 2.04 W for the v7.20 hardware.

The MC210CS, a power adapter and an installation guide.

Need more than one MC210CS for a Gigabit fibre link?
