Ruijie RG-ES205GC-V2 5-Port Gigabit Smart Cloud-Managed Non-PoE Switch, Fanless Metal Desktop

Price:

$ 55.54


Ruijie RG-EG1510XS Reyee 10-Port Multi-Gig Cloud Managed Business Router, 1500 Clients, 2 x 10G SFP+
Ruijie RG-EG1510XS Reyee 10-Port Multi-Gig Cloud Managed Business Router, 1500 Clients, 2 x 10G SFP+
$ 1,035.50
$ 1,035.50
Ruijie RG-ES207GS-AC-OD 7-Port Gigabit Outdoor IP65 Cloud-Managed PoE Switch, 4 x PoE+ 60W, 2 x SFP, AC Input
Ruijie RG-ES207GS-AC-OD 7-Port Gigabit Outdoor IP65 Cloud-Managed PoE Switch, 4 x PoE+ 60W, 2 x SFP, AC Input
$ 204.88
$ 204.88

Ruijie RG-ES205GC-V2 5-Port Gigabit Smart Cloud-Managed Non-PoE Switch, Fanless Metal Desktop

https://arcip.com.au/web/image/product.template/10356/image_1920?unique=306b97f

Ruijie RG-ES205GC-V2 5-port Gigabit smart cloud-managed switch (non-PoE). Five 10/100/1000BASE-T RJ45 ports, 10 Gbps switching capacity, 7.44 Mpps forwarding rate, up to 32 VLANs, 2000 MAC entries, static link aggregation, port isolation, DHCP snooping and storm control. Managed via Ruijie Cloud, Ruijie Reyee App or eWeb, with SON zero-touch provisioning and camera detection. Fanless metal case for wall or desk, 2.5 W maximum power, ±6 kV surge protection on service ports, 0°C to 40°C operation. Genuine Ruijie from ARC IP Networks, authorised Ruijie reseller with Australian stock.

$ 55.54 55.54 AUD $ 55.54 incl. GST

Not Available For Sale


  • Brand
  • Switching Capacity
  • Network Layer
  • Form Factor
  • Port Speed
  • Ports
  • Network Connectivity

This combination does not exist.

Switch PoE Ruijie Cloud Managed Reyee CCTV
  • Stock

    Authorised Australian Reseller | Australian Stock | Genuine Local Warranty

  • Instalment
    Buy Now, Pay Later
  • [Warranty Information] Warranty
    Manufacturer Warranty
Estimate delivery
Shipping calculated at checkout
Estimate delivery times: 3-7 business days
Guaranteed Safe Checkout
Guaranteed Safe Checkout
Accepted payments: Google Pay, Apple Pay, Visa, Mastercard and PayPal
SKU
RG-ES205GC-V2
Barcode
6976915006618
Tags

Ruijie RG-ES205GC-V2 at a glance

The Ruijie RG-ES205GC-V2 is a 5-port Gigabit Layer 2 smart switch from the Reyee range that is managed through Ruijie Cloud, the Reyee App or its local eWeb interface. It offers 10 Gbps switching capacity, up to 32 VLANs and static link aggregation in a fanless metal case drawing at most 2.5 W.

ARC IP Networks is an authorised Ruijie reseller in Australia. We supply the genuine Ruijie RG-ES205GC-V2 from Australian stock, with a GST tax invoice on every order.

Ports5 x Gigabit RJ45
Switching10 Gbps
ManagementRuijie Cloud / App
Surge6 kV service ports

Best for

  • Small offices and shops that want a managed switch visible in Ruijie Cloud
  • Small CCTV installs where the switch should detect cameras and NVRs
  • Desk or wall placement where a silent fanless unit is needed

Key features

Five 10/100/1000BASE-T RJ45 ports with 10 Gbps switching capacity and 7.44 Mpps forwarding.

Managed for life through Ruijie Cloud and the Ruijie Reyee App, or locally through eWeb over HTTP or HTTPS.

SON self-organising network support for zero-touch provisioning alongside other Reyee devices.

Up to 32 IEEE 802.1Q VLANs, static link aggregation and per-interface rate limiting.

Port isolation, DHCP snooping, storm control and a CPU protection policy for a more stable network.

Camera detection, cable test and port mirroring to speed up troubleshooting.

Service ports rated for ±6 kV common-mode surge protection.

Fanless metal case for wall or desk mounting, with a maximum power draw of 2.5 W.

Ruijie RG-ES205GC-V2 specifications

Ruijie RG-ES205GC-V2 technical specifications
SpecificationValue
Ports
10/100/1000BASE-T RJ45 ports5
SFP ports0
PoENone (non-PoE model)
Reset button1
Performance
Switching capacity10 Gbps
Forwarding rate7.44 Mpps
MAC address table2000 entries
Maximum VLANs32
Jumbo frame (MTU)9216 bytes
Flash memory8 MB
Layer 2, reliability and security
IEEE 802.1Q VLANYes
Static link aggregationYes
LACPNo
Rate limiting (inbound/outbound per interface)Yes
Port isolationYes
Storm controlBroadcast, multicast and unknown unicast
DHCP snoopingYes
CPU protection policyYes
IGMP snoopingNo
ACLs / 802.1X / RADIUSNo
802.1p / DSCP traffic classificationNo
Management
Cloud managementRuijie Cloud and Ruijie Reyee App
Local managementeWeb (HTTP/HTTPS)
SON (zero-touch provisioning)Yes
Camera detectionYes
Port mirroringYes
Cable testYes
EEEYes
IPv4 pingYes
DHCP / DNS clientYes
Online upgradeYes
SNMP / LLDP / SyslogNo
Power
Power supplyExternal DC power adapter
Adapter input100 V AC to 240 V AC, 50 Hz to 60 Hz
Adapter output5 V DC, 1 A maximum
Maximum power consumption2.5 W
Physical and environmental
CasingMetal
Dimensions (W x D x H)121 mm x 62 mm x 28 mm
CoolingFanless, natural cooling
MountingWall or desk
Operating temperature0°C to 40°C
Storage temperature–40°C to +70°C
Operating humidity10% to 90% RH (non-condensing)
MTBF200,000 hours
Surge protectionService ports ±6 kV common mode; power connector ±4 kV common mode, ±2 kV differential mode
CertificationCE, CB
In the box and warranty
ContentsSwitch, power cord (1 m), user manual, warranty card
Warranty3 years

Figures from Ruijie's official product page and datasheet.

The Ruijie RG-ES205GC-V2 in depth

A managed 5-port switch for small sites

The RG-ES205GC-V2 brings cloud management to the smallest part of a network. Its five Gigabit ports suit a reception desk, a small shop or an NVR position, and the switch is listed by Ruijie for CCTV, office, hotel, factory and retail use.

Cloud and app control

Through Ruijie Cloud or the Reyee App the switch can be monitored remotely and VLANs configured without a site visit, while SON allows zero-touch provisioning with other Reyee equipment. Ruijie promotes lifetime free cloud management for the Reyee range.

Built to keep running

Ruijie highlights one-click smart protection to prevent common after-sales issues, and the datasheet lists DHCP snooping, port isolation and storm control. The metal case is fanless and the service ports carry 6 kV surge protection.

Frequently asked questions

Straight answers about the Ruijie RG-ES205GC-V2 from the ARC IP Networks team. Last reviewed October 2026.

No. It is the non-PoE model with five 10/100/1000BASE-T RJ45 ports and no SFP port. For powered devices, see the PoE models in the same Reyee smart switch series.

It can be managed through Ruijie Cloud, the Ruijie Reyee App or the local eWeb interface over HTTP or HTTPS. SNMP is not supported.

Up to 32 IEEE 802.1Q VLANs, with a MAC address table of 2000 entries.

Ruijie rates maximum power consumption at 2.5 W, supplied by a 5 V DC power adapter.

Ruijie lists a 3-year warranty for the RG-ES205GC-V2.

ARC IP Networks is an authorised Ruijie reseller and supplies the RG-ES205GC-V2 from Australian stock with a GST tax invoice.

Explore the full Ruijie range: Ruijie Australia hub · Shop all Ruijie Reyee

Buy the Ruijie RG-ES205GC-V2 in Australia

ARC IP Networks is an authorised Ruijie reseller, supplying Ruijie Reyee access points, switches, routers and wireless bridges to businesses, installers and integrators across Australia.

  • Genuine Ruijie with the full manufacturer's warranty, supplied from Australian stock.
  • Australian stock, shipped Australia-wide.
  • Manufacturer's warranty and local help with warranty claims and choosing the right model.
  • GST tax invoice on every order, with trade and project pricing available.

Planning a Ruijie network?

Ask ARC IP Networks for project pricing or a configured quote, or call us to check the right Ruijie model for your site.

Brand Ruijie
Switching Capacity 10 Gbps
Network Layer Layer 2
Form Factor Desktop
Port Speed 5 x 10/100/1000BASE-T
Ports 5 Ports
Network Connectivity Wired
