Ruijie MINI-GBIC-LX-SM1310 1G LX SFP Transceiver Module, 1000BASE-LX, 1310 nm, 10 km, Duplex LC, SMF, DDM

Price:

$ 56.52


Ruijie MINI-GBIC-SX-MM850 1G SX SFP Transceiver Module, 1000BASE-SX, 850 nm, 550 m, Duplex LC, MMF, DDM
Ruijie MINI-GBIC-SX-MM850 1G SX SFP Transceiver Module, 1000BASE-SX, 850 nm, 550 m, Duplex LC, MMF, DDM
$ 50.23
$ 54.66 (8% OFF)
Ruijie RG-POE-AT30 1-Port Gigabit PoE+ Adapter
Ruijie RG-POE-AT30 1-Port Gigabit PoE+ Adapter
$ 38.56
$ 41.97 (8% OFF)

Ruijie MINI-GBIC-LX-SM1310 1G LX SFP Transceiver Module, 1000BASE-LX, 1310 nm, 10 km, Duplex LC, SMF, DDM

https://arcip.com.au/web/image/product.template/5561/image_1920?unique=0938db8

Ruijie MINI-GBIC-LX-SM1310 1G 1000BASE-LX SFP optical transceiver module. 1310 nm wavelength, up to 10 km over single-mode fibre (SMF), duplex LC connector, UPC end face, 1.25 Gbps, DFB laser, PIN receiver, digital diagnostic monitoring (DDM/DOM), hot-pluggable, ≤ 1.5 W power consumption, 0°C to 70°C operating temperature. Conforms to IEEE 802.3, SFF-8472, SFF-8431, SFF-8432 and SFP+ MSA, RoHS compliant. Genuine Ruijie from ARC IP Networks, authorised Ruijie reseller with Australian stock.

$ 56.52 56.52 AUD $ 61.50 incl. GST

Not Available For Sale


  • Brand

This combination does not exist.

In stock online
Ruijie SFP Transceiver Reyee Fibre
  • Stock

    Authorised Australian Reseller | Australian Stock | Genuine Local Warranty

  • Instalment
    Buy Now, Pay Later
  • [Warranty Information] Warranty
    Manufacturer Warranty
Estimate delivery
Shipping calculated at checkout
Estimate delivery times: 3-7 business days
Guaranteed Safe Checkout
Guaranteed Safe Checkout
Accepted payments: Google Pay, Apple Pay, Visa, Mastercard and PayPal
SKU
MINI-GBIC-LX-SM1310
Barcode
6971693278011
Tags

Ruijie MINI-GBIC-LX-SM1310 at a glance

The Ruijie MINI-GBIC-LX-SM1310 is a 1G 1000BASE-LX SFP optical transceiver that runs at 1310 nm over single-mode fibre (SMF) with a duplex LC connector, supporting links of up to 10 km. It is hot-pluggable, supports digital optical monitoring (DDM/DOM) and draws no more than 1.5 W.

ARC IP Networks is an authorised Ruijie reseller in Australia. We supply the genuine Ruijie MINI-GBIC-LX-SM1310 from Australian stock, with a GST tax invoice on every order.

ReachUp to 10 km over SMF
Data rate1.25 Gbps (1G)
ConnectorDuplex LC
DiagnosticsDDM/DOM

Best for

  • Fibre links between buildings up to 10 km over single-mode fibre
  • Campus and site backbones on 1G SFP ports
  • Long camera or access runs where copper cannot reach

Key features

IEEE 1000BASE-LX 1G optical transceiver in the SFP form factor.

Up to 10 km over single-mode fibre (SMF) at 1310 nm.

Duplex LC connector with UPC fibre end face; DFB transmitter and PIN receiver.

Digital optical monitoring (DDM/DOM) for diagnostics.

Hot-pluggable for simplified maintenance.

Maximum power consumption of 1.5 W.

Conforms to IEEE 802.3, SFF-8472, SFF-8431, SFF-8432 and SFP+ MSA.

RoHS compliant with Class 1 laser safety, per Ruijie.

Ruijie MINI-GBIC-LX-SM1310 specifications

Ruijie MINI-GBIC-LX-SM1310 technical specifications
SpecificationValue
Optical interface
StandardIEEE 1000BASE-LX
Data rate1.25 Gbps
Form factorSFP, hot-pluggable
ConnectorDuplex LC
Cable typeSMF
Fibre end faceUltra Physical Contact (UPC)
Reach10 km
Transmitter
Wavelength1310 nm
Laser typeDFB
Max. transmit power (AVG)–3 dBm
Min. transmit power (AVG)–11 dBm
Min. extinction ratio≥ 9 dB
Receiver
Receiver typePIN
Receive sensitivity (OMA)< –19 dBm
Overload optical power (AVG)–3 dBm
Bit error ratio1.00E-12
Monitoring and power
Digital diagnostics (DDM/DOM)Yes
Power consumption≤ 1.5 W
Environment and physical
Operating temperature0°C to 70°C
Storage temperature–40°C to +85°C
Operating / storage humidity10% to 90% RH
Dimensions (W x D x H)56.5 mm x 13.5 mm x 8.5 mm
Compliance
StandardsIEEE 802.3, SFF-8472, SFF-8431, SFF-8432, SFP+ MSA
OtherRoHS; Class 1 laser safety (per Ruijie product page)
Warranty
Ruijie warranty3 years

Figures from Ruijie's official product page and datasheet.

The Ruijie MINI-GBIC-LX-SM1310 in depth

1G LX optics from Ruijie

The MINI-GBIC-LX-SM1310 is part of Ruijie's RG 1000BASE series of optical transceivers, used to connect switches, routers, servers and network interface cards. It follows IEEE 1000BASE-LX optical specifications at 1310 nm.

Reach and cabling

Ruijie rates the module for links of up to 10 km over single-mode fibre (SMF) with a duplex LC connector. Transmit power is –11 dBm to –3 dBm and receive sensitivity is < –19 dBm.

Easy to maintain

The module is hot-pluggable and supports digital diagnostic monitoring, so optical power and module health can be checked from a supported host.

Frequently asked questions

Straight answers about the Ruijie MINI-GBIC-LX-SM1310 from the ARC IP Networks team. Last reviewed October 2026.

Up to 10 km over single-mode fibre (SMF), per Ruijie's datasheet.

Single-mode. It uses SMF with a duplex LC connector at 1310 nm.

Yes. Ruijie lists digital diagnostic monitoring (DDM/DOM) support.

0°C to 70°C operating and –40°C to +85°C storage.

Ruijie's Reyee and consumer product warranty summary lists 3 years for the MINI-GBIC-LX-SM1310.

ARC IP Networks is an authorised Ruijie reseller and supplies the MINI-GBIC-LX-SM1310 from Australian stock with a GST tax invoice.

Related Ruijie products

Explore the full Ruijie range: Ruijie Australia hub · Shop all Ruijie Reyee

Buy the Ruijie MINI-GBIC-LX-SM1310 in Australia

ARC IP Networks is an authorised Ruijie reseller, supplying Ruijie Reyee access points, switches, routers and wireless bridges to businesses, installers and integrators across Australia.

  • Genuine Ruijie with the full manufacturer's warranty, supplied from Australian stock.
  • Australian stock, shipped Australia-wide.
  • Manufacturer's warranty and local help with warranty claims and choosing the right model.
  • GST tax invoice on every order, with trade and project pricing available.

Planning a Ruijie network?

Ask ARC IP Networks for project pricing or a configured quote, or call us to check the right Ruijie model for your site.

Brand Ruijie
20251226-RG_1000BASE_Series_Optical_Transceivers_Datasheet_-20240426___1_.pdf
