Cisco IE-3500H-8T-E IE3500 Heavy Duty IP67 Industrial Switch, 8x GbE M12 X-Coded, Network Essentials

Price:

$ 8,840.00


Cisco IE-3500-8P3S-E IE3500 Rugged Modular Industrial Switch, 8x GbE PoE+, 3x GE SFP, Network Essentials
Cisco IE-3500-8P3S-E IE3500 Rugged Modular Industrial Switch, 8x GbE PoE+, 3x GE SFP, Network Essentials
$ 9,613.04
$ 9,613.04
Cisco IE-4000-8T4G-E Industrial Ethernet 4000 DIN-Rail Switch, 8x FE Copper, 4x GE Combo Uplinks, LAN Base
Cisco IE-4000-8T4G-E Industrial Ethernet 4000 DIN-Rail Switch, 8x FE Copper, 4x GE Combo Uplinks, LAN Base
$ 12,668.49
$ 12,668.49

Cisco IE-3500H-8T-E IE3500 Heavy Duty IP67 Industrial Switch, 8x GbE M12 X-Coded, Network Essentials

https://arcip.com.au/web/image/product.template/13094/image_1920?unique=055e425

Cisco IE3500 Heavy Duty IE-3500H-8T-E industrial Ethernet switch. 8 x 1000/100/10M M12 X-coded ports, IP66/IP67 and UL 50E Type 4X sealed housing for wall mounting. 12-48VDC single input, 38W. 24000 MAC addresses, 5.1 GB flash, line-rate forwarding. Cisco IOS XE Network Essentials with TSN frame preemption, MRP, REP, MACsec-128 and IOx for Cyber Vision, Secure Equipment Access and ThousandEyes. -40 to 75°C with 200 LFM airflow. 5-year limited hardware warranty. Genuine Cisco from ARC IP Networks, a Cisco Registered Partner.

$ 8,840.00 8840.0 AUD $ 8,840.00 incl. GST

Not Available For Sale


  • Brand

This combination does not exist.

  • Stock

    Authorised Australian Reseller | Australian Stock | Genuine Local Warranty

  • Instalment
    Buy Now, Pay Later
  • [Warranty Information] Warranty
    Manufacturer Warranty
Estimate delivery
Shipping calculated at checkout
Estimate delivery times: 3-7 business days
Guaranteed Safe Checkout
Guaranteed Safe Checkout
Accepted payments: Google Pay, Apple Pay, Visa, Mastercard and PayPal
SKU
IE-3500H-8T-E

Cisco IE-3500H-8T-E at a glance

The Cisco IE3500 Heavy Duty IE-3500H-8T-E is a sealed IP66/IP67 industrial switch with 8 Gigabit M12 X-coded ports. It runs Cisco IOS XE Network Essentials with TSN frame preemption and IOx edge compute, takes 12-48VDC from a single source and is rated to -40 to 75°C with 200 LFM airflow.

ARC IP Networks is a Cisco Registered Partner in Australia. We supply the genuine Cisco IE-3500H-8T-E through Cisco's authorised Australian distribution, with a GST tax invoice on every order.

Ports8x GbE M12 X-code
IngressIP66/IP67, Type 4X
Input voltage12-48VDC
LicenceNetwork Essentials

Best for

  • Gigabit M12 networking on machines in exposed locations
  • Time-sensitive automation using TSN frame preemption
  • Edge apps such as Cisco Cyber Vision or ThousandEyes at the machine

Key features

8 x 10/100/1000 M12 X-coded ports in an IP66/IP67, UL 50E Type 4X housing.

Line-rate forwarding, 24000 MAC addresses and 1024 active VLANs.

5.1 GB user flash and an optional 16 GB SD card.

TSN frame preemption (IEEE 802.1Qbu and 802.3br).

MRP, REP and Fast REP ring redundancy.

IOx hosting for Cisco Cyber Vision, Secure Equipment Access and ThousandEyes Enterprise Agent.

Secure Boot with a hardware root of trust in the Cisco Trust Anchor Module, plus MACsec-128.

Network Essentials includes OSPF, RIP, static routing and PBR.

Cisco IE-3500H-8T-E specifications

Cisco IE-3500H-8T-E technical specifications
SpecificationValue
Ports
Ethernet ports8x 1000/100/10M M12 X-coded
Console1, M12 A-coded 5-pin
PoENot applicable
Performance
Forwarding rateLine rate for all ports, all packet sizes
Unicast MAC addresses24000
Active VLANs1024 (4096 VLAN IDs)
ACEs (PACLs)1536
Jumbo frames9198 bytes
Hardware
Flash (user accessible)5.1 GB
SD cardOptional, 16 GB (not shipped)
MTBF473,949 hours (Telcordia Issue 4)
Power
Power inputMini-change, single power source
Input voltage12-48VDC (absolute)
Input current3.1A
Power consumption38W (measured at 12V)
Software
LicenceNetwork Essentials (perpetual)
RoutingStatic, OSPF, RIP, PBR
RedundancyMRP, REP, Fast REP
TSNIEEE 802.1Qbu, 802.3br frame preemption
Physical and environment
Dimensions24.33 x 20.07 x 8.03 cm
MountingWall
Ingress protectionIP66/IP67, UL 50E Type 4X
Operating temperature-40 to 75°C (200 LFM airflow)
Storage temperature-40 to 85°C
Humidity5% to 95% noncondensing
Compliance and warranty
SafetyIEC 62368-1, UL 61010-2-201
EmissionsClass A (EN 55032)
Warranty5-year limited hardware warranty

Figures from Cisco's official data sheet.

The Cisco IE-3500H-8T-E in depth

Gigabit M12 switching on the machine

The IE3500 Heavy Duty Series is Cisco's sealed, wall-mount industrial switch range. The IE-3500H-8T-E has 8 Gigabit M12 X-coded ports in an IP66/IP67, UL 50E Type 4X housing.

TSN and edge compute

TSN frame preemption gives control traffic priority, and MRP, REP and Fast REP rings recover from link failures. IOx can host Cisco Cyber Vision, Secure Equipment Access or ThousandEyes Enterprise Agent; Cyber Vision and Secure Equipment Access are bundled only with Network Advantage orders.

Frequently asked questions

Straight answers about the Cisco IE-3500H-8T-E from the ARC IP Networks team. Last reviewed October 2026.

No. This model has no PoE budget; its 8 M12 X-coded ports are data-only Gigabit Ethernet.

No. Cisco states PRP, HSR and DLR are supported only on IE3505H variants; this model supports MRP, REP and Fast REP.

Network Essentials (perpetual), covering Layer 2, multicast, MACsec-128, QoS, static, OSPF, RIP and PBR routing, CIP, PROFINET, PTP and TSN. BGP, MACsec-256 and SD-Access are Network Advantage features.

A single DC source of 12-48VDC through a Mini-change connector; Cisco lists 3.1A input current and 38W consumption measured at 12V.

Cisco rates it -40 to 75°C with 200 LFM airflow, with storage from -40 to 85°C.

ARC IP Networks is a Cisco Registered Partner and supplies the genuine Cisco IE-3500H-8T-E through Cisco's authorised Australian distribution, with a GST tax invoice.
