| 4G |
|---|
| Network Type | LTE Band of EU:; 4G LTE-FDD: B1/B3/B5/B7/B8/B20/B28/B32 (2100/1800/850/2600/ 900/800/700/1450 MHz); 4G LTE-TDD: B38/B40/B41 (2600/2300/2500 MHz); 3G DC-HSDPA/HSPA+/HSDPA/HSUPA/WCDMA: B1/B3/B5/B8 (2100/1800/850/900 MHz) Carrier Aggregation of EU:; B1+B1/B3/B5/B7/B8/B20/B28/B38/B40/B41; B3+B3/B5/B7/B8/B20/B28/B38/B40/B41; B5+B5/B7/B38/B40/B41; B7+B7/B8/B20/B28/B32; B8+B32/B38/B40/B41; B20+B32/B38/B40; B28+B32/B38/B40/B41; B38+B38; B40+B40; B41+B41 |
|---|
| SIM Type | 2× Nano SIM slots (4G+ Cat6) |
|---|
| Frequency | Downlink: 300 Mbps; Uplink: 50 Mbps |
|---|
| Security |
|---|
| DPI | Deep Packet Inspection Support 2421 type Applications |
|---|
| Access Control | Source/Destination IP Based ACL; Stateful ACL; IPv4/IPv6 ACL; National Based ACL; FQDN |
|---|
| DNS Proxy | DNSSEC, DoH, DoT, and DNS Override |
|---|
| Filtering | Web Group Filtering; URL Categories and URLs Filtering; Web Security |
|---|
| ARP Inspection | Sending GARP Packets; ARP Scanning; IP-MAC Binding; ARP Detection |
|---|
| Attack Defense | TCP/UDP/ICMP Flood Defense; Block TCP Scan (Stealth FIN/Xmas/Null); Block Ping from WAN |
|---|
| Hardware Features |
|---|
| Standards and Protocols | IEEE 802.3, IEEE802.3u, IEEE802.3ab, IEEE802.3z, IEEE 802.3x, IEEE 802.1q, TCP/IP, DHCP, ICMP, NAT, PPPoE, NTP, HTTP, HTTPS, DNS, IPSec, PPTP, L2TP, OpenVPN, WireGuard VPN, GRE VPN, SNMP, 802.11a/b/g/n/ac/ax, LLDP |
|---|
| Interface | 1× Gigabit SFP WAN/LAN Port; 1× Gigabit WAN Port; 4× Gigabit WAN/LAN Ports |
|---|
| Network Media | 10BASE-T: UTP category 3, 4, 5 cable (Max 100 m) EIA/TIA-568 100Ω STP (Max 100 m); 100BASE-TX: UTP category 5, 5e cable (Max 100 m) EIA/TIA-568 100Ω STP (Max 100 m); 1000BASE-T: UTP category 5, 5e, 6 cable (Max 100 m) |
|---|
| Button | Reset Button |
|---|
| Power Supply | 53.5VDC / 1.31A Power Adapter |
|---|
| Wi-Fi Frequency & Signal Rate | 2.4 GHz: 574 Mbps; 5 GHz: 2402 Mbps (HE160) |
|---|
| Flash | 256 MB NAND |
|---|
| DRAM | 512 MB DDR4 |
|---|
| LED | SYS, WLAN, SFP, LTE1, LTE2, PoE Max, LTE Signal, WAN (1000M Link/Act, 100/10M Link/Act), WAN/LAN (1000M Link/Act, 100/10M Link/Act, PoE) |
|---|
| PoE Ports (RJ45) | 4× ports PoE+ output, 45 W PoE Budget |
|---|
| Dimensions ( W x D x H ) | 8.9 × 5.2 × 1.4 in (226 × 131 × 35 mm) (Antenna dimensions are not included) |
|---|
| Antenna | Wi-Fi: 3× 5GHz 5.5dBi & 2.4GHz 4.5dBi dual-band detachable antennas; LTE: 2× 4.0dBi omnidirectional detachable antennas |
|---|
| Mounting | Desktop/Wall-Mounting/Rackmount (rackmount kit not provided) |
|---|
| Max. Power Consumption | EU: 64W with PoE Max; 18W without PoE; US: 65W with PoE Max; 19W without PoE |
|---|
| Performance |
|---|
| Concurrent Session | 150,000 |
|---|
| New Sessions /Second | 4,500 |
|---|
| NAT (Static IP) | Upload: 947.1Mbps; Download: 940.1Mbps |
|---|
| NAT(DHCP) | Upload: 949.2Mbps; Download:941.1Mbps |
|---|
| NAT(PPPoE) | Upload: 942.6Mbps; Download:941.1Mbps |
|---|
| NAT (L2TP) | Upload: 875.4Mbps; Download: 892.0Mbps |
|---|
| NAT (PPTP) | Upload: 881.2 Mbps; Download: 895.8 Mbps |
|---|
| 66 Byte Packet Forwarding Rate | 1,453,489 pps / 1,453,488 pps |
|---|
| 1,518 Byte Packet forwarding rate | 81,274 pps / 91,275 pps |
|---|
| IPsec VPN Throughput | ESP-SHA1-AES256: 652.2Mbps; ESP-SHA256-AES256: 654.4Mbps; ESP-SHA384-AES256: 646.5Mbps; ESP-SHA512-AES256: 670.5 Mbps |
|---|
| GRE | Unencrypted: 951 Mbps; Encrypted: 615 Mbps |
|---|
| WireGuard VPN | 335.1 Mbps |
|---|
| OpenVPN | 101.8 Mbps |
|---|
| L2TP VPN Throughput | Unencrypted: 990.0 Mbps; Encrypted: 502.5 Mbps |
|---|
| PPTP VPN Throughput | Unencrypted: 1057.5 Mbps; Encrypted: 177.4 Mbps |
|---|
| DPI Throughput | TCP: 933 Mbps; UDP: 927 Mbps |
|---|
| SSL VPN Throughput | 114.6 Mbps |
|---|
| Wireless Features |
|---|
| Advanced Features | Seamless Roaming; Mesh (with EAP that supports Mesh); OFDMA; Beamforming; MU-MIMO; Rate Limit: Based on SSID/Client; Airtime Fairness; Wireless Encryption: WPA/WPA2/WPA3 Personal, WPA/WPA2/WPA3 Enterprise; Multiple SSIDs: 16 in total (8 per radio); Load Balance; Airtime Fairness; Band Steering; RADIUS Accounting; MAC Authentication; Reboot Schedule; Wireless Schedule; Enable/Disable Wireless Radio; Enable/Disable SSID Broadcast; Guest Network; Automatic Channel Selection Algorithm; Transmit Power Control: Adjust transmit Power on dBm |
|---|
| Basic Functions |
|---|
| LAN DNS | √ |
|---|
| WAN Connection Type | Static IP; Dynamic IP; PPPoE (supports MRU Configuration); PPTP; L2TP |
|---|
| MAC Clone | Modify WAN Address |
|---|
| DHCP | DHCP Server; DHCPv6 PD Server (only in Standalone Mode); DHCP Options Customisation; DHCP Address Reservation; Multi-IP Interfaces; Multi-Net DHCP; WAN DHCP 60 |
|---|
| Stateful ACL | √ |
|---|
| Quality of Service | √ |
|---|
| Bridge VLAN | √ |
|---|
| SMS | Receive / Send SMS |
|---|
| mDNS Repeater | √ |
|---|
| IPv6 | StaticIP / SLAAC / DHCPv6 / PPPoE / 6to4Tunnel / PassThrough / Non-Address mode |
|---|
| VLAN | 802.1Q VLAN |
|---|
| IPTV | IGMP v2/v3 Proxy, Custom Mode, Bridge Mode |
|---|
| Advanced Features |
|---|
| Advanced Routing | Static Routing; Policy Routing; RIP; OSPF |
|---|
| Bandwidth Control | IP-Based Bandwidth Control |
|---|
| Load Balance | Intelligent Load Balance; Application Optimised Routing; Link Backup(Timing, Failover); Online Detection |
|---|
| NAT | One-to-One NAT; Multi-Net NAT; Port Forwarding; Port Triggering; NAT-DMZ; FTP/H.323/SIP/IPSec/PPTP ALG; UPnP; Disable NAT |
|---|
| Session Limit | IP-Based Session Limit |
|---|
| Vpn |
|---|
| GRE | √ (Only in Standalone Mode) |
|---|
| SD-WAN | √ (Only in Controller Mode) |
|---|
| SSL VPN | 50 Tunnels |
|---|
| IPsec VPN | 100 IPSec VPN Tunnels; LAN-to-LAN, Client-to-LAN; Main, Aggressive Negotiation Mode; DES, 3DES, AES128, AES192, AES256 Encryption Algorithm; IPsec Failover; IKE v1/v2; MD5, SHA1, SHA2-384 and SHA2-512 Authentication Algorithm; NAT Traversal (NAT-T); Dead Peer Detection (DPD); Perfect Forward Secrecy (PFS) |
|---|
| PPTP VPN | PPTP VPN Server; PPTP VPN Client (10); 50 Tunnels; PPTP with MPPE Encryption |
|---|
| L2TP VPN | L2TP VPN Server; L2TP VPN Client (10); 50 Tunnels; L2TP over IPSec |
|---|
| OpenVPN | OpenVPN Server; OpenVPN Client (5); 55 OpenVPN Tunnels; "Certificate + Account" Mode; Full Mode |
|---|
| WireGuard VPN | √ |
|---|
| Authentication |
|---|
| Web Authentication | No Authentication; Simple Password; Hotspot (Local User / Voucher / SMS / Radius ); External Radius Server; External Portal Server; LDAP |
|---|
| Management Features |
|---|
| Omada App | Yes. |
|---|
| Centralised Management | Omada Central (Cloud-Based); Omada Hardware Controller; Omada Software Controller |
|---|
| Cloud Access | Yes. |
|---|
| Service | Dynamic DNS (Dyndns, No-IP, Peanuthull, Comexe, DDNS Customisation) |
|---|
| Maintenance | Web Management Interface; Remote Management; Export & Import Configuration; SNMP v1/v2c/v3; Diagnostics (Ping & Traceroute); NTP Synchronize; Port Mirroring; CLI (only in Standalone Mode); Syslog Support |
|---|
| Zero-Touch Provisioning | Yes. Require the use of an Omada Controller. |
|---|
| Management Features | Automatic Device Discovery; Intelligent Network Monitoring; Abnormal Event Warnings; Unified Configuration; Reboot Schedule; Captive Portal Configuration |
|---|
| Others |
|---|
| Network Services Enabled by Default | Web Server Manage and configure device through web (HTTP/HTTPS); Port: 80/443 Protocol: TCP _____________________________________________________ TDP Server Device discovery; Port: 20003 Protocol: UDP _____________________________________________________ DHCP Server Handle DHCP packets; Port: 67 Protocol: UDP _____________________________________________________ DNS Handle DNS packets; Port: 53 Protocol: TCP/UDP |
|---|
| Certification | CE, FCC |
|---|
| System Requirements | Microsoft Windows 98SE, NT, 2000, XP, Vista or Windows 7/8/8.1/10/11; MAC OS, NetWare, UNIX or Linux |
|---|
| Environment | Operating Temperature: 0 °C to 40 °C (32 °F to 104 °F); Storage Temperature: -40 °C to 70 °C (-40 °F to 158 °F); Operating Humidity: 10% to 90% non-condensing; Storage Humidity: 5% to 90% non-condensing |
|---|
