Siklu EH-MK-SM EtherHaul Pole Mounting Kit for Small ODUs and 0.5ft Antenna

https://arcip.com.au/web/image/product.template/3443/image_1920?unique=068361f

Siklu EH-MK-SM is the pole-mounting kit for small-form-factor EtherHaul radios, such as the EH-500TX, EH-600 and EH-7x0 with the 0.5 ft antenna. It gives fine ±10° azimuth and up to +60°/−45° elevation adjustment on 50–120 mm poles.

$ 241.40 241.4 AUD $ 241.40 incl. GST

Not Available For Sale


  • Brand

This combination does not exist.

Siklu
  • Stock

    Authorised Australian Reseller | Australian Stock | Genuine Local Warranty

  • Instalment
    Buy Now, Pay Later
  • [Warranty Information] Warranty
    Manufacturer Warranty
Estimate delivery
Shipping calculated at checkout
Estimate delivery times: 3-7 business days
Guaranteed Safe Checkout
Guaranteed Safe Checkout
Accepted payments: Google Pay, Apple Pay, Visa, Mastercard and PayPal
SKU
EH-MK-SM
Tags

Siklu EH-MK-SM at a glance

The Siklu EH-MK-SM is the small pole mount for compact EtherHaul radios: the EH-500TX and EH-600 series with integrated antennas, and the EH-7x0 series with the 0.5 ft antenna. It gives fine ±10° azimuth and up to +60°/−45° elevation adjustment, fits 50–120 mm poles and weighs 0.8 kg.

ARC IP Networks is an authorised Siklu reseller in Australia. We supply the genuine Siklu EH-MK-SM small mounting kit at competitive prices, from Australian stock, with the full manufacturer's warranty and a GST tax invoice.

Azimuth±10° fine
Elevation+60° / −45° fine
Pole size50–120 mm
Weight0.8 kg
Wind160 km/h op / 220 km/h survival
Temperature−45 to +70 °C
ComplianceCE (RoHS)
ExtenderEH-MK-SM-EXT

Best for

  • EH-500TX and EH-600 V-band radios
  • EH-7x0 E-band radios with the 0.5 ft antenna
  • Steep up- or down-tilt links between buildings

Consider instead

  • Siklu AX-MK-1ft-B: large E-band ODUs such as the EH-2500FX with 0.5 ft or 1 ft antennas

Key features

Fine ±10° azimuth adjustment

Elevation up to +60° / −45°, or −60° with the EH-MK-SM-EXT extender

Fits 50–120 mm poles

Rated for 160 km/h operation and 220 km/h survival

0.8 kg, CE (RoHS)

Siklu EH-MK-SM specifications

Mechanical

Azimuth adjustment±10°, fine
Elevation adjustmentUp to +60° / −45° fine (−60° with EH-MK-SM-EXT)
Pole diameter50–120 mm
Dimensions91 x 115 mm
Weight0.8 kg
Wind speed160 km/h operational, 220 km/h survival

Environmental

Temperature−45 °C to +70 °C
Humidity100%
ComplianceCE (RoHS)

Specifications from Siklu by Ceragon's official product documentation for the EH-MK-SM, checked October 2026.

The Siklu EH-MK-SM small mounting kit in depth

Which radios it fits

Siklu lists the EH-MK-SM for its small-form-factor EtherHaul radios: the EH-500TX and EH-600 series, which have integrated antennas, and the EH-7x0 series fitted with the 0.5 ft antenna. It is not the mount for large ODUs such as the EH-2500FX; for those Siklu lists the AX-MK-1ft-B or EH-MK-SP.

Alignment

Fine azimuth (±10°) and elevation adjustment make it easier to peak a narrow-beam millimetre-wave link. The elevation range of +60° to −45° covers most building-to-building links, and the EH-MK-SM-EXT extender takes down-tilt to −60°.

Frequently asked questions

Straight answers about the Siklu EH-MK-SM small mounting kit from the ARC IP Networks team. Last reviewed October 2026.

It is Siklu's pole-mounting kit for small EtherHaul radios (EH-500TX, EH-600, and EH-7x0 with the 0.5 ft antenna), with fine azimuth and elevation adjustment on 50–120 mm poles.

No. Siklu lists the AX-MK-1ft-B or EH-MK-SP for large E-band ODUs such as the EH-2500FX.

Up to +60° and −45° elevation with fine adjustment, and down to −60° with the EH-MK-SM-EXT extender. Azimuth fine adjustment is ±10°.

ARC IP Networks is an authorised Siklu reseller and supplies the genuine Siklu EH-MK-SM at competitive prices from Australian stock, with the full manufacturer's warranty and a GST tax invoice. Trade and project pricing is available.

Buy the Siklu EH-MK-SM in Australia

ARC IP Networks is an authorised Siklu reseller, supplying genuine Siklu by Ceragon mmWave and E-band radios, antennas and accessories at competitive prices to ISPs, integrators and businesses across Australia.

  • Genuine Siklu by Ceragon products, never grey import.
  • Australian stock with Australia-wide delivery.
  • Full manufacturer's warranty and local pre-sales help with link planning.
  • GST tax invoice on every order, with trade and project pricing available.

Mounting a compact EtherHaul link?

Ask ARC IP Networks for project pricing or a configured quote, or call us to check the right Siklu model for your link.
