Cisco CW9162I-Z Catalyst 9162 Wi-Fi 6E Tri-Band 2x2 Indoor Access Point, 2.5G mGig, BLE 5.1 (AU/NZ)

Price:

$ 1,452.59


Cisco CS-T10-TS-L-K9= Room Navigator Table-Stand 10.1" Touch Controller, First Light (White), Spare
Cisco CS-T10-TS-L-K9= Room Navigator Table-Stand 10.1" Touch Controller, First Light (White), Spare
$ 2,048.38
$ 2,048.38
Cisco DP-9811-K9= Desk Phone 9811, 2 Line Keys, 256 x 132 Display, PhoneOS, PoE Class 2, Carbon Black
Cisco DP-9811-K9= Desk Phone 9811, 2 Line Keys, 256 x 132 Display, PhoneOS, PoE Class 2, Carbon Black
$ 438.68
$ 438.68

Cisco CW9162I-Z Catalyst 9162 Wi-Fi 6E Tri-Band 2x2 Indoor Access Point, 2.5G mGig, BLE 5.1 (AU/NZ)

https://arcip.com.au/web/image/product.template/12760/image_1920?unique=3c3b158

Cisco Catalyst 9162I CW9162I-Z indoor Wi-Fi 6E access point, Australia/New Zealand regulatory domain. Three 2x2 radios on 2.4, 5 and 6 GHz, PHY rates up to 3.9 Gbps, OFDMA, MU-MIMO, TWT, CleanAir Pro. 1x 2.5G Multigigabit uplink, Bluetooth LE 5.1, USB 2.0. 802.3at PoE+ or Cisco UPOE (25.5W max) or 12V DC. Managed by Cisco Catalyst 9800 controllers or the Meraki dashboard. WPA3. Limited lifetime hardware warranty. Genuine Cisco from ARC IP Networks, a Cisco Registered Partner.

$ 1,452.59 1452.59 AUD $ 1,452.59 incl. GST

Not Available For Sale


  • Brand

This combination does not exist.

In stock online
  • Stock

    Authorised Australian Reseller | Australian Stock | Genuine Local Warranty

  • Instalment
    Buy Now, Pay Later
  • [Warranty Information] Warranty
    Manufacturer Warranty
Estimate delivery
Shipping calculated at checkout
Estimate delivery times: 3-7 business days
Guaranteed Safe Checkout
Guaranteed Safe Checkout
Accepted payments: Google Pay, Apple Pay, Visa, Mastercard and PayPal
SKU
CW9162I-Z

Cisco CW9162I-Z at a glance

The Cisco Catalyst 9162I (CW9162I-Z) is a Wi-Fi 6E indoor access point with three 2x2 radios on 2.4, 5 and 6 GHz, PHY rates up to 3.9 Gbps and a 2.5G Multigigabit uplink, in the Australia/New Zealand regulatory domain. Aimed at small to medium deployments, it can be managed on-premises by Catalyst 9800 controllers or in the cloud through the Meraki dashboard, and draws up to 25.5W on 802.3at PoE+.

ARC IP Networks is a Cisco Registered Partner in Australia. We supply the genuine Cisco CW9162I-Z through Cisco's authorised Australian distribution, with a GST tax invoice on every order.

Wi-FiWi-Fi 6E tri-band 2x2
Max PHY rateUp to 3.9 Gbps
ManagementCatalyst 9800 or Meraki
WarrantyLimited lifetime

Best for

  • Small to medium offices moving to 6-GHz Wi-Fi 6E
  • Organisations that want the option to switch between Catalyst 9800 and Meraki cloud management
  • Sites using Bluetooth LE for asset tracking and wayfinding

Key features

Wi-Fi 6E (802.11ax) with three 2x2 radios on 2.4, 5 and 6 GHz.

PHY data rates up to 3.9 Gbps, with 160 MHz channels on 6 GHz.

Uplink/downlink OFDMA and MU-MIMO, TWT and BSS colouring.

Cisco CleanAir Pro extends interference detection into the 6-GHz band, with band steering of 6E clients.

1 x 100M/1G/2.5G Multigigabit Ethernet uplink and USB 2.0 for application hosting.

Integrated Bluetooth Low Energy 5.1 radio for asset tracking, wayfinding and analytics.

Managed by Catalyst 9800 controllers or the Meraki dashboard, with the option to change mode later.

Powered by 802.3at PoE+, Cisco UPOE or 12V DC; reduced radio mode on 802.3af.

Secure Boot, image signing and the Cisco Trust Anchor module; WPA3 certified.

Cisco CW9162I-Z specifications

Cisco CW9162I-Z technical specifications
SpecificationValue
Wireless
Standard802.11a/b/g/n/ac/ax, Wi-Fi 6E
Radios2.4 GHz 2x2, 5 GHz 2x2, 6 GHz 2x2
Max PHY rateUp to 3.9 Gbps
Channel widths20-160 MHz (6 GHz), 20-80 MHz (5 GHz), 20 MHz (2.4 GHz)
Max transmit power20 dBm (100 mW) per band
BluetoothBluetooth Low Energy 5.1
Antennas
TypeInternal, omnidirectional in azimuth
Peak gain4 dBi (2.4 GHz), 5 dBi (5 GHz), 5 dBi (6 GHz)
Interfaces
Uplink1x 100M/1000M/2.5G Multigigabit Ethernet (RJ-45)
ConsoleRJ-45
USBUSB 2.0 at 4.5W
Power
Supported802.3bt Cisco UPOE, 802.3at PoE+, 802.3af, 12V DC
Max consumption (PoE+/UPOE)25.5W, all radios 2x2, 2.5G, USB on
802.3af mode13.3W, 2.4 GHz off, 5 and 6 GHz 1x1, 1G
Injectors / DCAIR-PWRINJ7=, AIR-PWRINJ6=, MA-INJ-6, MA-PWR-30W
Hardware and software
Memory2048 MB DRAM, 1024 MB flash
SoftwareCisco IOS XE 17.9.2/17.10.1 or later
ControllersCisco Catalyst 9800 Series (physical or virtual)
Regulatory domain-Z (Australia / New Zealand)
Physical and environment
Dimensions (W x L x H)200 x 200 x 44.45 mm
Operating temperature0 to 50°C
Storage temperature-30 to 70°C
Humidity10% to 90% noncondensing
Warranty
WarrantyLimited lifetime hardware warranty (WARR-CW-LIFE-LTD)
Includes5-day advance hardware replacement, 90-day software media

Figures from Cisco's official data sheet.

The Cisco CW9162I-Z in depth

Wi-Fi 6E for small and medium sites

The Catalyst 9162 Series brings the 6-GHz band to small and medium-sized deployments. The CW9162I-Z has three 2x2 radios across 2.4, 5 and 6 GHz, steering 6E-capable clients onto the clean 6-GHz band and leaving 2.4 and 5 GHz for older devices.

Your choice of management

The same hardware can run under Cisco Catalyst 9800 wireless controllers on-premises or under the Meraki cloud dashboard, and Cisco states you can switch management mode later without buying new hardware. Licensing is available through the Cisco Networking Subscription or Cisco DNA tiers.

Built-in intelligence and security

CleanAir Pro detects and classifies interference including on 6 GHz, AP Power Save can switch radios off out of hours, and a Bluetooth LE 5.1 radio supports location services. Secure Boot, image signing and the Trust Anchor module protect the AP's software.

Frequently asked questions

Straight answers about the Cisco CW9162I-Z from the ARC IP Networks team. Last reviewed October 2026.

Cisco states the Catalyst 9162 Series can be managed on-premises with Catalyst 9800 controllers or cloud-managed through the Meraki dashboard, and the management mode can be changed later without new hardware. Cisco also sells a dedicated Meraki-managed part number, CW9162I-MR.

802.3at PoE+, Cisco UPOE or the 12V DC MA-PWR-30W adapter give full tri-band 2x2 operation and 2.5G, up to 25.5W. On 802.3af (13.3W) the 2.4-GHz radio is off, 5 and 6 GHz run 1x1 and the uplink runs at 1G.

-Z is the Australia/New Zealand regulatory domain. Cisco notes that where 6-GHz use is not allowed or not yet supported in software, the 6-GHz radio is disabled.

Cisco offers licensing through the Cisco Networking Subscription (Wireless Essentials or Advantage, minimum 12-month term) or Cisco DNA Essentials and Advantage with 3, 5 or 7-year terms.

A limited lifetime hardware warranty for as long as the original end user owns or uses it, including 5-day advance hardware replacement and 90 days on software media.

ARC IP Networks is a Cisco Registered Partner and supplies the genuine Cisco CW9162I-Z through Cisco's authorised Australian distribution, with a GST tax invoice.
