Cisco 5G-ANTM-O-4-B 9-in-1 5G/LTE, Wi-Fi and GNSS Low-Profile Outdoor Antenna, IP67

Price:

$ 2,821.57


Cisco 5G-ANTM-GD Ground Disc for 5G-ANTM-O-4-B 9-in-1 Antenna Ceiling Mounting
Cisco 5G-ANTM-GD Ground Disc for 5G-ANTM-O-4-B 9-in-1 Antenna Ceiling Mounting
$ 144.89
$ 144.89
Cisco 5G-ANTM2-SMA-D= Multiband Swivel-Mount Dipole Antenna for 5G and LTE CAT7 PIMs
Cisco 5G-ANTM2-SMA-D= Multiband Swivel-Mount Dipole Antenna for 5G and LTE CAT7 PIMs
$ 152.53
$ 152.53

Cisco 5G-ANTM-O-4-B 9-in-1 5G/LTE, Wi-Fi and GNSS Low-Profile Outdoor Antenna, IP67

https://arcip.com.au/web/image/product.template/11577/image_1920?unique=f69e2bd

Cisco 5G-ANTM-O-4-B low-profile 9-in-1 antenna: four 4G LTE/5G FR1 elements (about 617-5950 MHz), four dual-band Wi-Fi elements (2400-2500 and 4900-5900 MHz) and one GNSS element (1565-1608 MHz). IP67 on a sealed surface, -40 °C to +85 °C, EN 50155:2007 and AAR for rail, 25 W maximum. SMA male cellular and GNSS cables, RP-SMA male Wi-Fi cables, metal stud mount, 176.0 x 154.8 x 76.5 mm. Ceiling mounting requires the 5G-ANTM-GD ground disc. Genuine Cisco from ARC IP Networks, a Cisco Registered Partner.

$ 2,821.57 2821.57 AUD $ 2,821.57 incl. GST

Not Available For Sale


  • Brand

This combination does not exist.

  • Stock

    Authorised Australian Reseller | Australian Stock | Genuine Local Warranty

  • Instalment
    Buy Now, Pay Later
  • [Warranty Information] Warranty
    Manufacturer Warranty
Estimate delivery
Shipping calculated at checkout
Estimate delivery times: 3-7 business days
Guaranteed Safe Checkout
Guaranteed Safe Checkout
Accepted payments: Google Pay, Apple Pay, Visa, Mastercard and PayPal
SKU
5G-ANTM-O-4-B

Cisco 5G-ANTM-O-4-B at a glance

The Cisco 5G-ANTM-O-4-B is a low-profile 9-port antenna with four 4G LTE/5G FR1 elements, four dual-band Wi-Fi elements and one GNSS element in one IP67 housing. It covers about 617 MHz to 5950 MHz on the cellular ports and suits vehicle, rail, ceiling and wall installations.

ARC IP Networks is a Cisco Registered Partner in Australia. We supply the genuine Cisco 5G-ANTM-O-4-B through Cisco's authorised Australian distribution, with a GST tax invoice on every order.

Elements4 LTE/5G, 4 Wi-Fi, 1 GNSS
Cellular617-5950 MHz
RatingIP67
ConnectorsSMA / RP-SMA male

Best for

  • Vehicle and rail deployments of Cisco industrial routers
  • Ceiling or wall mounting where one antenna must serve 5G, Wi-Fi and GNSS
  • Outdoor sites needing an IP67 multi-element antenna

Key features

Nine ports: two LTE/5G primary, two LTE/5G diversity, four Wi-Fi and one GNSS.

Cellular elements cover about 617 MHz to 5950 MHz for 4G LTE and 5G FR1.

Wi-Fi elements cover 2400-2500 MHz and 4900-5900 MHz.

GNSS 1565-1608 MHz with an LNA of about 26 dB typical gain.

IP67 on a sealed surface; meets EN 50155:2007 and AAR requirements for rail.

Metal stud mount with slotted jam nut and single cable exit.

SMA male on cellular and GNSS cables, reverse-polarity SMA male on Wi-Fi.

Operating temperature -40 °C to +85 °C; 25 W maximum power.

Cisco 5G-ANTM-O-4-B specifications

Cisco 5G-ANTM-O-4-B technical specifications
SpecificationValue
Elements
LTE/5G4 (2 primary, 2 diversity)
Wi-Fi4
GNSS1
RF
LTE/5GAbout 617-5950 MHz
Wi-Fi2400-2500 MHz, 4900-5900 MHz
GNSS1565-1608 MHz
Impedance50 ohms
Maximum power25 W
PolarisationLinear (GNSS right-hand circular)
GNSS LNA
Supply2.8-6.0 V
CurrentAbout 25 mA typical at 3.0 V
GainAbout 26 dB typical
Noise figureBelow 2.0 dB typical
Physical
Dimensions176.0 x 154.8 x 76.5 mm
ConnectorsSMA male (LTE, GNSS), RP-SMA male (Wi-Fi)
MountMetal stud, slotted jam nut
Environment
RatingIP67
Operating temperature-40 °C to +85 °C
RailEN 50155:2007, AAR

Figures from Cisco's official data sheet.

The Cisco 5G-ANTM-O-4-B in depth

One antenna for cellular, Wi-Fi and location

The 5G-ANTM-O-4-B packs nine elements into a low-profile housing: four for 4G LTE and 5G FR1 MIMO, four for dual-band Wi-Fi 5 and one for GNSS. Cisco's IR1800 installation guide lists it as the 9-in-1 transportation antenna.

Mounting options

It suits vehicles and trains, indoor ceilings, and indoor or outdoor walls. Ceiling mounting needs the 5G-ANTM-GD ground disc; wall mounting uses the 5G-ANTM-BRACKET. Tighten the lock nut to at least 14 Nm.

Frequently asked questions

Straight answers about the Cisco 5G-ANTM-O-4-B from the ARC IP Networks team. Last reviewed October 2026.

A 9-port low-profile antenna with four 4G LTE/5G FR1 elements, four dual-band Wi-Fi elements and one GNSS element, rated IP67.

About 617-5950 MHz on the cellular ports, 2400-2500 and 4900-5900 MHz for Wi-Fi, and 1565-1608 MHz for GNSS.

Only for ceiling mounting. Cisco requires the 5G-ANTM-GD ground disc for that deployment; it is not included with the antenna.

Yes. Cisco lists transportation as the most common use, and it meets EN 50155:2007 and AAR requirements for rail.

SMA male on the four cellular and one GNSS cable, and reverse-polarity SMA male on the four Wi-Fi cables.

ARC IP Networks is a Cisco Registered Partner and supplies the genuine Cisco 5G-ANTM-O-4-B through Cisco's authorised Australian distribution, with a GST tax invoice.
