Cisco 4G-LTE-ANTM-O-3-R= 3-in-1 Dual LTE + GPS Indoor/Outdoor Antenna, Red, IP67

Price:

$ 1,401.60


Cisco 4G-LTE-ANTM-O-3-C= 3-in-1 Dual LTE + GPS Indoor/Outdoor Antenna, Blue, IP67
Cisco 4G-LTE-ANTM-O-3-C= 3-in-1 Dual LTE + GPS Indoor/Outdoor Antenna, Blue, IP67
$ 1,401.60
$ 1,401.60
Cisco 4G-LTE-ANTM-O-3-W= 3-in-1 Dual LTE + GPS Indoor/Outdoor Antenna, White, IP67
Cisco 4G-LTE-ANTM-O-3-W= 3-in-1 Dual LTE + GPS Indoor/Outdoor Antenna, White, IP67
$ 1,401.60
$ 1,401.60

Cisco 4G-LTE-ANTM-O-3-R= 3-in-1 Dual LTE + GPS Indoor/Outdoor Antenna, Red, IP67

https://arcip.com.au/web/image/product.template/11568/image_1920?unique=f69e2bd

Cisco 4G-LTE-ANTM-O-3-R= red 3-in-1 indoor/outdoor antenna with two LTE elements and one GPS L1 element in a single low-profile IP67 radome. LTE 698-960 MHz and 1710-2700 MHz, 2.5 dBi typical gain, vertical linear polarisation, 3 W maximum. GPS 1575.42 MHz with 26 dBc amplifier gain. 90 mm high, 137 mm base, stud mount with serrated face nut, -40 °C to +85 °C. Includes two SMA-female to TNC-male adapters. Genuine Cisco from ARC IP Networks, a Cisco Registered Partner.

$ 1,401.60 1401.6 AUD $ 1,401.60 incl. GST

Not Available For Sale


  • Brand

This combination does not exist.

  • Stock

    Authorised Australian Reseller | Australian Stock | Genuine Local Warranty

  • Instalment
    Buy Now, Pay Later
  • [Warranty Information] Warranty
    Manufacturer Warranty
Estimate delivery
Shipping calculated at checkout
Estimate delivery times: 3-7 business days
Guaranteed Safe Checkout
Guaranteed Safe Checkout
Accepted payments: Google Pay, Apple Pay, Visa, Mastercard and PayPal
SKU
4G-LTE-ANTM-O-3-R=

Cisco 4G-LTE-ANTM-O-3-R= at a glance

The Cisco 4G-LTE-ANTM-O-3-R= is the red version of Cisco's 3-in-1 antenna, housing two LTE elements and one GPS L1 element in a single IP67 radome for indoor or outdoor mounting. The LTE elements cover 698-960 MHz and 1710-2700 MHz with 2.5 dBi typical gain, and two SMA-female to TNC-male adapters are included.

ARC IP Networks is a Cisco Registered Partner in Australia. We supply the genuine Cisco 4G-LTE-ANTM-O-3-R= through Cisco's authorised Australian distribution, with a GST tax invoice on every order.

LTE bands698-960 / 1710-2700 MHz
LTE gain2.5 dBi typical
RatingIP67
ConnectorsSMA-Male + TNC adapters

Best for

  • Roof or cabinet-top antennas for Cisco cellular routers
  • ATM, kiosk and cabinet sites with one or two routers
  • Sites that need LTE MIMO plus GPS location from one antenna

Key features

Two LTE antennas and one GPS antenna in a single low-profile radome.

LTE 698-960 MHz and 1710-2700 MHz, 2.5 dBi typical gain, vertical linear polarisation.

GPS L1 1575.42 MHz with 26 dBc ± 3 dB amplifier gain and 1.8 dB typical noise figure.

IP67 when mounted per the instructions; UV-resistant radome.

Metal stud mount with serrated face nut and a single cable exit.

Operating and storage temperature -40 °C to +85 °C.

Red radome; also available in black, blue, white.

Ships with two SMA-female to TNC-male adapters for routers with TNC-female MAIN and DIV ports.

Cisco 4G-LTE-ANTM-O-3-R= specifications

Cisco 4G-LTE-ANTM-O-3-R= technical specifications
SpecificationValue
LTE
Frequencies698-960 MHz, 1710-2700 MHz
Typical gain2.5 dBi
VSWR< 2.5:1
PolarisationVertical, linear
Impedance50 ohms
Maximum power3 W
Elevation beamwidth30° nominal
GPS
Band1575.42 MHz (GPS L1)
Amplifier gain26 dBc ± 3 dB
Noise figure1.8 dB typical
DC voltage3.3-5 V
DC current20 mA nominal
Physical
ConnectorSMA-Male (RG174 cable)
Height90 mm
Base diameter137 mm
ColourRed
MountStud with serrated face nut
Environment
UseIndoor and outdoor
Ingress protectionIP67
Temperature-40 °C to +85 °C
In the box
ContentsAntenna, two SMA-female to TNC-male adapters, installation guide

Figures from Cisco's official data sheet.

The Cisco 4G-LTE-ANTM-O-3-R= in depth

Two LTE paths and GPS in one radome

The 4G-LTE-ANTM-O-3 family combines two LTE elements for MIMO and a GPS L1 element under one low-profile, UV-resistant radome rated IP67, so a single hole gives a router both cellular diversity and location.

Installation

It mounts through a hole in a flat surface with a stud and serrated face nut. The router's MAIN and DIV ports are TNC-female, so use the two supplied SMA-to-TNC adapters.

Colour options

The same antenna is sold in white, black, red and blue; this part is the red radome.

Frequently asked questions

Straight answers about the Cisco 4G-LTE-ANTM-O-3-R= from the ARC IP Networks team. Last reviewed October 2026.

A red 3-in-1 antenna with two LTE elements and one GPS element in a single IP67 radome, for indoor or outdoor use.

LTE 698-960 MHz and 1710-2700 MHz at 2.5 dBi typical gain, plus GPS L1 at 1575.42 MHz.

Yes. It has SMA-Male connectors and ships with two SMA-female to TNC-male adapters for TNC-female MAIN and DIV ports.

Yes. It is rated IP67 when mounted per the instructions and operates from -40 °C to +85 °C.

No. Cisco lists the same specifications for the white, black, red and blue versions; only the radome colour changes.

ARC IP Networks is a Cisco Registered Partner and supplies the genuine Cisco 4G-LTE-ANTM-O-3-R= through Cisco's authorised Australian distribution, with a GST tax invoice.
