Ubiquiti USW-WAN-RJ45 UniFi 10GbE WAN Switch linking two Shadow Mode High Availability UniFi Gateways to a single ISP

https://arcip.com.au/web/image/product.template/4062/image_1920?unique=ada19b2
The USW-WAN-RJ45 is a UniFi device. 10 GbE WAN Switch linking two Shadow Mode High Availability UniFi Gateways to a single ISP.

465.85 465.85 AUD 465.85 incl. GST

Not Available For Sale


  • Brand
  • Form Factor

This combination does not exist.

UniFi Switch Managed Switch Ubiquiti
UBIQUITI
UBIQUITI

Ubiquiti Inc. offers a wide range of networking solutions for service providers and enterprises, including fixed wireless broadband, wireless backhaul, routing, LAN infrastructure, and video surveillance. The company stands out through its proprietary software, advanced firmware, and innovative hardware design.

  • Stock

    Authorised Australian Reseller | Australian Stock | Genuine Local Warranty

  • Instalment
    Buy Now, Pay Later
  • [Warranty Information] Warranty
    Manufacturer Warranty
Estimate delivery
Shipping calculated at checkout
Estimate delivery times: 3-7 business days
Guaranteed Safe Checkout
Guaranteed Safe Checkout
SKU
USW-WAN-RJ45
Barcode
810177160120
Tags
USW-WAN-RJ45
Ubiquiti UniFi UniFi WAN Switch RJ45 — 20 Gbps
USW-WAN-RJ45
USW-WAN-RJ45

Features

  • Combine with Shadow Mode High Availability to ensure uninterrupted connectivity
  • (1) 10 GbE ISP uplink and (2) 10 GbE downlink ports
  • (2) AC inputs for power redundancy
  • (1) GbE port for management with UniFi Network
  • *Use an additional USW-WAN-RJ45 switch for ISP failover deployments.

Specifications

Overview
Dimensions442.4 x 120 x 43.7 mm /
1 GbE RJ451 / (1G/100M/10M)
10 GbE RJ453 / (10G/5G/2.5G/1G/100M)
Redundancy(2) AC inputs
Form FactorRack mount (1U)
Performance
Switching Capacity20 Gbps
Total Non-Blocking Throughput10 Gbps
Forwarding Rate15 Mpps
Hardware
Max. Power Consumption18W
Power Method(2) Universal input, 100–240V AC, 50/60 Hz
Power Input MethodAC input
Power Supply(2) AC/DC, internal, 36W
Supported Voltage Range100–240V AC
ManagementEthernet
WeightWithout mounting brackets: 2.3 kg / With mounting brackets: 2.4 kg
Enclosure MaterialSGCC steel
Mount MaterialSGCC steel
ESD ProtectionAir: ± 16kV, contact: ± 10kV
Ambient Operating Temperature-5 to 40° C (23 to 104° F)
Ambient Operating Humidity10 to 90% noncondensing
CertificationsCE, FCC, IC, Anatel: 04273-25-08356
Software
UniFi NetworkVersion 9.1.120 and later

Professional Overview

The Ubiquiti USW-WAN-RJ45 is a UniFi network device. 10 GbE WAN Switch linking two Shadow Mode High Availability UniFi Gateways to a single ISP.

Weighing Without mounting brackets: 2.3 kg / With mounting brackets: 2.4 kg, the USW-WAN-RJ45 is built for reliable 24/7 operation. Australian stock, fast shipping from ARC IP Networks.

Part of our Ubiquiti UniFi Switches range — browse and compare the full lineup of PoE, aggregation, compact and 10G switches.

Ubiquiti USW-WAN-RJ45: Layer 2 switch

The UniFi WAN Switch RJ45 is a Layer 2 UniFi switch offering 10 Gbps of non-blocking throughput, 20 Gbps switching capacity.

Port layout is 1 × Gigabit RJ45, 3 × 10 GbE RJ45.

Ports and PoE

InterfaceCount & speeds
Gigabit RJ451 (1G/100M/10M)
10 GbE RJ453 (10G/5G/2.5G/1G/100M)

Switching performance

Non-blocking throughput10 Gbps
Switching capacity20 Gbps
Forwarding rate15 Mpps

Who the USW-WAN-RJ45 suits

  • Multi-WAN over copper where services hand off on RJ45.
  • Consolidating several internet feeds ahead of a gateway.
  • Sites without fibre handoff needing the same WAN aggregation.
  • UniFi-managed edge with per-link visibility.

Physical, power and mounting

Form factorRack mount (1U)
Dimensions442.4 x 120 x 43.7 mm (17.4 x 4.72 x 1.7")
WeightWithout mounting brackets: 2.3 kg (5.1 lb) With mounting brackets: 2.4 kg (5.3 lb)
Power supply(2) AC/DC, internal, 36W
Power method(2) Universal input, 100–240V AC, 50/60 Hz
Max. power consumption18W
Operating temperature-5 to 40° C (23 to 104° F)
EnclosureSGCC steel
RequiresVersion 9.1.120 and later

Frequently Asked Questions

What is the USW-WAN-RJ45?

The UniFi WAN Switch RJ45 is a UniFi managed switch, 10 Gbps of non-blocking throughput.

What ports does the USW-WAN-RJ45 have?

Gigabit RJ45: 1 (1G/100M/10M); 10 GbE RJ45: 3 (10G/5G/2.5G/1G/100M).

How is the USW-WAN-RJ45 mounted?

Rack mount (1U).

How much power does the USW-WAN-RJ45 use?

18W.

What UniFi version does it require?

UniFi Network 9.1.120 and later.

Does it need a separate UniFi controller?

UniFi switches are adopted and managed by a UniFi controller — a Cloud Gateway, Dream Machine, CloudKey or UniFi hosting. The switch itself does not host the controller.

Is the USW-WAN-RJ45 available in Australia?

Yes. ARC IP Networks is an authorised Ubiquiti reseller holding Australian stock with full manufacturer warranty and fast domestic shipping.
