Ruijie Wi-Fi 5, 1267Mbps, 5*GE, PoE Passthrough

https://arcip.com.au/web/image/product.template/5638/image_1920?unique=8867584
The Ruijie RG-RAP1200(P) is a powerful Wi-Fi 5 dual-band access point, offering 1267Mbps speeds, five Gigabit Ethernet ports, and convenient PoE passthrough for flexible network expansion.

107.43 107.43 AUD 107.43 incl. GST

Not Available For Sale


  • Brand

This combination does not exist.

PoE Ruijie
  • Stock

    Authorised Australian Reseller | Australian Stock | Genuine Local Warranty

  • Instalment
    Buy Now, Pay Later
  • [Warranty Information] Warranty
    Manufacturer Warranty
Estimate delivery
Shipping calculated at checkout
Estimate delivery times: 3-7 business days
Guaranteed Safe Checkout
Guaranteed Safe Checkout
SKU
RG-RAP1200(P)
Barcode
6971693271449
Tags
RG-RAP1200(P) Wi-Fi 5 (AC1200) Dual-Band Access Point with 5 Gigabit Ports & PoE Passthrough
Ruijie

Features

  • Dual-band Wi-Fi 5 (802.11ac Wave 2) with up to 1267Mbps aggregate wireless rate
  • 5 x 10/100/1000BASE-T Gigabit Ethernet Ports for versatile wired connectivity
  • PoE Passthrough on multiple downlink Gigabit ports for powering compatible devices
  • Supports Ruijie Cloud management for remote control, monitoring, and optimization
  • Integrated omni-directional antennas for optimized signal coverage
  • Supports 802.3af/at Power over Ethernet (PoE) input for flexible deployment
  • Intelligent QoS for optimized network performance and traffic prioritization
  • Advanced security features: WPA/WPA2-PSK, WPA/WPA2-Enterprise
  • High-density user access capability with seamless roaming support
  • Sleek ceiling/wall-mount design for discreet integration

Specifications

Wireless
Wi-Fi Standards802.11a/b/g/n/ac Wave 2
Operating Frequencies2.4 GHz & 5 GHz
Max Wireless Rate1267Mbps (2.4GHz: 400Mbps, 5GHz: 867Mbps)
MIMO2x2 MIMO @ 2.4GHz, 2x2 MIMO @ 5GHz
AntennaInternal Omni-directional
Spatial Streams2 @ 2.4GHz, 2 @ 5GHz
Ports
Ethernet Ports5 x 10/100/1000BASE-T RJ45 (1 Uplink, 4 Downlink)
PoE
PoE Input802.3af/at PoE (on Uplink port)
PoE OutputPoE Passthrough (on Downlink ports)
Max PoE Passthrough BudgetDynamic, depends on PoE input source and AP power consumption
Power
Power Supply802.3af/at PoE
Max Power Consumption< 15W (AP itself, without passthrough load)
Physical & Environmental
Dimensions (W x D x H)(Approx.) 194mm x 194mm x 37mm
InstallationCeiling/Wall-mount
Operating Temperature0°C to 40°C
ManagementRuijie Cloud App, Web GUI

Professional Overview

The Ruijie RG-RAP1200(P) is a high-performance Wi-Fi 5 (802.11ac Wave 2) dual-band access point, meticulously engineered to provide superior wireless connectivity with integrated wired features and power passthrough capabilities for diverse environments such as small to medium-sized businesses (SMBs), hotels, dormitories, and modern offices. With an impressive aggregate wireless rate of up to 1267Mbps (400Mbps on 2.4GHz and 867Mbps on 5GHz), this access point ensures smooth, high-speed Wi-Fi performance, capable of handling numerous concurrent users and bandwidth-intensive applications such as high-definition video streaming, large file transfers, and cloud-based services.

A key advantage of the RG-RAP1200(P) is its five Gigabit Ethernet (GE) ports. One port typically serves as the uplink, receiving PoE input for flexible power and data delivery over a single cable. The remaining four Gigabit ports function as downlinks, offering high-speed wired connectivity for devices like desktop computers, smart TVs, or IP phones directly from the AP. Crucially, these downlink ports support PoE Passthrough, enabling the AP to power other low-power PoE devices, further simplifying cabling and reducing the need for additional power outlets in multi-device setups. This versatile port configuration makes it an ideal choice for rooms or workstations requiring both robust wireless and consolidated wired connectivity.

Power over Ethernet (802.3af/at PoE) support for input simplifies installation by allowing both power and data to be delivered over a single Ethernet cable, eliminating the need for local power adapters and reducing overall wiring complexity. This makes deployment flexible and cost-effective across numerous rooms. The device also supports intelligent Quality of Service (QoS) features to prioritize critical applications, ensuring smooth performance for latency-sensitive traffic like VoIP and video conferencing, even during peak network usage, thereby enhancing user experience.

As a key component of Ruijie's Reyee Cloud ecosystem, the RG-RAP1200(P) offers robust cloud management capabilities. Network administrators can leverage the intuitive Ruijie Cloud App or web GUI for zero-touch provisioning, remote monitoring, configuration, and troubleshooting from anywhere, at any time. This centralized management significantly simplifies large-scale deployments, reduces operational costs, and ensures consistent network performance across an entire property. The Ruijie RG-RAP1200(P) delivers a powerful combination of high-speed Wi-Fi 5 performance, extensive Gigabit connectivity with PoE Passthrough, intelligent cloud management, and flexible deployment, making it an excellent and future-proof choice for enhancing wireless and wired experiences in modern business and hospitality settings.
