TP-Link CPE220 WIRELESS OUTDOOR CPE

Price:

0.00


TP-Link CPE210 WIRELESS OUTDOOR CPE
TP-Link CPE210 WIRELESS OUTDOOR CPE
Not Available For Sale
TP-Link CPE510 WIRELESS OUTDOOR CPE
TP-Link CPE510 WIRELESS OUTDOOR CPE
Not Available For Sale

TP-Link CPE220 WIRELESS OUTDOOR CPE

https://arcip.com.au/web/image/product.template/8052/image_1920?unique=fa59611
TP-Link CPE220 TP-Link CPE220 WIRELESS OUTDOOR CPE.. Professional networking from TP-Link's Omada SDN platform. Australian stock from ARC IP Networks.

0.00 0.0 AUD 0.00 incl. GST

Not Available For Sale


  • Form Factor
  • WiFi Standard
  • CPU
  • RAM
  • Brand

This combination does not exist.

Outdoor TP-Link
  • Stock

    Authorised Australian Reseller | Australian Stock | Genuine Local Warranty

  • Instalment
    Buy Now, Pay Later
  • [Warranty Information] Warranty
    Manufacturer Warranty
Estimate delivery
Shipping calculated at checkout
Estimate delivery times: 3-7 business days
Guaranteed Safe Checkout
Guaranteed Safe Checkout
SKU
CPE220
Tags
CPE220
TP-Link CPE220 WIRELESS OUTDOOR CPE.

Features

  • TP-Link CPE220 TP-LINK WIRELESS OUTDOOR CPE.

Specifications

HARDWARE FEATURES
ProcessorQualcomm Atheros 560MHz CPU, MIPS 24Kc
Memory64MB DDR2 RAM, 8MB Flash
Interface1 10/100Mbps Shielded Ethernet Port (LAN0,Passive PoE in)1 10/100Mbps Shielded Ethernet Port (LAN1)1 Grounding Terminal1 Reset Button
Power SupplyPassive Power over Ethernet via LAN0 (+4,5pins; -7,8pins)Voltage range: 16-27VDC
Max. Power Consumption10.8 Watts MaxNote: When deployed using Passive PoE, the power drawn from the power source willbe higher by some amount depending on the length of the connecting cable.
Dimensions ( W x D x H )11×3.1×2.1 inch (276×79×60 mm)
AntennaBuilt-in 12dBi 2x2 Dual-polarized Directional AntennaBeam Width: 60° (H-Plane) / 30° (E-Plane)Note: For more details, please refer to datasheet
Protection15KV ESD Protection6KV Lightning Protection
EnclosureOutdoor ASA stabilized plastic materialIPX5 waterproof Certification
WIRELESS FEATURES
Wireless StandardsIEEE 802.11b/g/n (with Pharos MAXtream disabled)
Proprietary ProtocolTDMA Mode (with Pharos MAXtream enabled)
Wireless SpeedsUp to 300Mbps (40MHz,Dynamic)Up to 144.4Mbps (20MHz,Dynamic)Up to 72.2Mbps (10MHz,Dynamic)Up to 36.1Mbps (5MHz,Dynamic)
Frequency2.4~2.483GHzNote: Available operating frequency may vary depending on the limitationsof the countries or regions in which the device is used.
Transmission Power30dBm/1000mw (Adjustable power by 1dBm)Note: Maximum transmission power may vary across different channels depending on the limitations of the countries or regions in which the device is used.
SOFTWARE FEATURES
Wireless ConfigurationsPharos MAXtream TDMA Technology802.11b/g/n ModesSelectable Channel Width: 5/10/20/40MHzAutomatic Channel SelectionTransmission Power ControlDynamic Frequency Selection (DFS)WDS Enable/DisableSecurity: WPA/WPA2, WPA-PSK/WPA2-PSK (AES/TKIP) Encryption, 64/128/152-bit WEP EncryptionSSID Broadcast Enable/DisableMulti-SSID with VLAN Tagging (AP mode only)Distance/ACK Timeout SettingWireless MAC Address FilterWireless Advanced:> Beacon Interval/RTS Threshold/Fragmentation>Threshold/DTIM Interval/AP Isolation/Short GI/Wi-Fi Multimedia
Management FeaturesDiscovery and Remote Management via Pharos Control applicationHTTP/HTTPS Web-based managementSystem LogSNMP Agent(v2c)Ping Watch DogDynamic DDNSSSH Server
System ToolsWireless Signal Quality Indicators:Signal Strength/Noise/Transmit CCQ/CPU/MemoryMonitors: Throughput/Stations/Interfaces/ARP/Routes/WAN/DHCPSpectrum AnalyzerSpeed TestPingTraceroute
System-level OptimizationsOptimized IGMP Snooping/Proxy for multicast applicationsHardware watch dog
POE ADAPTER FEATURES
Dimensions(W x D x H)85.8×43.9×31.9 mm
Interfaces1 AC Jack with Earth Ground1 10/100/1000Mbps Shielded Ethernet Port (Power + Data)1 10/100/1000Mbps Shielded Ethernet Port (Data)
ButtonRemote Reset Button
Power Status LEDsGreen
Input100-240VAC, 50/60Hz
Output24VDC, 0.5A Max+4, 5pins; -7, 8pins. (Support up to 60m Power over Ethernet)
Efficiency>80%
CertificationsCE/FCC/UL/IC/GS/PSB/C-tick/SAA/S-Mark/KC-mark
OTHERS
CertificationCE, FCC, RoHS, IPX5
Package ContentOutdoor Wireless CPE24V 0.5A Passive PoE AdapterPole Mounting StrapsAC Power CordInstallation Guide
System RequirementsMicrosoft Windows 98SE, NT, 2000, XP, Vista™ or Windows 10, Windows 8, Windows 7,MAC OS, NetWare, UNIX or Linux.Note: We recommend you to use one of following Web browsers for an improved userexperience: Google Chrome, Safari, and Firefox. IE browsers are not recommended.
EnvironmentOperating Temperature: -40℃~70℃ (-40℉~158℉)Storage Temperature: -40℃~70℃ (-40℉~158℉)Operating Humidity: 10%~90% non-condensingStorage Humidity: 5%~95% non-condensing

Professional Overview

The TP-Link CPE220 (TP-Link CPE220 WIRELESS OUTDOOR CPE.) is a professional networking solution designed for business environments. TP-Link's Omada SDN platform provides centralized cloud management, zero-touch provisioning, and comprehensive network monitoring across all sites.

Performance specifications include a Qualcomm Atheros 560MHz CPU, MIPS 24Kc processor.

Managed through the Omada SDN Controller, the CPE220 supports VLAN management, ACLs, QoS, bandwidth control, and captive portal authentication. The unified platform enables consistent policies across access points, switches, and routers.

Built to TP-Link's commercial-grade standards. Australian stock from ARC IP Networks with fast nationwide shipping and local technical support.

Form Factor Outdoor ASA stabilized plastic materialIPX5 waterproof Certification
WiFi Standard IEEE 802.11b/g/n (with Pharos MAXtream disabled)
CPU Qualcomm Atheros 560MHz CPU, MIPS 24Kc
RAM 64MB DDR2 RAM, 8MB Flash
Brand TP-Link
